DIGITAL AUDIO PLAYER

(ORC-200M)

User Manual

- 1 -

Table of Contents

Need help?

Do you have a question about the ORC-200M and is the answer not in the manual?

Questions and answers

Summary of Contents for Oracom ORC-200M

Page 1 DIGITAL AUDIO PLAYER (ORC-200M) User Manual - 1 -...
Page 2: Table Of Contents
# CONTENTS # @ PREPARATION ■ Feature ■ Checking parts ■ Names and functions of ORC-200M ■ LCD display panel @ INSTALLATION AND USE ■ Turning on/off the power ■ Setting the modes ■ Playing back digital music/voice files ■ Adjusting the volume ■...
Page 3: Checking Parts
° Digital Audio Player (ORC-200M) ° Stereo Earphone ° USB cable ° Installation CD ° One AAA size battery ° User manual ■ Names and functions of ORC-200M Earphone jack Microphone LCD display pannel Volume control button Mode button ◀◀ / ▶▶ button ▷□...
Page 4: Installation And Use
0 3 : 3 6 : 5 2 ° Press the ▷□ button on the ORC-200M for longer than 1 seconds to turn off the power. If the unit is in the Stop mode for longer than 1 minute, it will power off automatically.
Page 5: Setting The Section Repeating Function
ORC-200M. * VBR(Variable Bit Rate) file: MP3 file which has multi compression rates applied ° To move the desired spot of the song during playback Press the ◀◀ / ▶▶ button for longer than 1 second and release the ◀◀ / ▶▶ button at the desired spot of the song.
Page 6: Button Table
■ BUTTON TABLE Button Former status Push time Operation Power off Briefly Playback after power on Music/Voice playback Briefly Stop Music/Voice playback Recording Longer Power off Stop ▷□ Stop (Music/Voice mode) Briefly Playback Stop (Recording mode) Briefly Start Voice Recording Recording Briefly Finish Voice Recording...
Page 7: Application
@ APPLICATION ■ SETTING THE MENU ° Press the mode button for longer than 1 sec., and it is converted to the menu mode. When selecting, use the mode button and when moving the different order, － use + / button.
Page 8: Managing Files
Caution) All files are deleted when executing the format. ■ SETTING THE LOGO ° Logo can be selected in the display panel. - Default: Oracom Logo - User: User's Logo by using the logo editor ° Display logo It can be selected if the logo is displayed always...
Page 9: Display The File Information
1. On: Turned on always 2. Off: Turned on accordance with the time. 3. Lighting Time: The lasting time of backlight － Set the time to press + / button. B A C K L I G H T ① O n ②...
Page 10: Menu Table
■ MENU TABLE MENU Repeat 1.Normal 2.Repeat one 3.Repeat all Repeat list 4.Repeat list ▶ 1.file1 5.Shuffle 2.file2 6.Intro 3.file3 ... Return Return User 1.Normal 2.User ▶ 10 Band Return File 1.Delete ▶ Delete Music/Voice Format 1.Music ▶ 2.Format ▶ 1.M/V file1 1.OK 2.Voice ▶...
Page 11: Computer Conncetion
Note) Do not need to install the driver again after installation for use of windows98/SE ° Insert the installation CD supported to "CD-ROM driver" in PC and plug ORC-200M into PC's USB port. Click on the next button when the pop-up diagram shows as below.
Page 12 ° on the next button when the pop-up diagram shows as below. Check "CD-ROM drive" and click ° Click on the next button when the pop-up diagram shows as below.. - 1 2 -...
Page 13: Connecting Orc-200M To Pc
"Removable Disk" folder is made in the My Computer of the Window Explore. ° The usage is the same as floppy disk or hard disk. When ORC-200M is removed from PC, the Removable Disk is disappeared in the My Computer folder.
Page 14: Managing Files
The message, Waiting shows in the display panel of ORC-200M while connecting to PC. P C < - > P l a y e r S t a n d b y ■ MANAGING FILES ° There are MUSIC, VOICE, and LOGO folder in the Removable disk and they are still existed even if formatted.
Page 15: Formatting
ORC-200M from PC. The data is damaged while the data is being transferring when separating ORC-200M from PC. Caution) Do not separate ORC-200M from PC during PC<->Player ( ▶ ) is moving in the display panel of ORC-200M. Note) In Windows 2000, ME, and XP, the safe procedure will be to double click on the icon( located at the bottom right corner of your screen and follow instructions before removing.
Page 16: Logo Editor
@ LOGO EDITOR ■ INSTALLING LOGO EDITOR ° Install the logo editor program supported from CD. ■ EDITING LOGO ° To use the frame function - What is the frame function? It is the logo editor function to make several pictures into one logo and to show the logo in the display panel continuously.
Page 17 ° The example of the second page for frame ° The example of the third page for frame - 1 7 -...
Page 18 ° The example of the fourth page for frame ° To import the picture file Select the Convert image icon ( ) in the menu icon. Select the desired picture file to click on the Open button as below. Transfer the logo to the Logo Editor if the desired logo is made The desired logo is made in the display panel of the Logo Editor as the sample above.
Page 19: Installing Logo
If any other folders are used except LOGO or any folders are made in the LOGO folder for the input of the logo file, the logo can not be displayed in the display panel. ° Select Display->Logo->User in the menu mode and the display panel of ORC-200M shows your own logo...
Page 20: Customer Service
@ CUSTOMER SERVICE ■ PRODUCT SPECIFICATION ° Memory Capacity: 64/128/256/512MB built in memory ° Communication Method: Supporting USB 1.1(Plug & Play) ° Earphone Output Power: 5.0mW / 16 Ω ° S/N, THD: 80dB / 0.1% (with 'A' filter) ° Output Frequency Range: 20Hz ~ 20KHz °...
