Rivas
INSET LIVE FUEL-EFFECT GAS FIRES
User Instructions
These instructions should be read by the user before operating the
appliance and retained for future reference
Model No's AICC**MN2 & AICC**SN2 are only for use on Natural Gas
(G20) at a supply pressure of 20 mbar in G.B. / I.E.
Model No's AICC**MP & AICC**SP are only for use on Propane Gas
(G31) at a supply pressure of 37 mbar in G.B. / I.E.
** denotes trim and fret variant fitted to product

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rivas and is the answer not in the manual?

Questions and answers

Related Manuals for Formosa Fires Rivas

Summary of Contents for Formosa Fires Rivas

  • Page 1 Rivas INSET LIVE FUEL-EFFECT GAS FIRES User Instructions These instructions should be read by the user before operating the appliance and retained for future reference Model No’s AICC**MN2 & AICC**SN2 are only for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E.
  • Page 2 This should be con- sidered when installing or decorating. The Model number of this appliance is as stated on the rating plate affixed to the control panel of the fire and the appliance is manufactured by:- Formosa Fires...

  • Page 3: Important Safety Information

    ABOUT YOUR NEW FORMOSA FIRES RIVAS GAS FIRE The Formosa Fires Rivas coal effect gas fire incorporates a unique and highly developed fuel bed which gives the realism of a loose coal layout combined with realistic flames and glow. The use of durable ceramic material in the construction of the fuelbed components ensures long and trouble free operation.

  • Page 4: Operating The Fire (Manual Control Models)

    The fire must only be operated with a fender which meets the criteria described in the rear of this book. OPERATING THE FIRE (MANUAL CONTROL MODELS) The controls are located behind the ashpan cover which is situated behind the Ashpan / Fender. The controls, comprise a control valve to adjust the gas flow and a push button piezo igniter.

  • Page 5: Operating The Fire (Slide Control Models)

    OPERATING THE FIRE (SLIDE CONTROL MODELS) The controls comprise a control lever, to turn the fire on and off and adjust the gas rate. The control lever is located at the top right hand side of the fire. Depressing the control lever fully operates the igniter and lights the pilot flame and ignition rate gas.

  • Page 6: Cleaning The Fuel Bed

    None of these parts must be washed or exposed to any cleaning agents or water. Any damaged parts must be replaced by contacting your dealer or telephoning Formosa Fires on the number stated on the rear cover of this book. Coals must only be replaced with a complete and genuine replacement set and the fire must never be run with the wrong number or damaged coals.
  • Page 7 RE-ASSEMBLING FUEL BED AND COMMISSIONING Place the ribbed ceramic fuelbed base on top of the fuelbed support and pull fully forwards to the burner. Make sure that the fuelbed base is located centrally in the fire box. Ensure that the fuelbed base fit fully down onto the fuel bed support and is not lodged on the burner.
  • Page 8 Fit three of the large sized square coals onto the front ceramic rail, and two of the random shaped coals as shown below ensuring that they are evenly spaced. Use the recess’s in the front ceramic rail as a guide for placement. (See figure 3 below). Fig.
  • Page 9 Select three of the large random coals and two of the large square coals and arrange as shown behind the second row of coals, using the ribs in the fuelbed matrix as a guide for placement. (See figure 5 below). Fig.
  • Page 10 The exact position and fit of the coals may be finely adjusted to give the most pleasing and random appearance. This appliance uses fuel effect pieces containing Refractory Ceramic Fibres (R.C.F.), which are man-made vitreous silicate fibres. Excessive exposure to these materials may cause temporary irritation to eyes, skin and respiratory tract.

  • Page 11: User-Replaceable Parts

    GAS SAFE registered gas installer. The part numbers of the user replaceable parts are as follows, these are available from Formosa Fires who may be contacted at the address shown below. Fuelbed base B-58690 Fuelbed front rails (L/H &...
