Before using the device please read this user manual accurately.
Accessories: FMT300BT, Remote control for the steering wheel, Remote control for
manual mode, Audio cable 3.5 to 2.5 jack, Earphones, Fuse, User Manual
FMT300BT Feature
1. MP3 FM-Transmitter and Bluetooth hands-free talking for the car, compatible
with nearly all Bluetooth mobile phones.
2. CVC-technology for clearly speaking (restrain noise & echo).
3. Excellent sound quality with full Duplex Communication.
4. Priority: Bluetooth call
5. Plays music from mobile phone via Bluetooth.
6. Mute function (music) for enjoyable speaking comfort.
7. Re-dial function* & voice-dial function* (* depend on mobile phone functions).
8. Automatically bluetooth connection (after first adjustment).
9. Equalizer-mode & Repeat-mode.
10. Function for folder and file selection.
11. Steering wheel remote control – and hand remote control.
12. Flexible, rotatable axis of device easily operated.
Technical Parameters
Bluetooth interface:
Bluetooth frequency range:
Supported Bluetooth profiles:
FM-transmitting frequency:
Operating voltage range:
Charger output range:
Microphone:
Supported memory format:
Display:
Supported Audio In / Audio Out:
DSP
(Digital Signal Processing)
FMT300BT User Manual
Bluetooth music
technology: Echo elimination
Line-in
Version 2.1, Class 2
2.402 ~ 2.480 GHz
HSHF, Headset, A2DP
88.1 ~ 107.9 MHz
DC 12V ~ 24V (car cigarette lighter socket)
5V DC, 1.5A
Integrated with noise elimination
SD / SDHC / MMC / USB
LCD display with blue light
2,5 mm
Background noise reduction
1
SD / USB.
Advertisement
Summary of Contents for Technaxx FMT300BT
- Page 1 FMT300BT User Manual Before using the device please read this user manual accurately. Accessories: FMT300BT, Remote control for the steering wheel, Remote control for manual mode, Audio cable 3.5 to 2.5 jack, Earphones, Fuse, User Manual FMT300BT Feature 1. MP3 FM-Transmitter and Bluetooth hands-free talking for the car, compatible with nearly all Bluetooth mobile phones.
- Page 2 Bluetooth Function Operations (Pairing the device with a Bluetooth enabled mobile phone) 1. First set the FMT300BT (without memory card / without USB flash drive) in ON status. 2. Press PLAY button for a longer time (at the unit directly or at the remote control) until screen display shows “PAIRING”...
- Page 3 Operations at the FMT300BT Play Play music under “Playing mode” Press once to answer a call under Answer a call “Speaking” mode PLAY (►) Press and hold for min. 3 seconds Pairing “PAIRING” appears at the display Stop to play music under “Playing” mode Stop Press short under “Playing”...
- Page 4 Re-dialing last No. Press long under “Playing” mode to re-dial the last outgoing call-No. (working End or reject a call Press long under “Speaking” mode to when FMT300BT is end or reject a call connected to a Transfer a call Press once under “Speaking”...
- Page 5 Operations at the 21 button Hand Remote Control Press short to enter into the FM-channel Enter frequency adjusting mode adjusting mode (Channel Modulate) Press short under “Playing” mode to Change EQ-mode change the EQ-mode from NORMAL ROCK CLASSIC LIVE EQ / Change Repeating Press long under “Playing”...
- Page 6 End or reject a call Press long under “Speaking” mode to connected to a end or reject a call Bluetooth enabled mobile phone) Press once under “Speaking” mode to Transfer a call transfer a call to a mobile phone FMT300BT in a car FMT300BT close view...
- Page 7 2) Remove the battery. 3) Insert the replacement battery. Keep attention on the direction of the correct polarization (+/-). 4) Put the cover back to the battery compartment. ICONs on the FMT300BT Display Progress Indicator File Name Folder Name Memory Type...
- Page 8 Different status shown on the FMT300BT display FMT300BT is powerd ON Audio-In connected Pairing with Bluetooth devices Pairing is succussful completed Bluetooth enabled (connected) FM frequency FM frequency Bluetooth enabled (connected) Audio-In connected Playing music from USB drive...
- Page 9 Playing music from SD card Adjusting volume Changing music track Adjusting FM frequency Music is paused Switching EQ mode Switching REPEAT mode...
- Page 10 Changing folder Pressing CH button Typing music track No. Voice dailing (depends on the voice dailing function of the mobile phone) Playing music from a mobile phone over the Bluetooth connection...
- Page 11 Important Notice 1. Use at voltage DC 12-24V ONLY! Other voltage could affect the accurate work of the device or – in worst case – damage of the device. 2. When starting the car engine – DO NOT insert the device to the car- cigarette-lighter socket.
-
Page 12: Important Notice
Security and Disposal Hints for Batteries • Hold children off batteries. When a child swallowed a battery by mistake go to a doctors place or bring the child into a hospital promtly! • Never short batteries. • Look for the right polarity ( ) and (▬) of batteries! Always change all batteries, never use old and new batteries or batteries of different typs together.
