true-i SMART HOME SYSTEM User Manual

Wireless smart home gateway with patents
Hide thumbs
Table of Contents

Advertisement

Quick Links

TRUE-I SMART HOME SYSTEM
USER MANUAL
www.true-i.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMART HOME SYSTEM and is the answer not in the manual?

Questions and answers

Summary of Contents for true-i SMART HOME SYSTEM

  • Page 1 TRUE-I SMART HOME SYSTEM USER MANUAL www.true-i.com...

  • Page 2: Table Of Contents

    3.1 Access Point (AP) mode connection (For changing of user’s wifi setting) ......3 3.2 Internet connection setup ...................... 6 3.3 LED light code ........................7 4. Inclusion of devices at True-i gateway ..........8 4.1 Inclusion of door lock controller module (HMDM-100) ............8 4.2 Inclusion of AC IR Extender ....................9 4.3 Factory reset of IR Extender ....................
  • Page 3 5.15 How to switch IR extender for controlling Aircon and Remocon page ......21 5.16 Learning code for remote control on ‘Remocon’ control page ......... 23 6. Customizing “Coming Home” and “Leaving Home” option ..24 6.1 Customizing “Coming Home” option ................. 24 6.2 Customizing “Leaving Home”...

  • Page 4: Downloading Mobile Application

    True-i User Manual 1. Downloading Mobile Application 1.1 Downloading “TrueEye Smart Home” mobile application on Android 1) Go to “Play Store” to download “TrueEye SmartHome” mobile application. User need to have a google/ gmail account for downloading application from “Play Store”.

  • Page 5: Creating An Account And Registration Of Serial Number

    MUST click “Check ID” to check if ID is available. 4) Choose the user prefer password and confirm the password. 5) Key in the True-i gateway serial number. The user MUST click “Check Serial Number” to check whether the gateway is registered.

  • Page 6: True-I Gateway Connection Type

    3. True-i gateway connection type 3.1 Access Point (AP) mode connection (For changing of user’s wifi setting) 1) “RESET” button for switching to AP mode connection. 2) Micro SD card slot for keeping video recording and firmware upgrading. 3) “STATUS” LED and “POWER” LED for the True-i gateway.
  • Page 7 Once the gateway is in AP mode, look for gateway default SSID to connect. The gateway default SSID is “TrueEyeAP” as shown in the picture. 6) Click “TrueEyeAP” to connect from the user’s mobile phone.  Please take note that “TrueEyeAP” SSID is ONLY allowed to connect to one mobile device each time the user connects.
  • Page 8 10) After connection is successful to “TrueEyeAP” SSID, open “TrueEye Smart Home” mobile application. 11) When the user connects in AP mode, the user does not need to login ID and password. Click “SETTING” page as shown in the picture. 12) Click “SETUP”...

  • Page 9: Internet Connection Setup

    For subsequent setup (if user’s Wi-Fi information is changed) For subsequent setup for changing user’s Wi-Fi information, the user has to put the True-i gateway to be in Access Point (AP) mode first. (See 3.1 Access Point (AP) mode connection for details.)

  • Page 10: Led Light Code

     Please take note that the user can change the Wi-Fi setting ONLY in AP mode. 3.3 LED light code There are two LED lights located on left corner of the gateway. The LED indication is as in the following table. ...

  • Page 11: Inclusion Of Devices At True-I Gateway

    4. Inclusion of devices at True-i gateway 4.1 Inclusion of door lock controller module (HMDM-100) 1) Remove the cover to insert the door lock controller module (HMDM-100). 2) Insert the door lock module accordingly to the connection. Note: Ensure that the device is within 1 meter from the True-i gateway for inclusion.

  • Page 12: Inclusion Of Ac Ir Extender

    4) User can also use USB power cable to power the IR extender instead of using batteries. Note: Ensure that the device is within 1 meter from the True-i gateway for inclusion. Note: Please use Wi-Fi connection during inclusion 5) Open “TrueEye Smart Home” mobile application and click on “Setting”...

  • Page 13: Factory Reset Of Ir Extender

    9) This portion of IR extender is for transmitting signal. 10) This portion of IR extender is for receiving signal while adding/ inclusion of device or learning the code from mobile application. It is also known as “Program” button. 4.3 Factory reset of IR Extender Press and hold “Program”...

  • Page 14: Inclusion Of Door/ Window Contact Sensor

    2) Put CR123A Lithium battery into the battery compartment. Note: Ensure that the device is within 1 meter from the True-i gateway for inclusion. Note: Please use Wi-Fi connection during inclusion 3) Open “TrueEye Smart Home” mobile application and click on “Setting”...

  • Page 15: Inclusion Of Pir Motion Sensor

    2) Put CR123A Lithium battery into the battery compartment. Note: Ensure that the device is within 1 meter from the True-i gateway for inclusion. Note: Please use Wi-Fi connection during inclusion 3) Open “TrueEye Smart Home” mobile application and click on “Setting”...

  • Page 16: Inclusion Of Smart Plug

    1) Connect the smart plug to AC power outlet. Note: Ensure that the device is within 1 meter from the True-i gateway for inclusion. Note: Please use Wi-Fi connection during inclusion 2) Open “TrueEye Smart Home” mobile application and click on “Setting”...

  • Page 17: Navigating True-I Mobile Application

    5. Navigating True-i mobile application 5.1 Home page When the “Home” button is pressed, user can see the True-i “Home page” of the mobile application. Controls: Main control panel for viewing of different smart home devices. To access individual devices, click the “CONTROLS” icon.

  • Page 18: Customize Page

    5.3 Customize page To activate “Coming Home” or “Leaving Home” function to be used at the “Home page”. Click the activate button and test on the defined setting. 5.4 Scene page The user can set certain motion to activate specified actions. (E.g. closing the door will off the lights.) ...

  • Page 19: Setting Page

    5.5 Setting page 1) For device(s) addition/ inclusion, click “ADD” button. 2) To remove/ excluding the device(s), click “REMOVE” button. 3) Association of devices (used by installers) 4) For device(s) that user does not use for a certain time, the user can put device(s) under “UNREACHABLE DEVICE”...

  • Page 20: Control Page

    5.6 Control page User can save the frequently used icon under “Favourite” page at the upper right corner of “My Controls” page. The user can control the devices according to the options. The user can access these devices in the control page: ...

  • Page 21: Door Lock Control Page

    5.8 Door lock control page To “LOCK” or “UNLOCK”, click “LOCK” or “UNLOCK” button respectively. To check status of connected door lock see the padlock icon.  ‘Grey’ means connected with “ON” or “OFF” position.  ‘Orange with exclamation’ sign means not connected. To rename the door lock, press and hold the text area, the text box will pop up, user will then be able to change the preferred name.

  • Page 22: Ip Camera Page

     To learn about the air- con codes, click the learn code button. 5.12 Remocon control page To use smart phone as a remote control via True-i gateway, click the “REMOCON” icon on the control page. The user will see “Remocon control” page as shown in the figure.

  • Page 23: Curtain Control Page

    5.13 Curtain control page  Click “CLOSE” button to close the curtain.  Click “OPEN” button to open the curtain.  Click “FULL CLOSE” button to completely close the curtain.  Click “FULL OPEN” button to completely open the curtain. ...

  • Page 24: How To Switch Ir Extender For Controlling Aircon And Remocon Page

    5.15 How to switch IR extender for controlling Aircon and Remocon page As a default, IR extender device will be able to see in “Aircon” control page. 1) Click this icon for selection of included IR extender devices. If the user has more than one IR extender, the user has to choose the respective IR extender from this menu for controlling the device.
  • Page 25 6) As a default, there is no IR extender will be seen as shown in the picture. 7) Click this icon for selection of IR extender devices that is switched to ‘Remocon’ control page. 8) Click “Remote” icon for switching IR extender from ‘Remocon’...

  • Page 26: Learning Code For Remote Control On 'Remocon' Control Page

    5.16 Learning code for remote control on ‘Remocon’ control page To do learning code for remote control, the user has to go to ‘Remocon’ control page under “CONTROLS” option from the ‘Home’ page. Please ensure that the device (e.g; Television or fan) should be turned “ON”...

  • Page 27: Customizing "Coming Home" And "Leaving Home" Option

    6. Customizing “Coming Home” and “Leaving Home” option 6.1 Customizing “Coming Home” option “Coming Home” and “Leaving Home” options can be customized under “CUSTOMIZE” page as shown in red circle. After customization is done, the user can click to activate the “Coming Home”...
  • Page 28 5) Click door “unlock” icon according to this example. 6) Click the icon to choose for selecting the second option for this example. 7) Choose “Switch @ node 52” in this example. 8) Click “Done” button after selection. 9) Click “ON” button according to this example. 10) Click “Save”...

  • Page 29: Customizing "Leaving Home" Option

    6.2 Customizing “Leaving Home” option “Coming Home” and “Leaving Home” options can be customized under “CUSTOMIZE” page as shown in red circle. After customization is done, the user can click to activate the “Coming Home” and “Leaving Home” buttons at “Home page” of the “TrueEye Smart Home”...
  • Page 30 15) Click door “lock” icon according to this example. 16) Click the icon to choose for selecting the second option for this example. 17) Choose “Switch @ node 52” in this example. 18) Click “Done” button after selection. 19) Click “OFF” button according to this example. 20) Click “Save”...

  • Page 31: How To Configure "Scene" Page

    7. How to configure “Scene” page 7.1 Configuration in Android mobile application “Scene” page is mainly for allowing the users to create simple conditional statements. This option is also known as IFTTT (“If This Then That”) option. 1) Click “+” sign, for new “Scene” configuration. 2) There will be a pop up box to enter new “Scene”...
  • Page 32 In this scenario, if the door contact sensor node is triggered (door is opened), the light switches will be “ON”. 5) Choose “Binary Sensor @ node 6” which is door contact sensor in this scenario. 6) Click “ON” for opening the door. If the user is triggering for closing position of the door, the user has to choose “OFF”.
  • Page 33 10) As a default add in, the “Switch” is in “OFF” position. According to the example scenario, the Switch should be in “ON” position. 11) Click the button to choose for the third sequence to follow. 12) In this scenario, “Multiswitch-1 @ node 3” will be chosen. The user can choose any node for the desired option.
  • Page 34 15) In this scenario, “Multiswitch-2 @ node 3” will be chosen. The user can choose any node for the desired option. 16) Click the chosen “Multiswitch-2 @ node 3” in “ON” position. 17) Click the button to choose for the fifth sequence to follow. 18) In this scenario, “Switch @ node 31”...
  • Page 35 19) Click the chosen “Switch @ node 31” in “ON” position according to the example. 20) Click “Save” icon for saving the conditional statement set by the user. 21) The user has to click “ACTIVATE” for the “Scene” that the user has just created for the conditional sequence to follow.

  • Page 36: Configuration In Apple Ios Mobile Application

    7.2 Configuration in Apple iOS mobile application “Scene” page is mainly for allowing the users to create simple conditional statements. This option is also known as IFTTT (“If This Then That”) option. 21) Click “+” sign, for new “Scene” configuration. 22) There will be a pop up box to enter new “Scene”...
  • Page 37 In this scenario, if the door lock is triggered (door is unlocked), the smart plug will be “ON” after 5 seconds delay. 25) Scroll and choose “Doorlock @ node 48” which is door contact sensor in this scenario. 26) Click “Done” button after selection. 27) Click “unlock”...
  • Page 38 32) The user can put delay up to 10 seconds. 33) Click the button to choose for the third sequence to follow (e.g.; after unlocking the door, the smart plug will be “ON”). 34) In this scenario, “Switch @ node 52” will be chosen for the third sequence.
  • Page 39 38) As a default, this button will be grey off and the conditional statement will not be activated until the user press “ACTIVATE” button. 39) The user has to click “ACTIVATE” for the “Scene” that the user has just created for the conditional sequence to follow. This example shows that when the door is unlocked, the smart plug will be switched “ON”...

  • Page 40: Manging User Account

    8. Manging user account 8.1 Changing password 1) Click “FORGOT/ CHANGE PASSWORD” if the user forgot the password. 2) Type “Registered ID” that you have use it before. 3) Type Gateway Serial No. (without dash “-”) 4) Type “Registered email” that the user have used to register for gateway.
