N-Com BX5 User Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

EN
USER INSTRUCTIONS AND SAFETY
Congratulations on your purchase of an N-Com product.
N-Com BX5 was made using the most advanced technologies and the best materials.
Long-running tests and thorough system development have allowed the highest audio
quality to be achieved.
For additional information about BX5, and to download high-definition instructions as well
as the latest Firmware version, visit the website www.n-com.it
Firmware Version: 1.0x
REFERENCE STANDARDS
The products of the N-Com line are in compliance with standards as per the table below:
BX5
Battery
charger
Battery
The Declarations of Compliance can be downloaded from the website www.n-com.it
(Download section).
FccID: Y6MNCOM10
Bluetooth is a registered trademark property of Bluetooth SIG, Inc.
The Bluetooth system complies with the main safety requirements
and other applicable provisions of Directive 99/5/CE, Directive
2009/65/EC, Directive 2011/65/CE, Directive 2012/19/EU
Directive 2006/95, 2004/108, 2009/65/EC, 2011/65/CE, 2012/19/EU,
2009/125/CE
Directive 2006/66/CE
IC: 9455A-NCOM10
Bx5
R-NZ
BX5 - 27/04/2016 12:08:00
