StoveTec Wood/Charcoal
Stove Manual
This instruction manual can be translated into the local
language. For a template, please contact:
StoveTec
PO Box 1175
79093 Highway 99
Cottage Grove, Oregon 97424
541-767-0287
Instructions and photos by Evan Shenkin, Illustration by Lance MacCarty
www.stovetec.net
USA
Detailed Instructions for
the Wood/Charcoal Stove
The Wood/Charcoal stove can be used with wood or
charcoal fuels.
• For wood burning, open the big door and place the
fuel shelf in front of the stove. Insert the sticks,
burning only at the ends makes a lot less smoke.
Control the airflow using the little door – fully open for
high power, 1/2 open for low power. To light the
stove, place some kindling inside the combustion
chamber. Add larger pieces of wood when the flame
is established. Continue pushing sticks into the stove
as they are burned. Do not overfill the stove.
• To use the stove with charcoal, insert the ceramic
piece and close the big door. Then fill with charcoal
from the top. Control the power of the stove by
adjusting the small lower door, fully open for high
power and almost fully closed for low power. The
ceramic piece must be used or the metal door will
burn out quickly.
• The adjustable pot skirt helps to save fuel! Loosen the
nut and adjust the skirt making sure that the skirt touches
the top of the stove. Then tighten the nut.
Use the stove only in a well-ventilated area!
Do not use the stove indoors.
Keep the stove out of the rain. Keep it dry.
Use stove on a heat-resistant surface.
Advertisement
Summary of Contents for StoveTec Wood/Charcoal Stove
- Page 1 Detailed Instructions for StoveTec Wood/Charcoal the Wood/Charcoal Stove Stove Manual The Wood/Charcoal stove can be used with wood or charcoal fuels. • For wood burning, open the big door and place the fuel shelf in front of the stove. Insert the sticks, burning only at the ends makes a lot less smoke.
-
Page 2: Carbon Monoxide Hazard
Failure to comply with the precautions and instructions provided with this stove can result in death, serious bodily injury and property loss or damage from hazards of fire, burn, • This stove is red hot during use and can ignite flammables asphyxiation, and/or carbon monoxide poisoning. - Page 3 3. Place pot skirt under bottom of pot. ======================= Instructions for using Stove with ======================= ------ Use stove in a well-ventilated area on heat resistant 4. Press pot skirt together and tighten screw. surface. ----- 1. Open the big door. Remove brick from stove. 5.
- Page 4 Special tips for reducing fuel use while 7. Larger sticks catch fire from the kindling underneath. cooking with wood: 8. Burning the sticks at the tip will create much less smoke. Push sticks into the stove as they burn up. Keep lid on pot at all times.
- Page 5 C. Put brick back into stove. Slide top door and close ======================= completely. Instructions for using Stove with ======================= ------Use stove outside on a heat resistant surface------ 1. Put brick back into stove. Slide top door and close completely. The brick must be used with charcoal or the metal door will burn out quickly.
- Page 6 5. Place pot skirt under bottom of pot. Do not overload with fuel 6. Press pot skirt together and tighten screw. The stove body is hot – do not touch 7. Place the pot and pot skirt on top of the stove. Push the pot skirt down onto the top of the stove.
- Page 7 Delivering clean and efficient stove to the world cooks won’t happen on it’s own. StoveTec is brought to you by Aprovecho Research Center, same people who have worked tirelessly for the last 30 years to design and build the world’s new standard for biomass stoves, and who have completed over 100 projects in 60 countries.
