Summary of Contents for Telephone Technical Services DP3-AV
- Page 1 TELEPHONE TECHNICAL SERVICES USER GUIDE Manufactured in Australia for Telephone Technical Services PO BOX 675 SPRINGWOOD QLD 4127...
-
Page 2: Table Of Contents
Door Phone Performance Page Operation Summary Page Mounting the Door Phone Page Balance Pot Adjustment Page Wiring Diagrams Pages 10-11 Wiring Directions Pages 12-13 Surface Mounting Kits Page Door Phone Covers Page Specifications Pages Warranty Information Pages Page 2 Telephone Technical Services... -
Page 3: Description
D O O R S TAT I O N Telephone Technical Services CONTROLLER. It can be FLUSH MOUNTED or SURFACE MOUNTED if the optional SMK3-V or SMK3-H Surface Mount Kit is used (see p14). -
Page 4: Door Phone Dimensions
MODEL DP3 DOOR PHONE Page 4 Telephone Technical Services... -
Page 5: Door Phone Range
Touch switch operation with 99 User Codes Marine Grade Stainless Steel face plate. Blue and White LED Night illumination. Available in Vertical orientation only. Optional Surface Mounting Kit is available. (130mm Wide, 264mm High, 30mm Depth). Page 5 Telephone Technical Services... -
Page 6: Door Phone Performance
CONTROLLER where ADSL is used on the same line. If you do not do so, volume in both directions will be affected. Refer to your Door Station Controller User Guide for detailed information on the use of ADSL with this product. Page 6 Telephone Technical Services... -
Page 7: Operation Summary
For maximum clarity, it may be necessary to adjust the Balance Pot (see page 9). WHEN TESTING YOUR DOOR PHONE DO NOT USE A TELEPHONE IN CLOSE PROXIMITY AS FEEDBACK WILL CAUSE LOSS OF VOLUME. Page 7 Telephone Technical Services... -
Page 8: Mounting The Door Phone
Stainless Steel Surface Mounting Kits are available for all Model DP2 to DP5 Door Phones, so that your Door Phone can be mounted ONTO a wall surface, rather than into it. See page 14 for further detail. Page 8 Telephone Technical Services... -
Page 9: Balance Pot Adjustment
PHONE, as feedback interference will affect the Balance Pot settings. 4) The Balance POT does not increase volume. Moving it when unnecessary may cause a deterioration in audio quality or a loss of audio in 1 direction. Page 9 Telephone Technical Services... -
Page 10: Wiring Diagrams Pages
LOCK 2 WHITE ORANGE LOCK 1 LOCK 1 BROWN BLACK POWER POWER YELLOW RED AUDIO AUDIO GREEN CAT5 CABLE or SOLID CORE CABLE The colours used are those of the wires in the supplied Interface box. Page 10 Telephone Technical Services... - Page 11 DOOR PHONE WIRING BLACK POWER POWER YELLOW AUDIO AUDIO GREEN CAT5 CABLE or SOLID CORE CABLE The colours used are those of the wires in the supplied Interface box. Page 11 Telephone Technical Services...
-
Page 12: Wiring Directions Pages
Note : The polarity of the Audio signal and power connections is not important and can be reversed. Important Note : The colours referred to on this page and page 13 are those of the wires in the supplied interface box. Page 12 Telephone Technical Services... - Page 13 2 positions of the DP2 Phoenix socket. POWER CONNECTION (polarity is not important) The 2 pins either side of the centre 2 pins of the DS Controller socket connect to the 2 outer positions of the 4 pin Phoenix socket. Page 13 Telephone Technical Services...
-
Page 14: Surface Mounting Kits
All kits have an integrated Rain Deflector. Model SMK2-V for DP2 units mounted vertically Model SMK2-H for DP2 units mounted horizontally Model SMK3-V for DP3, DP4, DP5 mounted vertically Model SMK3-H for DP3, DP4 mounted horizontally Page 14 Telephone Technical Services... -
Page 15: Door Phone Covers
Model DPC2-V : for Model DP2 Door Phone Model DPC3-V : for Model DP3, DP4, DP5 COVERS FOR HORIZONTAL MOUNTED DOOR PHONES Model DPC2-H : for Model DP2 Door Phone Model DPC3-H : for Model DP3, DP4 Door Phones Page 15 Telephone Technical Services... -
Page 16: Specifications Pages
Damage caused to this device or attached equipment, by lightning strikes or over voltage surge is not covered under this warranty. CASE SEALED AT FACTORY OPENING THE CASE VOIDS THE WARRANTY Page 16 Telephone Technical Services...
