Contents About this Guide ..............3 WEEE Notice ................ 3 CE Regulatory Notice ............3 Notes on Installation ............. 4 Caution ................. 4 Introduction ..............5 Features ..............5 Package Contents ............. 5 Product Overview ............6 Remote Control ............7 Getting Started .............. - Page 3 3.1.1 Record videos while driving ......14 3.1.2 Record all other types of videos ....14 3.1.3 Emergency Recording ........15 3.1.4 The Recording Screen ........16 3.1.5 Taking Snapshot ........... 17 Playback Videos and Photos ........18 3.2.1 Playing Videos ..........19 3.2.2 Viewing Photos ..........
-
Page 4: About This Guide
About this Guide The content in this document is for information purpose and is subject to change without prior notice. We made every effort to ensure that this User Guide is accurate and complete. However, no liability is assumed for any errors and omissions that may have occurred. -
Page 5: Notes On Installation
Notes on Installation Install the device near the rear-view mirror to obtain the best open-field view. Make sure that the lens is within the wiping range of the windscreen wiper to ensure a clear view even when it rains. Do not touch the lens with your fingers. Finger grease may be left on the lens and will result in unclear videos or snapshots. -
Page 6: Introduction
1 Introduction Thank you for purchasing this advanced Car Recorder. This device is specifically designed for real time video and audio recording when driving. 1.1 Features • Full HD camera (1920x1080 @ 30fps) • 2.4” LCD color screen • Wide angle lens •... -
Page 7: Product Overview
1.3 Product Overview Front View Top and Bottom Views Side (Left and Right) Views Rear View Item Item Bracket Socket LED Light Microphone LCD Panel Power Button Up Button ( Memory Card Slot Down Button ( USB Connector Enter Button ( HD Connector Wide Angle Lens Back Button (... -
Page 8: Remote Control
1.4 Remote Control Description Press to take a Photo ( ). (Take snapshots during recording.) Press to enter the menu or return to previous screen. Similar function as Back Button ( Press to move up. Similar function as Up Button ( Press to confirm selection. -
Page 9: Getting Started
2 Getting Started 2.1 Inserting the Memory Card Insert the memory card with the gold contacts facing the back of the device. Push the memory card until it clicks into place. To remove the memory card Push to eject the memory card out of the slot. Note: 1. -
Page 10: Installing In Vehicles
2.2 Installing in Vehicles 2.2.1 Mount to Windshield Attach the bracket to the device. Slide it into the bracket holder until you hear a click. With the suction-cup laying flat, position the suction-cup on the windshield. Hold the base firmly windshield and press down the clamp to mount the car holder to the windshield. -
Page 11: Adjust The Device Position
2.2.2 Adjust the device position Loose the knob to swivel the device vertically. Knob Loose the knob to swivel the device horizontally up to 360°. Knob Then tighten the knob to make sure the device is securely locked in place. -
Page 12: Connecting To Power
2.3 Connecting to Power Use only the supplied car adapter to power up the device and charge the built-in battery. Connect one end of the car adapter to the USB connector of the device. Plug the other end of the car charger to the cigarette lighter socket of your vehicle. -
Page 13: Powering The Device On / Off
2.4 Powering the Device On / Off 2.4.1 Auto Power On/Off Once the vehicle engine is started, the device automatically turns on. If the Automatic Record function is enabled, the recording will automatically start right after the device turns on. See Set Automatic Recording (2.5.1). -
Page 14: Initial Settings
2.5 Initial Settings Before using the device, we recommend you to enable the Automatic Record function and set up the correct date and time. 2.5.1 Set Automatic Recording To enable the recording to start automatically after you turn on the power, do the following: Press the button to enter the OSD menu. -
Page 15: Using The Car Recorder
3 Using the Car Recorder 3.1 Recording Videos 3.1.1 Record videos while driving When the vehicle engine starts up and the Automatic Record function is enabled, the device automatically turns on and starts recording. Recording will automatically stop when the engine is switched off. Or, press the button to stop recording manually. -
Page 16: Emergency Recording
3.1.3 Emergency Recording During Video Recording, press the button to enter emergency recording mode, the “Emergency” message will be shown immediately on the upper left corner of the screen, and the recorded file will be protected. To stop the recording, press the button. -
Page 17: The Recording Screen
3.1.4 The Recording Screen Description Item Indicates the recording duration. Duration Indicates the current recording date and time. Date and time Guide icon Press the button to enter the OSD menu. (Menu) Guide icon Press the button to switch to Playback mode. (Playback) Indicates the video resolution. -
Page 18: Taking Snapshot
The results of GPS positioning are only for reference, and should not affect the actual driving situation. The system also cannot ensure the positioning accuracy. GPS positioning accuracy may differ depending on weather and location such as high buildings, tunnels, undergrounds, or forests. -
Page 19: Playback Videos And Photos
3.2 Playback Videos and Photos If recording is in progress, press the button to stop recording. The standby screen is displayed. Press the button to enter the OSD menu. Press the button to select the file category that you want to browse and press the button. -
Page 20: Playing Videos
3.2.1 Playing Videos To play videos, do the following: If recording is in progress, press the button to stop recording. Press the button to enter the OSD menu. Press the button to select File Playback and press the button. Press the button to select Video or Emergency and press the button. -
Page 21: The Playback Screen
3.2.3 The Playback Screen Video Playback Screen Photo Playback Screen Description Item Date and time Indicates the recorded date and time. Press the button to return to file selection Guide icon display. (Back) Press the button to view the previous Guide icon video/photo. -
Page 22: Deleting Files
3.2.4 Deleting Files To delete file(s), do the following: If recording is in progress, press the button to stop recording. Press the button to enter the OSD menu. Press the button to select File Deletion and press the button. Press the button to select the file category and press the button. -
Page 23: Adjusting The Settings
4 Adjusting the Settings 4.1 Using the Menu You can customize the video recording and other general settings via the on-screen display (OSD) menus. If recording is in progress, press the button to stop recording. Press the button to open the OSD menu. Press the button to select a menu option and press the button to enter the selected menu. -
Page 24: Menu Tree
4.2 Menu Tree Refer to the below table for details on menu items and available menu options. Menu option Description Available option Select the file category Video / Emergency / File Playback that you want to view. Picture Displays the current state Satellite Status of the satellite reception. - Page 25 Menu option Description Available option Enable / Disable the Automatic device to automatically On / Off Record record video after the device is turned on. Set the recording duration Record Interval for each recorded video 3 min. / 5 min. file.
- Page 26 Menu option Description Available option and a warning message is displayed on the screen. English / Deutsch / Français / Español / Italiano / Português / Set the on-screen display Language Polski / Čeština / menu language. Nederlands / Ελλάδα / Dansk / Norsk / Svenska / Magyar Video / Emergency /...
-
Page 27: Installing The Software
5 Installing the Software 1. Place the attached CD ROM into the CD player. 2. If the CD does not execute automatically, please use Windows File Manager to execute the Install_CD.exe file in the CD. The following screen will be shown up. 3. -
Page 28: Supercar
6 SuperCar Item Item Video Player File Path Play / Pause Browser File Previous File List Next File Name Stop Volume Current Duration / Total Google Map Duration Compass Signal Noise Ratio (SNR) Speed Meter G-Sensor Note: 1. To display the route on Google Maps, please make sure the internet is connected before starting the video playback 2. -
Page 29: Specifications
Specifications Item Description Image sensor 1/3” CMOS sensor 2304 (H) x 1536 (V) Effective pixels Support Micro SDHC up to 32GB (Suggest to use a Storage media Class 6 memory card with at least 8GB capacity) LCD display 2.4” LCD color TFT (112K pixels) Wide Angle Fixed Focus lens Lens F2.4, f=3.0mm... - Page 30 Item Description Battery Built-in 470mAH Li-polymer rechargeable Operating 0° ~ 50° C Temperature Operating 20 ~ 70% RH Humidity Storage -20° ~ 80° C Temperature Dimensions 63 x 70 x 28.7 mm Weight Approx. 94g...
-
Page 31: Conformity
Conformity The Manufacturer hereby declares that the CE marking was applied to the Rollei CarDVR-110 in accordance with the basic requirements and other relevant provisions of the following CE Directives: 2011/65/EC RoHs Directive 2004/108/EC Low Voltage Directive 1999/5/EG R&TTE Directive... -
Page 32: License Statement
In this instance your e-mail must contain details of what the relevant product is, the relevant serial number and documentary evidence of...
