Page 1: Cover
Gentleman’s Brand Ambassador kit v4 USER GUIDE... -
Page 2: Introduction
Gentleman's Brand Making Combustion Obsolete Founded in 2008, Gentleman’s Brand is committed to engineering premium vaporizer pens and portable vaporizer accessories. We believe in creating products that combine performance, safety and beautiful design, while providing world-class customer service. We stand behind all of our products. at’s why we o er a one year “No Hassle”... -
Page 3: Table Of Contents
Contents Cover..........................Introduction........................Contents..........................Ambassador Kit V4 Contents..................... Double Agent - Adjusting the Voltage, Recommended Voltage Settings......Turning On/O the Double Agent, Charging the Double Agent........Charging the Double Agent....................Priming the V2 and Mega V2 Cartridges................Priming (Continued)......................Filling the V2 Cartridge.................... -
Page 4: Ambassador Kit V4 Contents
Ambassador Kit V4 Contents Double Agent Pen w/Aesthetic Sleeve Fill Tool V2 Concentrate Cartridge w/Mouth Tip Non-stick Concentrate Jar Silicone Mouth Tip Wall Adapter Mega V2 w/Mouth Tip 420 mAh USB Rapid Charger... -
Page 5: Double Agent - Adjusting The Voltage, Recommended Voltage Settings
Double Agent - Adjusting the Voltage (Higher voltages may overheat coil causing permanently failure.) e Double Agent is a variable voltage vaporizer. By adjusting the voltage up or down you choose how much power goes to the heating element in the cartridge. Higher voltages provide more power causing larger vapor clouds, a higher temperature of vapor, and can cause a burnt taste if the voltage is too high. -
Page 6: Turning On/O The Double Agent, Charging The Double Agent
Turning On/Off the Double Agent e Double Agent can be locked in the o position so that accidental button pushes don’t drain the battery. Rapidly press the button 5 times to turn the Double Agent o . Pressing the button in this state will have no e ect. You will need to press the button another 5 times to turn on the Double Agent again. -
Page 7: Charging The Double Agent
Charging the Double Agent 1.5h 1. Screw the Double Agent into the USB rapid charging cord. 2. Plug the USB rapid charging cord in to your computer or the included wall adapter. e light on the charger will change color from red to green when the vaporizer is done charging. -
Page 8: Priming The V2 And Mega V2 Cartridges
Priming the V2 and Mega V2 Cartridges WARNING: Before you can ll your cartridge and begin using it, you need to prime the cartridge using the following instructions. 1. Remove the mouth tip from the cartridge. 2. Place your V2 or Mega V2 upright on a at surface. Your kit features holes in the removable foam layer inside the box to help hold cartridges upright during lling. -
Page 9: Priming (Continued)
Priming (Continued) 5. Gently heat the concentrate with a lighter until it begins to liquify. Drip 2 drops (0.1-0.2g) of 1 inch concentrate onto the heating coil at the center of the cartridge. 6. Screw the cartridge into your vaporizer. Do not attach the mouth tip yet. -
Page 10: Filling The V2 Cartridge
Filling the V2 Cartridge 1. If you haven’t already primed the cartridge please read the directions on Pages 7-8 rst. 0.2-0.4 g 2. Collect 0.2g - 0.4g of concentrate onto your 1 inch ll tool. Slowly heat the concentrate with a lighter until it slides o the ll tool. -
Page 11: Filling The Mega V2 Cartridge
Filling the Mega V2 Cartridge 1. Collect 0.5g - 1.0g of concentrate on your 0.5-1.0 g lling tool. Slowly heat the concentrate with a lighter until it slides o the ll tool. Try to 1 inch guide the concentrate down to the heating element at the bottom of the cartridge. -
Page 12: Concentrate Cartridge Filling Tips
Concentrate Cartridge Filling Tips While it's natural to want to ll the V2 Concentrate Cartridge to the top, this will result in suboptimal performance. is is because the vapor is produced at the bottom of the cartridge and needs to "bubble up" through the solid layer of concentrate above it. -
Page 13: Concentrate Cartridge Lifespan
Concentrate Cartridge Lifespan Keeping the heating coil clean will improve taste and cartridge lifespan. To clean the coil perform a “dry burn”. Press the button on your vaporizer until the coil starts to turn orange and then let it cool down for 4-6 seconds. en do it again. -
Page 14: Filling The Dry Herb Cartridge *Sold Separately At Gentlemansvapes.com
Filling the Dry Herb Cartridge IMPORTANT: Dry Herb cartridges are an optional upgrade when purchased online and are NOT INCLUDED in the Ambassador Kit. 1. Remove the mouth tip from the cartridge by pulling and twisting it away from the cartridge. 2. -
Page 15: Filling The Dry Herb Cartridge (Continued)
Filling the Dry Herb Cartridge (Continued) 4. Push the mouth tip back onto cartridge. en screw the cartridge securely onto the battery. Hold the battery vertically and press your mouth to the mouth piece. Push and hold the button while taking long slow drags. Tip: In between pu s, you can shake the contents of the cartridge to redistribute the herb. -
Page 16: Proper Vaping Technique
Proper Vaping Technique 1. Hold the vaporizer vertically or at a 45 degree angle. If you hold the pen horizontally (like a cigarette) your concentrate will drip away from the heating coil, producing less vapor. 2. Hold the button for 2 seconds and then begin inhaling slowly. If you inhale quickly, the heating coil cools down and you will get a smaller pu . -
Page 17: Troubleshooting
Troubleshooting At Gentleman’s Brand we pride ourselves in providing the highest quality vaporizers, globes and cartridges on the market. For new and returning customers we have set up a Frequently Asked Questions (FAQ) and a troubleshooting guide that answers technical issues we have recorded from our customers. www.GentlemansVapes.com/Support www.GentlemansVapes.com/Videos We recognize that not all issues can be covered in a FAQ or guide. -
Page 18: Warranty
Warranty Gentleman's Brand's unconditionally and directly guarantees, for a period of one year from the original purchase date, that the Double Agent,and included wall adapter and USB charger will be free from manufacturing defects. If, during this period, these parts fail to function properly during normal use, they will be repaired or replaced by Gentleman's Brand at no charge except shipping and handling. -
Page 19: Safety Warning
Safety Warning If your pen is malfunctioning, do not attempt to charge or disassemble it. Gentleman’s Brand vaporizers include lithium-ion batteries and you risk serious bodily harm and injury if attempting to repair, modify or use the pen in a manner otherwise speci ed in this manual. -
Page 20: End
Gentleman’s Brand www.GentlemansVapes.com...
