Summary of Contents for Quesh Ltd 68888
- Page 1 Rugged DAB Radio with FM & AUX MODEL NUMBER: 68888 USER GUIDE After Sales Support UK/N.IRELAND HELPLINE N 01270 508538 REP.IRELAND HELPLINE N 1800 995 036 WEBSITE: www.quesh.co.uk EMAIL: enquiries@quesh.co.uk...
-
Page 2: Table Of Contents
Contents Welcome Section AUX Mode • Select AUX Mode Information & Safety Instructions • Using AUX Input • AUX Menu Option Contents & Features 11-14. System Options Controls & Layout • Sleep • Alarm (See Page 16) On/Off & Standby Control •... -
Page 3: Welcome Section
By doing so you now have the assurance and peace of mind which comes from purchasing a product that has been manufactured to the highest standards of performance and safety, supported by the high quality standards of Quesh Ltd. We want you to be completely satisfied with your purchase, so this MAXTEK product is backed by a comprehensive manufacturer’s... -
Page 4: Information & Safety Instructions
Information & Safety Instructions This radio can be powered by the 5V mains adaptor (included) or by 4 x ‘C’ size alkaline batteries (not included). Do not dispose of batteries in your household waste. Please contact your local authority for details on safe disposal. •... -
Page 5: Contents & Features
Contents & Features Contents 1 x Rugged DAB Radio 1 x 5V Mains Adaptor 1 x Telescopic Aerial Features • DAB receiver (174MHz - 240MHz) • FM receiver (87.5MHz - 108.00MHz) • Stores 10 FM presets • Stores 10 DAB presets •... -
Page 6: Controls & Layout
Controls & Layout Mode Preset Preset Preset Preset Info/Menu On/Off Scan Shift Preset Snooze Vol +/- 5/10 Tuning/Enter On/Off & Standby Control Turning On After the radio has been connected to a suitable power supply press the button to put the radio into ‘Standby’ mode. Press the button again to turn the radio on Turning Off Press and hold the... -
Page 7: Setup
Setup First Time Use After removing the radio from the packaging, connect the radio to a suitable power supply using the adaptor supplied or insert 4 x ‘C’ batteries into the battery bay in the back. Fully extend the aerial and press the button to enter standby mode and again to turn it on. -
Page 8: Dab Mode
DAB Mode Selecting A Station Use the ‘Tuning/Enter’ dial to cycle through the available DAB stations on the display. Press the dial to tune the radio into the station that is shown on the display. Scan You can retune or refresh the amount of DAB stations available by pressing the ‘Scan’... -
Page 9: Manually Tune Dab
Manually Tune DAB To manually tune the radio select ‘Manual Tune’ in the menu options. Use the ‘Tuning/Enter’ dial to tune the radio in then press the same dial to keep the current tuning. Save as a preset if required, (see page 14). -
Page 10: Prune
DAB Options Prune You can remove DAB stations from the radio that are listed with a ‘?’ in front of their name by using the prune function. Once you’ve selected a station you wish to remove, select ‘Prune’. from the menu options. You will be presented with the choice ‘Yes’ or ‘No’. -
Page 11: Fm Options
FM Options FM Menu Options Press and hold the ‘Info/Menu’ button until you see ‘Scan Setting’. Use the ‘Tuning/Enter’ dial to cycle through the options then press the same dial to select an option. The options here are: Scan Setting > Audio Set > System (See page 11). Scan Settings You can change the Auto Tune search ability between ‘all stations’... -
Page 12: Aux Mode
AUX Mode Select AUX Mode To select AUX press ‘Mode’ till ‘AUX’ shows on the display. Using AUX Input Connect a 3.5mm jack cable from the device like a mobile, MP3 player, tablet, etc, to the AUX port at the back of the radio. Make sure the device connected has the volume output at maximum in order to play the sound through the radio. -
Page 13: System Options
System Options System Menu Options Press and hold the ‘Info/Menu’ button until you see ‘Scan Setting’ in either DAB or FM mode, and ‘System’ in AUX mode. Turn the ‘Tuning/Enter’ dial to cycle to ‘System’ and press the same dial to select ‘System’. -
Page 14: Time
System Options Time All the time and date functions and preferences can be altered here. Turn the ‘Tuning/Enter’ dial to cycle through the options and press the same dial to select it. The options here are: Time/Date > Auto Update > Set 12/24 > Date Format. Time/Date With this option you can manually set the time and date. -
Page 15: Backlight
System Options Backlight You can change the brightness and light duration of the display. Turn the ‘Tuning/Enter’ dial to cycle through the options and press the same dial to select one. The options here are: Time Out > On Level > Dim Time Out This is to set the duration of time before the display dims. -
Page 16: Inactive Standby
System Options Inactive Standby (Sleep) You can set the radio to turn it’s self to standby after a preselect period of time with this feature. Choose from the options by turning the ‘Tuning/Enter’ dial and press the same dial to select. Choose from the following options: OFF >... -
Page 17: Dab/Fm Preset
DAB/FM Preset The radio has 10 preset slots for both DAB and FM selections. Storing Preset 1-5 Tune a station in on either DAB or FM and make sure it is currently playing. Press and hold one of the Presets marked 1/5, 2/6 3/8,4/9 or 5/10. -
Page 18: Dab/Fm Information
DAB/FM Information Information Details When listening in DAB or FM mode you can cycle through the available information from the broadcasting service and the radio by pressing the ‘Info’ button. The information cycle: • Now Playing • Now Playing • Power Type •... -
Page 19: Turning The Alarm On/Off
Alarm Setting the Alarm The process is controlled by using the ‘Tuning/Enter’ dial cycle through the available options and pressing it to select an option. Once an option has been selected it will move on to the next value to set until the process is complete. Process flow: Alarm: Alarm 1 Setup >... -
Page 20: Specifications
Specifications Specifications • DAB receiver (174MHz - 240MHz) • FM receiver (87.5MHz - 108.00MHz) • Stores 10 FM presets • Stores 10 DAB presets • Powered by 4 x C alkaline batteries (not included) • 5v mains adapter (included) • Auto adjusting clock •... - Page 21 Intentionally Left Blank...
- Page 22 Warranty Certificate Warranty This product is warranted to be free from defects in workmanship and parts for a period of 36 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour.
- Page 23 Warranty Card Rugged DAB Radio with FM & AUX Model Number: 68888 Please keep your purchase receipt together with your warranty card Name: Address: Date of purchase: Location of purchase: Fault Description: We recommend that you attach a photocopy of your receipt, showing the date of purchase, to this warranty card and keep it for your reference.
