Summary of Contents for Dea smartwifi

  • Page 2: Getting To Know Your Device

    Getting to Know Your Device Appearance The following figure is for your reference only. Device cap Front cover Indicator light USB connector SIM card slot...

  • Page 3: Indicator Light

    Getting to Know Your Device Indicator Light Indicator Status Description Red solid Turned on and not registered. Green solid Registered to 2G network. Blue solid Registered to 3G network. Green blinking Connected to 2G network and data is being transferred. Blue blinking Connected to 3G network and data is being transferred.

  • Page 4: Connection Scenarios

    Getting to Know Your Device Connection Scenarios The device can access the Internet by using a SIM card and it allows multiple clients to surf on the Internet at the same time. The following figures are for your reference only. NOTE: With other accessories, such as mobile power or car power adapter, you can supply power to your device and use it anywhere and anytime.

  • Page 5: Installing Your Device

    Installing Your Device Open the front cover. Install a SIM card to the SIM card slot. WARNING! Your device does not support the micro-SIM and nano-SIM card or any other non-standard SIM cards. To avoid damage to the device, do not use those cards or any card holders.
  • Page 6 Installing Your Device Close the front cover.

  • Page 7: Connecting To Your Device

    Connecting to Your Device Using USB Connecter Insert the device into your computer’s USB port securely. The operating system automatically detects and identifies your modem and starts the installation wizard. NOTE: If the system does not automatically launch installation, you can click the device in- stallation icon in My Computer to install the software.
  • Page 8 Connecting to Your Device Using Wi-Fi Supply power to your device by connecting to your PC or using other accessories. Ensure that your computer or other client devices have enabled Wi-Fi, and search for avail- able wireless networks. NOTE:Refer to your Wi-Fi-enabled client device manual for further details on how to search for wireless networks.
  • Page 9 Connecting to Your Device Using charger Supply power to your device by connecting to your Normal charger slot Getting to Know the Wi-Fi SSID and Password You can view the label on the device to get the default Wi-Fi SSID and password.
  • Page 10 Logging in to the IDEA Smart Wi-Fi Configuration Page Ensure that the connection between your device and the client device is correct. Launch the Internet browser and enter http://192.168.0.1 or http://idea.smartwifi in the ad- dress bar. NOTE: It is recommended that you use IE (7.0 or later), Firefox (15.0 or later), Opera (10.0 or later), Sa- fari (4.0 or later), or Google Chrome (10.0 or later).
  • Page 11 Changing the Wi-Fi SSID or Password Log in to the Idea Smart Wi-Fi configuration page. Select Settings > Wi-Fi Settings > Basic Settings. Change the Network Name (SSID) or the Pass Phrase (Password). Click Apply. NOTE: • To reset all the passwords, kindly press the reset button on the backside of the datacard. •...

  • Page 12: Accessing The Internet

    Accessing the Internet After a client device is successfully connected to your device, you can access the Internet in Au- tomatic or Manual mode. The default mode is Automatic. Mode Operation Your device is automatically connected to the Internet, and you can surf on the Automatic Internet through the client.

  • Page 13: Managing Your Device

    Managing Your Device Changing the Device Password Select Settings > Device Settings > Account Management. Enter the current password you use. Enter the new password you want to use. Enter the new password again. Click Apply to save your changes.
  • Page 14 Managing Your Device NOTE: If you forget the current password, go to Settings > Device Settings > Reset and click the Reset button to restore to the default password. Blocking Users on Wi-Fi Select Settings > Wi-Fi Settings > Black List. Check Enable and then click Apply to enable this function.
  • Page 15 Managing Your Device Click Block behind the connected client you want to block and then it will be added to the black list. NOTE: To unblock the client, click Delete behind it.
  • Page 16 Managing Your Device APN Settings Select Settings > Network Settings > APN. The APN parameters are shown in the following figure. The default APN mode is Auto.
  • Page 17 Managing Your Device To change the APN mode, check Manual and then you can add new APN item manually.
  • Page 18 Managing Your Device Click Add New. Enter the related parameters as described in the table below and then click Apply to add one new profile.
  • Page 19 Managing Your Device Parameter Function PDP Type Choose a PDP type from the drop-down list, IPv4 / IPv6 / IPv4&IPv6. Profile Name Type the profile name. Type the APN string. Password Authentication Protocol (PAP) provides a simple method without encryption for the peer to establish its identity using a 2-way handshake. Authentication Challenge-Handshake Authentication Protocol (CHAP) is used to periodically verify the identity of the peer using a 3-way handshake.

  • Page 20: Configuring Your Pc

    Configuring Your PC The following procedure describes how to configure the Internet Protocol in the Windows 7 oper- ating system for your Wi-Fi connection. Right-click Network and select Properties. Select Change adapter settings. Right-click Wireless Network Connection and select Properties. Select Internet Protocol Version 4 (TCP/IPv4), and click Properties.

  • Page 21: Warning And Notice

    Warning and Notice To the Owner • If inadequately shielded, some electronic devices, for example, the electronic system of vehicles, may be affected by the electromagnetic interference caused by the device. Consult the manufacturers of such devices before using the device if necessary. •...
  • Page 22 Warning and Notice • Do not use electronic transmission devices in aircrafts, at petrol stations or in hospitals. Ob- serve and obey all warning signs, and power off the device in these conditions. • Do not touch the inner antenna area unless necessary. Otherwise the performance of the device may be affected.
  • Page 23 Warning and Notice To the Users • Use original accessories or accessories that are authorized. Using any unauthorized acces- sories may affect the performance of the device and violate the related national regulations about telecom terminals. • Avoid using the device near or inside metallic constructions or establishments that can emit electromagnetic waves, because signal reception may be affected.

  • Page 24: Limited Warranty

    Warning and Notice • Only qualified personnel can dismantle and repair the device. • An operating temperature between -10°C and +60°C and humidity between 5% and 95% are recommended. Limited Warranty This warranty does not apply to defects or errors in the product caused by: Reasonable abrasion.
  • Page 25 Warning and Notice Power failures, surges, fire, flood, accidents, and actions of third parties or other events outside ZTE’s reasonable control. vi. Usage of third-party products or usage in conjunction with third-party products if such defects are due to the combined usage. vii.

  • Page 26: Limitation Of Liability

    Warning and Notice Limitation of Liability ZTE shall not be liable for any loss of profits or indirect, special, incidental or consequential dam- ages resulting from or arising out of or in connection with using of this product, no matter whether or not ZTE had been advised, knew or should have known of the possibility of such damages, including, but not limited to lost profits, interruption of business, cost of capital, cost of substitute facilities or product, or any downtime cost.

  • Page 27: Legal Information

    LEGAL INFORMATION Copyright © 2015 ZTE CORPORATION. All rights reserved. No part of this publication may be excerpted, reproduced, translated or utilized in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior writ- ten permission of ZTE Corporation.

  • Page 28: Troubleshooting

    Troubleshooting Problem Recommended Action The connection between your de- Install the software, and run the installation program in the vice and a PC through a USB cable path of My Computer. cannot be established. • Ensure that the Wi-Fi function is enabled. •...
  • Page 29 Contact your service provider and confirm your APN settings. • Enter the correct address. The default address is The Idea Smart Wi-Fi configuration http://192.168.0.1 or http://idea.smartwifi. page cannot be visited. • Use only one network adapter in your PC. •...
  • Page 30 For more assistance, please: • Send an email to mobile@zte.com.cn • Visit www.ztedevice.com • Call the service hotline: +86-755-26779999...
