Korg strokerhythm efgsj2 Owner's Manual

In-ear golf metronome.
Hide thumbs

Thank you for purchasing the Korg StrokeRhythm IN-EAR
GOLF METRONOME.
Merci d'avoir choisi LE MÉTRONOME-OREILLETTE DE GOLF
StrokeRhythm de Korg.
Vielen Dank, dass Sie sich für das IN-EAR-GOLF-METRONOM
StrokeRhythm von Korg entschieden haben.
Gracias por comprar el METRÓNOMO DE OÍDO PARA GOLF
StrokeRhythm de Korg.
こ の た び は、コ ル グ・ イ ン イ ヤ ー・ ゴ ル フ・ メ ト ロ ノ ー ム
StrokeRhythmをお買い上げいただきまして、 まことにありがと
うございます
アフターサービス
修理、 および
商品のお取り扱いについてのご質問、 ご相談は、 お
客様相談窓口へお問い合わせください。
お客様相談窓口
PHS等一部の電話ではご利用できません。固定電話また
は携帯電話からおかけください。
受付時間 月曜~金曜 10:00 ~ 17:00 (祝祭日、 窓口休業日を除く)
●サービス・センター :
〒168-0073 東京都杉並区下高井戸1-18-16 2F
■お願い
1. 保証書に販売年月日等の記入がない場合は無効となります。記入でき
ないときは、 お買い上げ年月日を証明できる領収書等と一緒に保管し
てください。
2. 保証書は再発行致しませんので、 紛失しないように大切に保管してく
ださい。
保証書
コルグ
StrokeRhythm
本保証書は、 保証規定により無償修理をお約束するものです。
お買い上げ日
販売店名
CALIFORNIA USA ONLY
Perchlorate Material–special handling may apply, See
www.dtsc.ca.gov/hazardouswaste/perchlorate.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
CAN ICES-3 B / NMB-3 B.
Precautions
Location
Using the unit in the following locations can result in a malfunction.
• In direct sunlight.
• Locations of extreme temperature or humidity.
• Excessively dusty or dirty locations.
• Locations of excessive vibration.
• Close to magnetic fields.
Power supply
Be sure to turn the power switch to OFF when the unit is not in use.
Remove the battery in order to prevent it from leaking when the unit is
not in use for extended periods.
Interference with other electrical devices
Radios and televisions placed nearby may experience reception
interference. Operate this unit at a suitable distance from radios and
televisions.
Handling
To avoid breakage, do not apply excessive force to the switches or
controls.
Care
If the exterior becomes dirty, wipe it with a clean, dry cloth. Do not use
liquid cleaners such as benzene or thinner, or cleaning compounds or
flammable polishes.
Keep this manual
After reading this manual, please keep it for later reference.
Keeping foreign matter out of your equipment
Never set any container with liquid in it near this equipment. If liquid gets
into the equipment, it could cause a breakdown, fire, or electrical shock.
Be careful not to let metal objects get into the equipment.
THE FCC REGULATION WARNING (for USA)
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equip-
ment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
If items such as cables are included with this equipment, you must
use those included items.
Unauthorized changes or modification to this system can void the
user's authority to operate this equipment.
Notice regarding disposal (EU only)
If this symbol is shown on the product, manual, battery, or
package, you must dispose of it in the correct manner to avoid
harm to human health or damage to the environment. Contact
your local administrative body for details on the correct dis-
posal method. If the battery contains heavy metals in excess
of the regulated amount, a chemical symbol is displayed
below the symbol on the battery or battery package.
IMPORTANT NOTICE TO CONSUMERS
This product has been manufactured according to strict specifica-
tions and voltage requirements that are applicable in the country
in which it is intended that this product should be used. If you have
purchased this product via the internet, through mail order, and/or
via a telephone sale, you must verify that this product is intended
to be used in the country in which you reside.
WARNING: Use of this product in any country other than that for
which it is intended could be dangerous and could invalidate the
manufacturer's or distributor's warranty.
Please also retain your receipt as proof of purchase otherwise your
product may be disqualified from the manufacturer's or distribu-
tor's warranty.
* All product names and company names are the trademarks or regis-
tered trademarks of their respective owners.
Features on this device
1. MODE button
2.
(Power) button
3. Display
4. Jog Switch
TIP Operate the jog switch by
sliding it in the direction of
the arrow.
1 2 3
5. Ear clip
Attach the device to your ear as
shown in the diagram at right.
Attaching the device
To attach the device to your ear,
5
open the ear clip, place the round
part near the hollow part of your
ear around the earhole, and then
close the ear clip.
the round part can rotate a maxi-
mum of 220 degrees. It will break if
you attempt to rotate it fartherthan
this.
As this a small and light-
weight device, there is a risk
that small children may place
it in their mouth and ingest it.
Keep the device out of reach and
store it away from small children.
Inserting the battery
1. Slide the lid open.
2. Pull the lid
diagonally upwards,
and then insert the
battery.
When inserting or replacing the battery, turn off the device's power.
Make sure to observe the correct polarity.
Turning on the power
1. To turn on the power, hold down the Power button until the dis-
play lights.
2. To turn off the power, hold down the Power button until the display
goes dark.
The display will blink if the battery has worn down.When this happens,
replace the battery as soon as possible.
Using this device
Press the MODE button to switch between the setting screens for
Tempo (
), Beat (
), Rhythm (
), and Volume (
order.
Setting the tempo
1. Press the MODE button to display the Tempo setting screen, and use
the jog switch to set the tempo from q = 30 to 252 (BPM). Slide and
hold the jog switch to make the tempo change in increments of 10.
TIP Set the tempo at around 70 bpm (for men) and 60 bpm (for women).
Start out by practicing your golf swings at this tempo.
Setting the volume
1. Press the MODE button to display the Volume setting screen, and
use the jog switch to set the volume to
(Volume: Low) or
(Volume: High).
If the device seems too loud, fasten it to your ear at a position slightly away
from the earhole.
To protect your hearing, avoid using this device for long periods of time.
Practicing golf swings
Swing the club in time with the device's rhythm.
Swing your club
along with
4
the rhythm!
Beep
Beep
TIP The diagram shows how to time your swing along with the sound.
220°
Adjust the timing according to your own preferences.
When using this device as a metronome, set the beat and rhythm.
Setting the beat and rhythm
1. Press the MODE button to display the Beat or Rhythm setting
screens.
2. Use the jog switch to set the beat and rhythm.
Beat: Select a beat from
(0 beat) to
(9 beat).
Rhythm: Select a rhythm pattern from
(Quarter Notes),
plets),
(Triplets :
,
,
), or
(Quadruplets :
TIP The setting will be remembered, even if you turn off the device.
However, the settings will return to the defaults (
for Beat,
for Rhythm, and
battery are replaced.
Rhythm Pattern List
Display Rhythm Pattern Display Rhythm Pattern
q
Specifications
Tempo: q = 30–252/min (BPM)
) in that
Beat: 0–9 beat
Rhythm: Quarter Notes, Duplets, Triplets, Quadruplets
Tempo accuracy: ±0.1
Speaker: piezoelectric speaker
Power supply: 3V lithium battery CR 2032
Battery life: approximately 200 hours (continuous use at Tempo = 60,
Beat =
, Rhythm =
, Volume =
Dimension (WxDxH): 49 x 22 x 22 mm / 1.93" x 0.87" x 0.87"
Weight: 9 g / 0.32 oz. (including battery)
Included items: Owner's Manual, CR2032 lithium battery (3V), ear pad,
carrying case
* Specifications and appearance are subject to change without notice
for improvement.
Beep
Beep
(Du-
,
,
).
for Tempo,
for Volume) after the
)
