- Page 1 USER’S manual HDMI SPLITTER OPHD-H102 OPHD-H104 OPHD-H108...
-
Page 2: Table Of Contents
Table of Contents Introduction ………………........…2 Features ….…………………….....………………..2 Model name …………....………………….………2 Panel Descriptions …....………………….………3 Package contents .……….....…………….……….3 Installation .………………....……………………….4 7. Specification ………………………....……………..5 8. Precaution .……………………………....………….6 Warranty .……………………………...…....……….7 10. Contact us..............8 www.ophit.com... -
Page 3: Introduction
Introduction OPHIT’s HDMI distributor system(OPHD-Hx) let your one digital video signal (Set-Top box, DVD Player and PC) with HDMI output distributes into 2,4,8 digital displays such as PC monitor, HDTV(LCD,PDP) and Projector. Features • Connects 2, 4, 8 HDMI output ports at the same time to one HDMI input ports •... -
Page 4: Panel Descriptions
EDID Switch (for factory setting only) Package contents Before installing OPHD-Hx series, please check the package contents. • HDMI Splitter (OPHD-H102/OPHD-H104/OPHD-H108) • Power Adapter: - OPHD-H102/OPHD-H104 : +5V, 2A DC - OPHD-H108 : +12V, 3.33A DC • User’s Manual www.ophit.com... -
Page 5: Installation
1. Connect your source (DVD,PC,PS3..) to the Splitter’s input port. 2. Connect up to 8 displays (TV, Monitor, Projector) on the output ports. 3. Plug the adapter. 4. Check if all LED blink once. 5. Connected output’s green LED is on. www.ophit.com... -
Page 6: Specification
+12V, 3.33A DC adapter for OPHD-H108 • Dimension - OPHD-H102 : 150W x 85D x 25H (mm) / weight : 335g - OPHD-H104 : 170W x 85D x 25H (mm) / weight : 385g - OPHD-H108 : 435W x 150D x 45H(mm) / weight : 1030g •... -
Page 7: Precaution
Have the product checked by a qualified service engineer before using it again. • Do not touch the Product with wet hands. Touching the housing and plug with wet hands is dangerous and can cause electrical shock. www.ophit.com... -
Page 8: Warranty
Warranty We, OPHIT hereby warrant the final purchase of our product as follows. In the case of troubles on our products, please contact the shop purchased. One(1) year limited warranty Our customers have right to be served with free charge when there is trouble in this product during one(1) year from the day purchased. -
Page 9: Contact Us
Contact us OPHIT CO., LTD. www.ophit.com Head office 908/301 Digital EmpireⅡ, 486 Sin-Dong, Youngtong-Gu, Suwon-City, Kyunggi-Do 443-734, KOREA TEL : +82-31-695-5543 FAX : +82-31-695-5545 E-mail : support@ophit.com Factory 3F, Suntechnovil, 5-27, Mangpo-Dong, Youngtong-Gu, Suwon-City, Kyunggi-Do 443-440, KOREA TEL : +82-31-205-4191 FAX : +82-31-205-4197... - Page 10 MEMO www.ophit.com...
- Page 11 Rev. 1.1 Copyright ⓒ 2011 OPHIT All right reserved...
