Soltec SS-750L User Manual

Ups + avr line-interactive sine wave
Hide thumbs
Table of Contents

Advertisement

Quick Links

UPS + AVR
Uninterruptible Power System
User's Manual
Line-Interactive Sine Wave
(Long backup models: SS-750L/1000L/1500L/2000L)
LOAD
100%
80%
60%
40%
20%
－ － － － － － － －
BATTERY
＋ ＋ ＋ ＋ － － － －
NORMAL
BACK UP
LOW BATT.
OVER LOAD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS-750L and is the answer not in the manual?

Questions and answers

Summary of Contents for Soltec SS-750L

  • Page 1 UPS + AVR Uninterruptible Power System User’s Manual Line-Interactive Sine Wave (Long backup models: SS-750L/1000L/1500L/2000L) 100% － － － － － － － － LOAD BATTERY ＋ ＋ ＋ ＋ － － － － NORMAL BACK UP LOW BATT. OVER LOAD...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS For Long run models: SS-750L/1000L/1500L/2000L only ------------- Page 3 – 4 INTRODUCTION Overview 1.2 Battery replacement warning Communication interface MAIN FEATURES ------------------------------------------------------ Page 5 CAUTION ----------------------------------------------------------------- Page 5 INSTALLATION AND OPERATION ------------------------------- Page 6 Installation Operation Connecting the FAX machine INDICATION AND CONTROL --------------------------------------- Page 7 –...
  • Page 3 FRONT PANEL FOR ALL MODELS 100% － － － － － － － － LOAD BATTERY ＋ ＋ ＋ ＋ － － － － NORMAL BACK UP LOW BATT. OVER LOAD LEDs of battery voltage level and load level. LED of operation status. Control button.

  • Page 4: For Long Run Models: Ss-750L/1000L/1500L/2000L Only

    For long run models: SS-750L/1000L/1500L/2000L only Rear Panel NEMA Type IEC Type － － － － Fuse. Inlet of city power. Outlets (NEMA/IEC). RS-232 Interface. DIP switch Phone jacks for fax machine (optional by DIP switch). Battery connector. 3DJH  RI ...

  • Page 5: Introduction

    INTRODUCTION (for long run models: SS-750L/1000L/1500L/2000L only) Overview: The series UPS is an advanced Line-Interactive Uninterruptible Power System which produces pure sine wave power to your equipment; unlike the traditional off-line UPS, the series provide very short transference when blackouts happen, and zero transference from AC mode to battery mode or from battery mode to AC mode.

  • Page 6: Main Features

    MAIN FEATURE: Line-Interactive structure. Microprocessor based design. ‘Green Power’ design with auto on/off function. RS-232 interface for communication. Protection for overload, short circuit, & over heat. Pure sine wave output. Zero Transference. CAUTION: The UPS is designed to power computer loads and the associated peripheral devices, such as monitors, modems, external H-Disk drivers, etc.

  • Page 7: Installation And Operation

    INSTALLATION & OPERATION: Installation Inspecting the packing carton for damage that may have occurred while in transit. Immediately notify the carrier and place of purchase if any damage is found. Retain the package for future use. Plugging the power cord to a 3-wire grounding receptacle. If an extension cord must be used between the UPS and the nearest wall outlet, use a 3-wire grounding type rated for at least 20 Amps.

  • Page 8: Indication And Control

    INDICATION AND CONTROL Battery level and load level LEDs The battery level LEDs show the voltage level both in back-up mode and in normal mode. When the LED indicates 20% of the capacity in back-up mode, it means that the UPS is going to shut down; for the length of backup time left, it will depend on the load.

  • Page 9: Dip Switch Settings

    DIP Switch Setting DIP Switch Function Table of DIP Switch Switch No. Function Down Down Down Down Voltage = 100V / 200V Voltage = 110V / 220V Voltage = 115V / 230V Voltage = 120V / 240V Frequency for DC Start 50Hz 60Hz Green Power...

  • Page 10: Communication Interface

    COMMUNICATION INTERFACE: The UPS provides both computer interfaces, smart software (RS-232) and dry contact (DB-9); by using different software and cable, the UPS shows different monitoring function. The definition and setup for RS-232 is as following: Baud Rate : 2400 dps Data Length : 8 bits Stop Bit : 1 bit...

  • Page 11: Trouble Shooting

    7. TROUBLE SHOOTING Problem Possible Cause Action to Take UPS no reaction while AC is 1. Line cord plug is loose 1. Check the line cord plug connected 2. Fuse on rear panel blown 2. Replace fuse (Inside the drawer of inlet) 3.

  • Page 12: Specifications

    8. SPECIFICATIONS: Specifications for long run models SS-750L/1000L/1500L/2000L: SS-750L SS-1000L SS-1500L SS-2000L MODEL / CAPACITY (750VA) (1000VA) (1500VA) (2000VA) Continuous Loading 500W 700W 900W 1200W Max. Loading 750W 1000W 1500W 2000W (< 30sec.) (< 30 sec.) (< 30 sec.) (< 30 sec.) INPUT Voltage Frequency Selectable 100/110/115/120V 1ø...

  • Page 13: Important Safety Instructions

    9. IMPORTANT SAFETY INSTRUCTIONS When replacing the batteries, use the same number and the same type of batteries. Do not dispose of batteries in a fire; the battery may explode. Do not open or mutilate the battery or batteries, released electrolyte is harmful to the skin and eyes. A battery can present a risk of electric shock and high short circuit current.
