  • Page 1 User Manual WIRELESS HEADSET MF620...

  • Page 2: Turning On/Off

    What’s in the box? Bluetooth Headset Ear Hook AC Adapter Ear Rubber User manual Getting to know the MF620 Indication LED Ear Rubber Multi-Function Button Volume Button Charging port Microphone Speaker Using your Headset TURNING ON/ OFF Turning On : Press the Multi-Function button for 2 seconds.

  • Page 3: Charge The Battery

    2 sec. 4 sec. Turning Off Turning On CHARGE THE BATTERY Before using your headset, charge the battery completely. Connect an adapter to the charging port of the headset and plug it into home power outlet. The Red LED remains on while the headset is charging and LED turns off when charging is completed.

  • Page 4: Proximity Pairing

    PIN code is “0000” .(4 zeros) Active Dev List Input PIN Code Model Name MF620 0000 SIMPLE PAIRING: If your mobile phone supports Bluetooth version spec 2.1, you don’t need to put PIN code to pair. (This function is only available when your mobile phone supports Bluetooth version 2.1)

  • Page 5: Making A Call

    EASY PAIRING : The headset goes into pairing (proximity pairing) mode automatically the first time you use it. MAKING A CALL 1. Last call-Redialing : Press the Multi-Function button. 2. Voice Dialing : Press the Multi-Function button for 2 seconds, then voice dialing is activated.

  • Page 6: Transferring A Call

    TRANSFERRING A CALL To transfer a call from headset to your mobile phone and vice versa, press the Multi-Function button on headset during the call for 2 seconds. ADJUSTING A VOLUME There are 6 volume levels that cycle as you press the Volume button. When the highest level is reached, you can hear the beep.
  • Page 7 MULTIPOINT : Using the Headset with two phones [NOTE] Some mobile phones are not available for Multipoint. 1. Multi-point Connect Set the headset into pairing mode first. After then search headset from each mobile phones at the same time. Please connect first mobile phone. Once the connection is completed, please connect the second mobile phones.

  • Page 8: Resetting The Headset

    RESETTING THE Headset Press and hold Multi-Function button and volume button simultaneously for 4 seconds then all information in headset will be deleted. [NOTE] Resetting is only possible when standby mode after disconnecting with your mobile phone. Status indication Status LED indication Alarm or Voice announcement Power on...

  • Page 9: Specifications

    Specifications Model Name MF620 Bluetooth Core Spec Bluetooth Specification 3.0 Profile HSP/HFP 1.5 Carrier Frequency 2402 MHz to 2480 MHz Modulation Method GFSK, 1Mbps, 0.5BT Gaussian Maximum Data Rate Asynchronous : 723.2 kbps / 57.6 kbps Synchronous : 433.9 kbps / 433.9 kbps...

  • Page 10: Safety And General Information

    SAFETY AND GENERAL INFORMATION 1. Please read this guidebook carefully and follow the instruction. 2. To avoid any damage or malfunction of the unit, do not drop it from high place. 3. Keep away unit from humidity, water and any other liquid. And if the unit is exposed by water, moisture and other liquid directly, then do not operate it normally to avoid any electrical shock, explosion and damage of the unit.

  • Page 11: Fcc Notice

    instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver.

  • Page 12: Warranty

    This product is CE marked according to the provision of the R&TTE Directive (99/5/EC). Here by MOVON Corporation, declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Please note that this product uses radio frequency bands not harmonized within EU.

  • Page 13: Weee Symbol Information

    WEEE SYMBOL INFORMATION Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
