[ Applicable Tire Size ]
24-inch ~ 700 x 45c
(Max tire outer diameter 726mm)
To use 26x1.0" or smaller tire, you need
the optional Small Wheel Adapter
Read this instructions manual carefully before use
Minoura Japan Headquarters
(for all customers)
1197-1 Godo, Anpachi, Gifu 503-2305 Japan
Phone: +81-584-27-3131 / Fax: +81-584-27-7505
Email: minoura@minoura.jp / www.minoura.jp
(ETRTO 47-622)
Made in Japan
instructions manual
(Shown image: non-remote MagRide60-D)
Minoura North American Tech Center
(for U.S. residents only)
Hayward, California, U.S.A.
Phone: 1-510-538-8599 / Fax: 1-510-538-5899
Email: support@minourausa.com
(ver.1.0 2016/7)
Advertisement
Table of Contents
Summary of Contents for MINOURA MAGRIDE-60
- Page 1 Small Wheel Adapter (Shown image: non-remote MagRide60-D) Read this instructions manual carefully before use Minoura Japan Headquarters Minoura North American Tech Center (for all customers) (for U.S. residents only) 1197-1 Godo, Anpachi, Gifu 503-2305 Japan Hayward, California, U.S.A.
- Page 2 Any damage or problem caused by transporting process is not covered under warranty. You should ask to the shipping company for solutions. Read enclosed "Minoura Limited Warranty Policy" card and refer our web site (www.minoura.jp) for more detail. - 2 -...
-
Page 3: Required Tools
Replace your rear wheel quick release skewer with the supplied one. Minoura guarantees the stability only when using the supplied skewer due to the coupling inner shape. If your bike is not equipped with quick release skewer and it's a hub nut type, you should remove the black plastic Grommet (skewer nut protector) from the right side coupling. - Page 4 Wheel Position Adjust Knob Place your rear wheel in between the couplings. Right Side Coupling 1) Turn the hub handle counter-clockwise Hub Handle to make the enough space between the couplings. You should almost fully open the coupling Left Side Coupling for easier wheel installation.
- Page 5 Contact the Drive Roller to the rear tire by turning the Roller Pressure Adjust Knob clockwise. (see Fig. G) The best position is that the roller compresses the tire in the depth of 3 – 4 mm. (see Fig. H) Please note: Too much or too little pressure will result in premature tire wear.
- Page 6 How To Adjust Resistance Level (MagRide60-D) MagRide60-D provides 3 different resistance levels to suit your training level. To Increase Resistance Level: Slide the Dial Lever toward "H" position. To Decrease Resistance Level: Slide the Dial Lever toward "L" position. (Fig. L) How To Adjust Resistance Level (MagRide60-R) Required Tool: 1 x M4 Hex Wrench MagRide60-R comes with a convenient remote shifter device.
- Page 7 Why Doesn't My Remote Shifter Work Correctly? If setting the remote in the L or H position becomes difficult, it may be due to the inner cable having too much slack. To fix this problem, follow the steps to adjust the initial cable tension.
