The producer is given the right to modifiy the present manual without updating previous editions.
DALLA CORTE
Via Broglio, 24
20158 Milano Italy
A
Filter holder with two cups spout
B
Filter set
C
Shower
D
Brush
E
Tamper
F
"T" key for shower screw
G
Dosing measure
USER'S INSTRUCTION
USER'S MANUAL
"MINI" PROFESSIONAL
IDENTIFICATION PLATE
S.r.l
COFFEE MACHINE'S DOTATION
WARNING
N.F.
Lt.
1,50
MOD. MINI
VOLT.
220 Hz 50 - 60
WATT. 1850 IPX2
ANNO
0.15MPa
LII REV. 05
1
Advertisement
Table of Contents
Summary of Contents for DallaCorte MINI PROFESSIONAL
- Page 1 USER’S MANUAL “MINI” PROFESSIONAL WARNING The producer is given the right to modifiy the present manual without updating previous editions. IDENTIFICATION PLATE DALLA CORTE N.F. ANNO S.r.l Via Broglio, 24 1,50 0.15MPa 20158 Milano Italy MOD. MINI VOLT. 220 Hz 50 - 60 WATT.
- Page 2 Installation must be carried out by qualified or authorized service people following producer’s instructions. WARNING Please read carefully all advices of the present manual, since it gives important indications regarding safety, installation use and service. Incorrect installation might damage people, animals or objects ,and the producer cannot be considered responsible for this damage WARNING The machine’s electrical safety is guaranteed only when the machine is properly and effectively installed as...
- Page 3 -in case of trouble or bad function ,turn off the appliance (turn off the main switch and the main clock). Any improper use or no observance of the present “User's instruction” will not give right to any term of guarantee or liability by the producer STARTING UP PROCEDURES Follow the instruction with help of drawing (page 5) •Raise the upper grill (5) and take out the water tank (6) putting pipe out.
- Page 4 HOW TO HEAT MILK (FOR CAPPUCCINO) Put milk in a jug. Place steam tube (9) in milk jug and open steam tap (8). When milk temperature is right as desired, turn off steam tap(8). Remember tol clean steam tube with a damp cloth in order to remove all milk deposit on steam tube ! WARNING Do not open steam tap(8) before put steam tube(9) inside milk jug, because it is possible to burn oneself!
- Page 6 FIG 2 LEGENDA Main swicth Push-button panel (3 switches) Group head Upper grill Water tank 3 liter capacity Complete filter holder Steam tap Steam tube 10 Cup-ret basin 11 Cups grill 12 Manometer 13 Back panel 14 Screws 15 Grill for boiler protection 16 Temperature regulation knob ALARMS Electronic control board guarantee correct functions.
- Page 7 COFFEE GROUP TEMPERATURE REGULATION The installed electronic central control unit has got a temperature which can be regulated between 85° C and 110° C In order to set the temperature of the coffee group, follow these instructions: • In order to raise the temperature of the group, turn the regulation knob (pic. 3) clockwise, in order to decrease it turn it anticlockwise (the regulation knob can turn by ¾...
