  • Page 3 This product incorporates copyright protection technology that is protected by method claims of certain U.S. pat- ents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home or other limited viewing uses only unless otherwise authorized by Macrovision Corporation.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.

  • Page 8: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply. If you are unsure of your local power specifications, consult Warning your service representative or local power company.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 11: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
  • Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.

  • Page 14: Lcd Screen Care

    Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...

  • Page 15: Table Of Contents

    Preface Contents Notice .................I System Map: Right View ..........1-11 FCC Statement .............II System Map: Left View ..........1-12 Instructions for Care and Operation ......IV System Map: Bottom View ..........1-13 Power Safety .............. VI Windows Vista Start Menu & Control Panel ....1-14 Battery Precautions ...........VII Video Features .............1-15 Cleaning ..............
  • Page 16 Preface Drivers & Utilities USB Printer ...............2-12 Install Instructions: ...........2-12 What to Install ..............4-1 Parallel Printer ............2-12 Module Driver Installation ..........4-1 Intel Turbo Memory Module ........4-1 Power Management Driver Installation ............4-2 Overview ................3-1 Updating/Reinstalling Individual Drivers ....4-3 The Power Sources ............3-2 User Account Control (Win Vista) ......4-4 AC/DC Adapter ............3-2 Windows Security Message .........4-4...
  • Page 17 Preface Intel Turbo Memory Technology .......4-6 Battery Low Alarm Beep: (Advanced Menu) ....5-10 Security Menu ..............5-11 BIOS Utilities Set Supervisor Password (Security Menu) ....5-11 Password on boot: (Security Menu) ......5-12 Overview ................5-1 Fixed disk boot sector: (Security Menu) ......5-12 The Power-On Self Test (POST) ........5-2 Boot Menu ..............5-13 Failing the POST ............5-3 Exit Menu ..............5-14...
  • Page 18 Preface Bluetooth Driver Installation ........7-7 Problems & Possible Solutions ........8-7 Connecting to Bluetooth Devices .......7-8 Screen Resolution Error ..........8-11 PC Camera Module ............7-11 Interface (Ports & Jacks) PC Camera Driver Installation .........7-12 PC Camera Audio Setup ...........7-13 Overview ...............A-1 BisonCap for 1.3M pixel camera module ....7-15 Ports and Jacks ..............A-2 VideoView (for 2.0M pixel camera module) ...7-17 Card Reader ..............A-2...
  • Page 19 Preface Nvidia Video Driver Controls Environmental Spec ............C-5 Physical Dimensions & Weight ........C-5 NVIDIA Video Driver Installation ....... B-1 Optional ................ C-6 NVIDIA Control Panel ..........B-2 Attaching Other Displays ..........B-5 Windows XP Information Display Modes .............. B-7 DVD Regional Codes ...........D-2 Enabling TV Display ..........
  • Page 20 Preface Battery Life ..............D-17 User Enrollment ............D-41 Recharging the Battery with the AC/DC Adapter ..D-18 USB TV Tuner Module ..........D-43 Proper handling of the Battery Pack ......D-19 Consumer Infrared Remote Control Unit Driver ..D-43 Battery FAQ..............D-20 TV Tuner Driver Installation ........D-43 Driver Installation ............

  • Page 21: Quick Start Guide

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 22: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...

  • Page 23: Model Differences

    Quick Start Guide Model Differences This notebook series includes two different design types, however only one design is pictured in this manual. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the appropriate drivers.

  • Page 24: System Software

    Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the following operating systems are sup- ported: Operating System &...

  • Page 25: System Startup

    Quick Start Guide System Startup 1. Remove all packing materials. Shutdown 2. Place the computer on a stable surface. 3. Securely attach any peripherals you want to use with the notebook (e.g. keyboard Note that you should and mouse) to their ports. always shut your com- 4.

  • Page 26: System Map: Lcd Panel Open

    Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open 1. Optional Built-In PC Wireless Device Camera Operation Aboard 2. LCD Aircraft 3. Hot Key Buttons 4. Power Button The use of any portable elec- 5.

  • Page 27: Led Indicators

    Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Icon Color Description Green The Computer is On Orange The Battery is Charging Blinking Blinking The Battery has Reached Critically Low The Computer is In Sleep Mode Green Orange...

  • Page 28: Hot Key Buttons & Keyboard

    Quick Start Guide Hot Key Buttons & Keyboard Activate the Number Lock feature by pressing the Num Lk key at the top right of the keyboard. You may These buttons give instant access to the default Inter- check if Number Lock is enabled or not by looking at net browser and e-mail program, and to a user-defined the LED status indicators.

  • Page 29: Function/Hot Key Indicators

    Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is in- stalled (see “Hot Key”...

  • Page 30: System Map: Front & Rear Views

    Quick Start Guide System Map: Front & Rear Views Figure 1 - 4 Front View 1. LCD Latches 2 3 4 5 2. Line-In Jack 3. Headphone-Out Jack 4. Microphone-In Jack 5. S/PDIF-Out Jack 6. LED Indicators 7. Infrared & Consumer Infrared Transceiver Overheating...

  • Page 31: System Map: Right View

    Quick Start Guide System Map: Right View Figure 1 - 5 Right View 1. Express Card Slot 2. 7-in-1 Card Reader 3. 2 * USB 2.0 Ports 4. Mini-IEEE 1394 Port 5. RJ-11 Phone Jack 6. RJ-45 LAN Jack 7. CATV Antenna Jack Mini-IEEE 1394 Port (Enabled With TV The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices.

  • Page 32: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 6 Left View 1. Speaker 2. Security Lock Slot 3. Optional Device Drive Bay (for CD/DVD Device, see page Changing DVD Regional Codes CD/DVD Emergency Eject If you need to manually eject a CD/DVD Go to the Control Panel and double-click (e.g.

  • Page 33: System Map: Bottom View

    Quick Start Guide System Map: Bottom View Figure 1 - 7 Bottom View 1. Vent/Fan Intake/Out- 2. Battery 3. Optical Device Release Latches 4. Component Bay Cover 5. Infrared & Consumer Infrared Transceiver 6. Sub Woofer Battery Information Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial dis- charges.

  • Page 34: Windows Vista Start Menu & Control Panel

    Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 35: Video Features

    Quick Start Guide Video Features You can configure display options, from the Display Settings control panel in Windows as long as the appro- priate video driver is installed. For more detailed video information see “NVIDIA Video Driver Installation” on page B - To access Display Settings in Windows: 1.

  • Page 36: Display Devices & Options

    Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display (con- nected to the DVI-Out port) or TV (connected to the S-Video-Out jack) as your display device. Figure 1 - 9 - Display Settings &...

  • Page 37: Power Options

    Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 14) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
  • Page 38 Quick Start Guide 1 - 18...

  • Page 39: Storage Devices, Mouse, Audio & Printer

    Storage Devices, Mouse, Audio & Printer Chapter 2: Storage Devices, Mouse, Audio & Printer Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical Device • 7-in-1 Card Reader •...

  • Page 40: Hard Disk Drive

    Storage Devices, Mouse, Audio & Printer Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.

  • Page 41: Optical Device

    Storage Devices, Mouse, Audio & Printer Optical Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the model you purchased (see “Storage” on page C - 3). The Adjustment optical device is usually labeled “Drive D:”...

  • Page 42: Handling Cds Or Dvds

    Storage Devices, Mouse, Audio & Printer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed.

  • Page 43: Dvd Regional Codes

    Storage Devices, Mouse, Audio & Printer DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...

  • Page 44: 7-In-1 Card Reader

    Storage Devices, Mouse, Audio & Printer 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).

  • Page 45: Expresscard Slot

    Storage Devices, Mouse, Audio & Printer ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g.

  • Page 46: Application Hot Key

    Storage Devices, Mouse, Audio & Printer Application Hot Key To configure a program to open when the application hot key button is pressed Application.exe (Windows Media Player is the default program), follow the instructions below. You will need to locate the actual application execut- Double-click the hot key driver icon in the taskbar.

  • Page 47: Touchpad And Buttons/Mouse

    Storage Devices, Mouse, Audio & Printer TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.

  • Page 48: Audio Features

    Storage Devices, Mouse, Audio & Printer Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).

  • Page 49: Enabling Fast Infrared (Fir)

    Storage Devices, Mouse, Audio & Printer Enabling Fast Infrared (FIR) If you wish to enable and use the fast infrared transceiver then follow the procedure out- lined below. Enable the FIR Device in the BIOS 1. Restart the computer. 2. Enter the PhoenixBIOS Setup Utility by pressing F2 during the POST. 3.

  • Page 50: Adding A Printer

    Storage Devices, Mouse, Audio & Printer Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options.

  • Page 51: Power Management

    Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.

  • Page 52: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components (see page Attach the AC/DC adapter to the DC-In jack at the rear of the computer.

  • Page 53: Turning On The Computer

    Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot- ways shut your comput- er down by choosing the key button when it is pressed for less than 4 seconds (pressing and holding the power...

  • Page 54: Power Plans

    Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
  • Page 55 Power Management Each Windows Power Plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance for maximum performance when the computer is pow- ered from an AC power source.

  • Page 56: Power-Saving States

    Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where Power Button you left off. Sleep is the default power-saving state in Windows Vista. The Power Button Earlier versions of Windows used Stand By and Hibernate as system power-saving in the Start Menu (in Classic View use the states.

  • Page 57: Hibernate

    Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.

  • Page 58: Configuring The Power Buttons

    Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Protection It is recommended that you enable a password on wake up in order to protect your data.

  • Page 59: Resuming Operation

    Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color send the computer to...

  • Page 60: Battery Information

    Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power When the battery is criti- Your computer’s battery power is dependent upon many factors, including the pro- cally low, immediately grams you are running, and peripheral devices attached.

  • Page 61: Conserving Battery Power

    Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that Windows Mobility this may have an affect on computer performance. Center • Lower the brightness level of the LCD display. The system will decrease LCD Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.

  • Page 62: Battery Life

    Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...

  • Page 63: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.

  • Page 64: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
  • Page 65 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
  • Page 66 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.

  • Page 67: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities This chapter deals with installing the drivers and utili- Table 4 - 1, on page 4 - 3 lists what you need to install and it is very important that the drivers are in- ties essential to the operation or improvement of some stalled in the order indicated (see “Driver Installa-...

  • Page 68: Driver Installation

    Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the DVD-ROM and click Install Drivers (button), or Op- Drivers Installer menu below.

  • Page 69: Updating/Reinstalling Individual Drivers

    Drivers & Utilities Updating/Reinstalling Individual Drivers Driver Page If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do Chipset Page 4 - 4 this go to the Control Panel in the Windows OS and Video Page 4 - 4 double-click the Programs and Features icon (Pro-...

  • Page 70: User Account Control (Win Vista)

    Drivers & Utilities User Account Control (Win Vista) New Hardware Found If a User Account Control prompt appears as part of If you see the message “New Hardware Found” the driver installation procedure, click Continue/Al- (Found New Hardware Wizard) during the installa- low, and follow the installation procedure as directed.

  • Page 71: Audio

    Drivers & Utilities Audio 1. Click 3. Install Audio Driver > Yes. 1. Click 6.Install LAN Driver > Yes. 2. Click Next. 2. Click Next > Install. 3. Click Finish to restart the computer. 3. Click Finish. Modem TouchPad 1. Click 4.Install Modem Driver > Yes. 1.

  • Page 72: Optional Drivers

    Drivers & Utilities Optional Drivers Bluetooth See the pages indicated for the driver installation pro- See the install procedure in “Bluetooth Driver Instal- cedures for any modules included in your purchase op- lation” on page 7 - tion. PC Camera See the install procedure in “PC Camera Driver In- stallation”...

  • Page 73: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The Setup utility up Defaults with <F9>.

  • Page 74: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...

  • Page 75: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 76: The Setup Utility

    BIOS Utilities The Setup Utility The Phoenix Setup utility tells the system how to configure itself and manage basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 5 - 1 on page 5 - 2 is usually present for a...

  • Page 77: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.

  • Page 78: Main Menu

    BIOS Utilities Main Menu Phoenix TrustedCore(tm) Setup Utility Main Main Advanced Security Boot Exit Figure 5 - 2 Main Menu Item Specific Help System Time: [22:12:05] System Date: [05/25/2007] <Tab>, <Shift Tab>, or IDE Primary/Master [FUJITSU MHV2100BH PL-(S1)] <Enter> selects field. IDE Secondary/Master [Optiarc DVD RW AD-7530A-(] System Memory:...

  • Page 79: Ide Primary/Master (Main Menu)

    BIOS Utilities IDE Primary/Master (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a HDD on the com- puter’s IDE Primary/Master Channel. Use the Auto (Type:) setting to have the items configured automatically for you. IDE Secondary/Master (Main Menu) Pressing Enter opens the sub-menu to show the configuration of an optical Device on the computer’s IDE Channel 1.

  • Page 80: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 Phoenix TrustedCore(tm) Setup Utility Advanced Menu Main Advanced Security Boot Exit Advanced Item Specific Help Advanced Chipset Control I/O Device Configuration Select options for Reset Configuration Data: [No] Advanced Chipset features. Legacy USB Support: [Enabled] Boot-time Diagnostic Screen: [Enabled]...

  • Page 81: I/O Device Configuration (Advanced Menu)

    BIOS Utilities Phoenix TrustedCore(tm) Setup Utility Advanced Figure 5 - 4 Advanced Chipset Control Item Specific Help Advanced Chipset Control Menu Intel Turbo Memory Intel Robson [Disabled] Technology SATA - Device 31, Function 2: [Compatible] AHCI Configuration Enabled] DFOROM(Robson) Support: [Enabled] Help Select Item...

  • Page 82: Legacy Usb Support: (Advanced Menu)

    BIOS Utilities Legacy USB Support: (Advanced Menu) Use this menu item to enable/disable the support for Legacy Universal Serial Bus. Boot-time Diagnostic Screen: (Advanced Menu) Use this menu item to enable/disable the Boot-time Diagnostic Screen (or POST screen - see “The Power-On Self Test (POST)”...

  • Page 83: Security Menu

    BIOS Utilities Security Menu Phoenix TrustedCore(tm) Setup Utility Security Menu Main Advanced Security S S e e c c u u r r i i t t y y Boot Exit changes Item Specific Help Supervisor Password Is: Clear make here affect the Set Supervisor Password [Enabled] access to the Setup...

  • Page 84: Password On Boot: (Security Menu)

    BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password should be entered to boot the computer (you may only set a password on boot if a supervisor password is enabled). If “Enabled” Password Warning is selected, only users who enter a correct password can boot the system (see the If you set a boot pass- warning in the sidebar).

  • Page 85: Boot Menu

    BIOS Utilities Boot Menu Phoenix TrustedCore(tm) Setup Utility Figure 5 - 6 Main Advanced Security Boot Exit Boot Menu Item Specific Help Boot priority order: USB KEY: Keys used to view or USB FDC: configure devices: USB CD: Optiarc CD-RW CRX880A-(SM) Up and Down arrows IDE HDD: FUJITSU MHV2100BH PL-(S1) select a device.

  • Page 86: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 7 Phoenix TrustedCore(tm) Setup Utility Main Advanced Security Boot Exit Exit Menu Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help...

  • Page 87: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help. Before you begin you will need: Please check with your service representative...

  • Page 88: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...

  • Page 89: Removing The Battery

    Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Please check with your Turn the computer off, turn it over and remove the battery. service representative Slide latch...

  • Page 90: Upgrading The Hard Disk Drive

    Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive(s) can be taken out to accommodate other 2.5" serial (SATA) HDD System Warning hard disk drives with a height of 9.5mm (h) (see “Storage” on page C - 3).
  • Page 91 Upgrading The Computer Remove the bay cover Figure 6 - 3 Bay Cover Removal Remove screws from the hard disk cover. Slide the hard disk assembly in the direction of the arrow Figure 6 - 4 Hard Disk Assembly Removal Upgrading the Hard Disk Drive 6 - 5...
  • Page 92 Upgrading The Computer Carefully remove the hard disk assembly in the direction of the arrow Figure 6 - 5 HDD Removal Remove screws to separate the hard disk from the bracket. Reverse the process to install any new hard disk. Figure 6 - 6 HDD Bracket Screws...

  • Page 93: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO- DIMM) DDR II (DDR2) type memory modules (see “Memory” on page C - 2). The total memory size is automatically detected by the POST routine once you turn on your computer.
  • Page 94 Upgrading The Computer Remove the bay cover Figure 6 - 8 Bay Cover Removal Contact Warning Be careful not to touch the metal pins on the module’s connecting edge. Even the cleanest Gently pull the two release latches ( & on the sides of the memory socket in hands have oils which the direction indicated by the arrows in...
  • Page 95 Upgrading The Computer The RAM module will pop-up, and you can remove it. Figure 6 - 10 RAM Module Removal Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory socket.

  • Page 96: Upgrading The Optical (Cd/Dvd) Device

    Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn the computer off, turn it over and remove the battery. Slide the latch towards the unlock symbol and hold it in place. Slide latch (while still holding latch in place) in the direction indicated by the arrow in order to push the device out of the computer.

  • Page 97: Removing The Tv Tuner Card/Turbo Memory Module

    Upgrading The Computer Removing the TV Tuner Card/Turbo Memory Module There is a MiniCard slot available for either the TV Tuner OR Turbo Memory mod- ule if included in your purchase option. Note that the MiniCard slot used for the Wireless LAN module, supports the Wireless LAN module only (the Wireless LAN MiniCard slot does not support the TV Tuner OR Turbo Memory module).
  • Page 98 Upgrading The Computer Remove the bay cover The TV Tuner OR Turbo Memory module will be visible at point Figure 6 - 13 Bay Cover Removal For the TV Tuner: Remove screws & , and then carefully disconnect cable The TV Tuner module will pop-up, and you can remove it.
  • Page 99 Upgrading The Computer For the Turbo Memory Module: Remove screws & The Turbo Memory module will pop-up, and you can remove it. Figure 6 - 15 Removing the Turbo Memory Module Removing the TV Tuner Card/Turbo Memory Module 6 - 13...
  • Page 100 Upgrading The Computer 6 - 14...

  • Page 101: Modules

    Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. The chapter includes information on the following: •...

  • Page 102: Wireless Lan Module

    Modules Wireless LAN Module If you have included an Intel Wireless WiFi Link 4965AGN (802.11a/g/n) PCIe Wireless Device WLAN module in your purchase option, make sure that the Wireless LAN module Operation Aboard is on before installing the driver. Use the Fn + F11 key combination (see Table 1 Aircraft - 4, on page 1 -...

  • Page 103: Connecting To A Wireless Network

    Modules Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 1 Taskbar Menus Right-click icon...
  • Page 104 Modules Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network). Figure 7 - 3 Connecting Move the cursor over the taskbar icon...
  • Page 105 Modules To disconnect from the wireless network you can click the taskbar wireless icon , and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make sure that any network...

  • Page 106: Windows Mobility Center

    Modules Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).

  • Page 107: Bluetooth Module

    Modules Bluetooth Module The optional Bluetooth module allows you to connect your computer to Bluetooth Wireless Device enabled devices such as other computers, desktop computers, mobile phones, print- Operation Aboard ers, digital cameras, PDAs, headsets etc. using a short-range radio frequency. Aircraft Make sure that the Bluetooth module is on.

  • Page 108: Connecting To Bluetooth Devices

    Modules Connecting to Bluetooth Devices Make sure the Bluetooth module is turned on. If the Bluetooth taskbar icon is grayed out, click the icon and select Turn on Bluetooth (or double-click the icon to start Bluetooth). The Bluetooth Places window will then appear (the icon will change color Figure 7 - 7 Turn on Bluetooth Double-click Search Devices to search for any available Bluetooth devices within...
  • Page 109 Modules Double-click any of the devices found to bring up the device options. Figure 7 - 9 Bluetooth Device Options More advanced options (and Help) are available by clicking the taskbar icon and selecting Display Classic View. This will bring up the IVT BlueSoliel window. Click Bluetooth >...
  • Page 110 Modules Disconnecting Online Help You can close the pro- BlueSoliel Online Help gram by selecting Turn is available from the off Bluetooth from the Help menu (or press the taskbar menu. F1 key) in the IVT Blue- Soleil window. This DOES NOT turn off the Bluetooth mod- Click any of the under- ule power.

  • Page 111: Pc Camera Module

    Modules PC Camera Module There are 2 camera options available for this computer, depending on your purchase Latest PC Camera configuration. The 1.3M pixel camera module uses the BisonCap application to Driver Information capture video files. The 2.0M pixel camera module uses the VideoView application to capture video files.

  • Page 112: Pc Camera Driver Installation

    Modules PC Camera Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual DVD-ROM into the CD/DVD drive. 2.0M PC Camera Screen Refresh 2. Click Optional (button). 3. Click 3.PC Camera Driver, Web cam > Yes. The 2.0M PC Camera module supports...

  • Page 113: Pc Camera Audio Setup

    Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
  • Page 114 Modules Figure 7 - 12 Audio Setup for PC Camera Right-click 7 - 14 PC Camera Module...

  • Page 115: Bisoncap For 1.3M Pixel Camera Module

    Modules BisonCap for 1.3M pixel camera module BisonCap is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the BisonCap program from the Start > Programs/All Programs > Bison- You may pre-allocate Cam menu (it is recommended that you set the capture file before the capture the file size for the cap-...
  • Page 116 Modules Eliminating Screen Flicker (BisonCap) If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select Video Capture Filter..Click either 50Hz or 60Hz under Frequency in Property Page (tab).

  • Page 117: Videoview (For 2.0M Pixel Camera Module)

    Modules VideoView (for 2.0M pixel camera module) VideoView is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the VideoView program from the Start > Programs/All Programs > USB2.0 You may pre-allocate the PC Camera menu (it is recommended that you set the capture file before the file size for the capture file...
  • Page 118 Modules Eliminating Screen Flicker (VideoView) If you find that the video screen in the VideoView program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the VideoView program. Go to Options and scroll down to select Video Capture Filter..Click either 50Hz or 60Hz under Flickering Reduction in Image (tab).
  • Page 119 Modules Zoom (VideoView) If you have enabled digital zoom when installing the 2.0M Pixel Camera driver you may use the Options > Setting menu to zoom the camera in and out. Run the VideoView program. Figure 7 - 15 Go to Options and scroll down to select Setting. Setting Use the slider to adjust the zoom level, and click OK to save the setting.

  • Page 120: Fingerprint Reader Module

    Modules Fingerprint Reader Module The optional fingerprint reader Protector Suite Software provides a high level Password Warning of security for your computer. A further level of security and control is provided in the BIOS (see “Security Menu” on page 5 - 11).

  • Page 121: Fingerprint Reader Driver Installation

    Modules Fingerprint Reader Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual DVD-ROM into the CD/DVD drive. Help & Manual 2. Click Optional, and then click 4.Install FingerPrint Driver > Yes. Right-click the taskbar icon 3.

  • Page 122: User Enrollment

    Modules User Enrollment Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon On the first run of the program you will be asked to click the button to accept the license, and then click OK. Click Next (“Enrollment to the hard disk”...
  • Page 123 Modules Click Next for each window of the tutorial (you can click the button to “skip tutorial” at any time). Click the button above any of the fingers to begin the enrollment process for that Fingerprint finger. Enrollment 10. Swipe the finger three times to enroll that finger. 11.
  • Page 124 Modules 16. Right-click the taskbar icon to bring up the menu that allows you to Edit Fingerprints, Start Control Center, access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/All Programs menu.

  • Page 125: Usb Tv Tuner Module

    Modules USB TV Tuner Module A CD containing drivers, software and a user guide will be supplied if your purchase TV Antenna configuration includes the optional USB TV Tuner module. In addition a driver is provided on the Device Drivers & Utilities + User’s Manual DVD-ROM for the The TV antenna sup- plied with any TV Tuner remote control supplied with the TV Tuner.

  • Page 126: Consumer Infrared Remote Control Unit Driver

    Modules Consumer Infrared Remote Control Unit Driver 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual DVD-ROM into the CD/DVD drive. Screen Rotation & TV Tuner Modules 2. Click Optional, and then click 5.Install ITE CIR Driver > Yes. 3.
  • Page 127 Modules 17. Run the Hybrid DTV application from the Start > Programs/All Pro- grams > Hybrid DTV and select the DTVplayer program or double-click the DTVplayer shortcut on the desktop. 18. Run Windows Media Center directly from the Start menu (Start > Pro- grams >...

  • Page 128: Digital Tv Broadcast Signal

    Modules Digital TV Broadcast Signal The antenna is the most crucial factor in receiving a clear digital terrestrial TV broadcast signal. The passive antenna provided should provide a clear signal when CATV Cable Safety placed beside a window. If the signal is not clear then you can purchase an active Make sure that your antenna (it should also be placed beside a window) to improve the signal.

  • Page 129: Intel Turbo Memory Module

    Modules Intel Turbo Memory Module If you have included an Intel Turbo Memory (Robson) NAND flash memory card ReadyBoost Issue module in your purchase option, then you will need to enable the option in the BIOS (see ) BEFORE installing the Windows Vista op- “Advanced Menu”...

  • Page 130: 7 - 30 Intel Turbo Memory Module

    Modules 7. Select Exit Saving Changes from the Exit menu (or press F10 and Enter) and press Enter to exit the BIOS and reboot the computer. 8. As the computer starts up, press a key when you see the message "Press any key to boot from CD or DVD".

  • Page 131: Troubleshooting

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 132: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 133: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.

  • Page 134: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.

  • Page 135: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 136 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.

  • Page 137: Problems & Possible Solutions

    Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned the power on Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 138 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
  • Page 139 Troubleshooting Problem Possible Cause - Solution Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk. The sound cannot be The volume might be set too low.
  • Page 140 Troubleshooting Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC/DC adapter, press a key on the the screen goes dark. keyboard, or press the sleep (Fn + F4) key combination, or press the power button if no LEDs are lit.

  • Page 141: Screen Resolution Error

    Troubleshooting Screen Resolution Error If you are experiencing either screen resolution reduction, or screen flickering after resuming from Sleep in Windows Vista only then follow the instructions below to fix this problem. This error arises in compliance with Windows Vista policy, which triggers TMM (Transient Multi-Monitor Manager) when the notebook lid (S3) is closed.
  • Page 142 Troubleshooting Double-click Task Scheduler Library > Microsoft > Windows. Click MobilePC to open the control panel. Right-click TMM and select Disable. Figure 8 - 2 - TMM Disable Close all the control panels. 8 - 12 Screen Resolution Error...

  • Page 143: Interface (Ports & Jacks)

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to commu- nicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...

  • Page 144: Ports And Jacks

    Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) RS MMC (requires PC adapter) SD (Secure Digital) Mini SD (requires PC adapter) MS (Memory Stick) MS Duo (requires PC adapter) MS (Memory Stick Pro) TV Antenna Jack...

  • Page 145: Headphone-Out Jack

    Interface (Ports & Jacks) Item Description Headphone-Out Jack Headphones or speakers may be connected through this jack. Note: Set your system’s volume to a reduced level before connecting to this jack. Infrared (FIR) The FIR (fast infrared) transceiver at the front of the computer allows the computer to Transceiver communicate with similarly equipped devices (see “Enabling Fast Infrared (FIR)”...

  • Page 146: Mini-Ieee 1394 Port

    Interface (Ports & Jacks) Item Description Mini-IEEE 1394 Port This allows high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below). IEEE 1394 The Mini-IEEE 1394 ports only support SELF POWERED IEEE 1394 devices. RJ-11 Phone Jack This port connects to the built-in modem.

  • Page 147: Serial Port

    Interface (Ports & Jacks) Item Description Serial Port Connect a serial type mouse to this port. 7-Pin S-Video-Out Jack Connect your television to your computer and view DVDs, VCDs or anything else your computer can display. USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.
  • Page 148 Interface (Ports & Jacks) A - 6...

  • Page 149: Nvidia Video Driver Controls

    Nvidia Video Driver Controls Appendix B: Nvidia Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Resolution Error NVIDIA Video Driver Installation If you are experiencing screen resolution prob- Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - lems/screen flickering after resuming from Sleep in...

  • Page 150: Nvidia Control Panel

    Nvidia Video Driver Controls NVIDIA Control Panel More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Open the Display Settings (see page 16) control panel. To access the Ge- Click Advanced Settings (button). Force..
  • Page 151 Nvidia Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and tools which allows quick access to features such as display configuration, 3D Set- tings and Help menus etc. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
  • Page 152 Nvidia Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure B - 3 Help Menus B - 4 NVIDIA Control Panel...

  • Page 153: Attaching Other Displays

    Nvidia Video Driver Controls Attaching Other Displays Configuring an External Display in Windows Vista Display Devices Attach your external display to the external monitor port and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Besides built-in Windows Mobility Center control panel (Mobile PC >...
  • Page 154 Nvidia Video Driver Controls Configuring an External Display using the NVIDIA Control Panel Attach your external display to the external monitor port and turn it on. Go to NVIDIA Control Panel (see “NVIDIA Control Panel” on page B - Function Key Click Display, and then click Change Display configuration.

  • Page 155: Display Modes

    Nvidia Video Driver Controls Display Modes Single Display Mode Resolution Error Only one of your displays is used. If you are experiencing screen resolution prob- Clone Mode lems/screen flickering after Clone Mode simply shows an exact copy of the Primary display desktop on the other resuming from Sleep in Windows Vista see page display(s).
  • Page 156 Nvidia Video Driver Controls Using New Display Detected to Enable Extended Mode Attach your external display to the external monitor port and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
  • Page 157 Nvidia Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external display to the external monitor port and turn it on. Click Start, and click Control Panel (or point to Settings and click Control Display Settings Panel). Extended Desktop Click Adjust screen resolution under the Appearance and Personalization menu (or double-click Personalization >...

  • Page 158: Enabling Tv Display

    Nvidia Video Driver Controls Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an Detect Displays S-Video cable from the TV to the 7-pin S-Video-Out jack at the rear of the computer. To get a full range of dis- You will need to enable the TV display from the NVIDIA Control Panel as per the play options click...

  • Page 159: Changing The Tv Signal Format

    Nvidia Video Driver Controls Changing the TV Signal Format When the TV is selected as a display device, click the home icon to return to the category menu. Click Video and Television, and then click “Change the signal or HD format” Select the TV signal format (the menu allows you to select TV format by country if you are unsure of your TV format).
  • Page 160 Nvidia Video Driver Controls B - 12...

  • Page 161: Specifications

    Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.

  • Page 162: Processor Types

    Specifications Feature Specification Processor Types Intel® Core™2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package, Socket P 2MB On-die L2 Cache & 800MHz FSB T7100 1.80 GHz Intel® Core™2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package, Socket P 4MB On-die L2 Cache &...

  • Page 163: Video Adapter Options

    Specifications Feature Specification Video Adapter NVIDIA GeForce Go 7950 GTX PCI-E Video Options Card MXM-IV Video Card Options 512MB GDDR3 Video RAM On Board MS DirectX® 9.0 compatible Note that card types, specifications and drivers are subject to continual updates and changes. NVIDIA GeForce 8700M GT PCI-E Video Card Check with your service center for the latest de- MXM-III...

  • Page 164: Audio

    Specifications Feature Specification Audio Intel® High Definition Audio Interface (HDA) S/PDIF Digital Output 7.1CH 3D Stereo Enhanced Sound System Built-In Microphone Ω) SRS WOW Surround Sound Technology 2 * Built-In Speakers (1.5W, 8 Ω Inside One Sub Woofer (2W, 8 Sound-Blaster PRO™...

  • Page 165: Communication

    Specifications Feature Specification Communication Built-In 56K MDC Modem, V.90 & V.92 Compliant TV Tuner Module with MiniCard, USB Interface (Option) Built-In Gigabit Ethernet LAN Bluetooth 2.0 + EDR (Enhanced Data Rate) Wireless LAN Module: Module (Factory Option) Intel® Wireless WiFi Link 4965AGN Wireless LAN Module with MiniCard, PCIe Interface (Option) 1.3M or 2.0M Pixel USB 2.0 PC Camera Module (Factory Option)

  • Page 166: Optional

    Specifications Feature Specification Optional Optical Drive Module Options: 1.3M or 2.0M Pixel USB 2.0 PC Camera Module (Factory Option) DVD/CD-RW Combo Drive Module DVD-Super Multi Drive Module Fingerprint Reader Module (Factory Option) Intel® Wireless WiFi Link 4965AGN Wireless LAN TV Tuner Module with MiniCard, USB Interface Module with MiniCard, PCIe Interface Intel Turbo Memory (Robson) NAND Flash Bluetooth 2.0 + EDR (Enhanced Data Rate)

  • Page 167: Power Management

    Windows XP Information Appendix D: Windows XP Information This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows XP OS. • DVD Regional Codes • Windows XP Start Menu & Control Panel • Audio Features •...

  • Page 168: Dvd Regional Codes

    Windows XP Information DVD Regional Codes Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.

  • Page 169: Windows Xp Start Menu & Control Panel

    Windows XP Information Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 170: Audio Features

    Windows XP Information Audio Features You can configure the audio options on your computer from the Sounds and Audio Sound Volume Devices Windows control panel. For advanced options double-click the Realtek Adjustment HD Audio Manager icon in the taskbar (or click the control panel) to bring up How high the sound vol- the Realtek Audio Configuration menus.

  • Page 171: Function/Hot Key Indicators

    Windows XP Information Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is in- stalled (see “Hot Key”...

  • Page 172: Application Hot Key

    Windows XP Information Application Hot Key To configure a program to open when the application hot key button is pressed (Windows Media Player is the default program), follow the instructions below. Application.exe You will need to locate the 1. Double-click the Hot Key driver icon in the taskbar.

  • Page 173: Video Features

    Windows XP Information Video Features You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the appropriate video driver is installed. To access Display Properties in Windows: 1. Click Start, point to Settings and click Control Panel (or just click Control Panel). 2.

  • Page 174: Display Properties

    Windows XP Information Display Properties Figure D - 5 - Display & Additional Properties Video Card Options Note that card types, specifications and drivers are subject to continual updates and changes. Check with your service center for the latest details on video cards supported. The items listed in the Additional Properties window allow you to configure your display(s).

  • Page 175: Display Devices & Options

    Windows XP Information Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV as your display device. A VGA monitor/Flat Panel Display connects to the DVI-Out port or external monitor port;...

  • Page 176: Attaching Other Displays

    Windows XP Information Attaching Other Displays 1. Attach your external display to the external monitor port/DVI-Out Port (or TV to the S- Video-Out jack), and turn it on. Device Settings 2. Go to the Additional Properties in the GeForce..Properties control panel tab. Click the display icon to 3.
  • Page 177 Windows XP Information 6. Select the display option from the Primary Display/ Secondary Display dropbox. If you have a TV and external monitor/flat panel display attached you will have a number of available options. Select and Apply the appropriate option. nView Display Mode Options The display options list-...

  • Page 178: To Enable Extended Desktop

    Windows XP Information To Enable Extended Desktop Attach your external monitor to the external monitor port and turn it on. Click Start, point to Settings (or click Control Panel) and click Control Panel (if you are in Category View choose Appearance and Themes). Double-click Display (icon).

  • Page 179: Power Management Features

    Windows XP Information Power Management Features The Power Options control panel icon in Windows (see page 3) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk, or you may use either Stand by or Hibernate mode to conserve power throughout the system.

  • Page 180: System Power Options

    Windows XP Information Each Windows Power Scheme will also adjust the processor performance of your machine in order to save pow- er. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.

  • Page 181: Stand By

    Windows XP Information Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle at its slowest speed. All open applications are retained in memory.

  • Page 182: Configuring The Power Button

    Windows XP Information Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hibernate mode. In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery). If you are in a power saving mode set to save power through individual components (e.g.

  • Page 183: Battery Information

    Windows XP Information Battery Information Please follow these simple guidelines to get the best use out of your battery. New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ” on page D - 20). Battery Life Your computer’s battery life is dependent upon many factors, including the programs you are running, and pe- ripheral devices attached.

  • Page 184: Recharging The Battery With The Ac/Dc Adapter

    Windows XP Information Battery life may be shortened through improper maintenance. To optimize the life and improve its perfor- mance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason “Removing the Battery”...

  • Page 185: Proper Handling Of The Battery Pack

    Windows XP Information Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.

  • Page 186: Battery Faq

    Windows XP Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer by yourself even when you see a message that indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.

  • Page 187: Driver Installation

    Windows XP Information Driver Installation Check the driver installation order from Table D - 4, on page D - 22 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the Drivers Installer menu below.
  • Page 188 Windows XP Information WinXP SP2 Driver Page # Manual Driver Installation Chipset D - 24 Click the Browse CD button in the Drivers Installer appli- Video D - 24 cation and browse to the executable file in the appropriate Audio D - 24 driver folder.

  • Page 189: Updating/Reinstalling Individual Drivers

    Windows XP Information Updating/Reinstalling Individual Drivers If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do Windows XP Service Pack 2 this go to the Control Panel in the Windows OS and Make sure you install Windows XP Service Pack 2 (or a double-click the Add/Remove Programs item.

  • Page 190: Chipset

    Windows XP Information Chipset Modem 1. Click 1.Install Chipset Driver > Yes. 1. Click 4.Install Modem Driver > Yes. 2. Click Next > Yes > Next > Next. 2. Click OK. 3. Click Finish to restart the computer. 3. The modem is now ready for configuration. Video 1.

  • Page 191: Card Reader/Expresscard

    Windows XP Information Card Reader/ExpressCard Module Drivers 1. Click 6.Install CardReader Driver > Yes. See the following pages for the driver installation pro- 2. Click Next > Next. cedures for any of the optional modules included in your purchase configuration. 3.

  • Page 192: Intel Wlan Module

    Windows XP Information Intel WLAN Module Before installing the Wireless LAN driver use the Fn + F11 key combination to toggle power to the module . Intel WLAN Driver Installation 1. Make sure the module is powered on (use the Fn + F11 key combination to toggle power to the mod- ule), and then insert the Device Drivers &...

  • Page 193: Intel Wlan Module D

    Windows XP Information User Guide You can view the User Guides from the Device Drivers & Utilities + Us- er’s Manual DVD-ROM. Click Optional > Yes and then click the Unlock but- ton. Click 1.Wireless Lan > Yes. Click View User Guide (button).

  • Page 194: Bluetooth Module

    Windows XP Information Bluetooth Module Before installing the Bluetooth driver use the Fn + F12 key combination to toggle power to the module . Bluetooth Driver Installation 1. Make sure the module is powered on and then insert the Device Drivers & Utilities + User’s Manual DVD-ROM into the CD/DVD drive.

  • Page 195: Bluetooth Module D

    Windows XP Information Bluetooth Local Area Connection Icon If you want to display the Local Area Connection icon for the Bluetooth connection in the taskbar, set it up as follows: Disconnecting Access the Network Connections control panel in Windows (Start > Settings > In order to have the taskbar Network Connections OR Start >...

  • Page 196: Connecting To Bluetooth Devices

    Windows XP Information Connecting to Bluetooth Devices Make sure the Bluetooth module is turned on. 1. If the Bluetooth taskbar icon is grayed out, click the icon and select Turn on Bluetooth (or double-click the icon to start Bluetooth). Figure D - 17 Turn on Bluetooth 2.
  • Page 197 Windows XP Information Double-click any of the devices found to bring up the device options. Figure D - 19 Bluetooth Device Options More advanced options (and Help) are available by clicking the taskbar icon selecting Display Classic View. This will bring up the IVT BlueSoliel window. Click Bluetooth >...
  • Page 198 Windows XP Information Disconnecting Online Help You can close the pro- BlueSoliel Online Help gram by selecting Turn is available from the off Bluetooth from the Help menu (or press the taskbar menu. F1 key) in the IVT Blue- Soleil window. This DOES NOT turn off the Bluetooth mod- Click any of the under-...

  • Page 199: Pc Camera Module

    Windows XP Information PC Camera Module Before installing the optional PC Camera module driver use the Fn + F10 key com- Taking Still Pictures bination to toggle power to the module. There are 2 camera options available for this computer, depending on your purchase configuration. The 1.3M pixel camera mod- Double-click ule uses the BisonCap application to capture video files.
  • Page 200 Windows XP Information For the 2.0M Pixel Camera Module: 1. Click Install. 2. Click to select Yes or No in answer to the power system question. 3. Click Finish > Finish to restart the computer. 4. Run the VideoView application program from the VideoView shortcut on the desktop, or from the USB2.0 PC Camera item in the Start >...
  • Page 201 Windows XP Information BisonCap (for 1.3M pixel camera module) BisonCap is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the BisonCap application from the Start > Programs/All Programs > Bison- Cam menu (it is recommended that you set the capture file before the capture You may pre-allocate the process - see Set Capture File below).
  • Page 202 Windows XP Information Eliminating Screen Flicker (BisonCap) If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. 1. Run the BisonCap application. 2. Go to Options and scroll down to select “Video Capture Filter...”. 3.
  • Page 203 Windows XP Information VideoView (for 2.0M pixel camera module) VideoView is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the VideoView program from the Start > Programs/All Programs > USB2.0 PC Camera menu (it is recommended that you set the capture file before the cap- You may pre-allocate ture process - see Set Capture File below).
  • Page 204 Windows XP Information Eliminating Screen Flicker (VideoView) If you find that the video screen in the VideoView program is flickering, you can try to adjust the setting in the Video Capture Filter options. 1. Run the VideoView program. 2. Go to Options and scroll down to select Video Capture Filter..3.
  • Page 205 Windows XP Information Zoom (VideoView) If you have enabled digital zoom when installing the 2.0M Pixel Camera driver you may use the Options > Setting menu to zoom the camera in and out. Run the VideoView program. Figure D - 24 Go to Options and scroll down to select Setting.

  • Page 206: Fingerprint Reader

    Windows XP Information Fingerprint Reader If you have included the fingerprint reader in your purchase option you will need to Help & Manual install the driver as per the instructions below. Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full security pro- Right-click the taskbar icon tection.

  • Page 207: User Enrollment

    Windows XP Information User Enrollment Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon On the first run of the program you will be asked to click the button to accept the license, and then click OK. Click Next (“Enrollment to the biometric device”...
  • Page 208 Windows XP Information 10. Click Finish. 11. Right-click the taskbar icon to bring up the menu that allows you to Edit Fingerprints, start Control Center, access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/All Programs menu.

  • Page 209: Usb Tv Tuner Module

    Windows XP Information USB TV Tuner Module The USB TV Tuner Module driver and application are provided on a separate CD-ROM for Windows XP (see for further information). In addition a driver is provided on the Device “USB TV Tuner Module” on page 7 - 25 Drivers &...
  • Page 210 Windows XP Information 10. Click Next > Next > Next. 11. Click the button to restart the computer, and then click Next. 12. Click Finish to restart the computer. 13. Run the Hybrid DTV application from the Start > Programs/All Programs > Hybrid DTV and select the DTVplayer program or double-click the DTVplayer shortcut on the desktop.

  • Page 211: Enabling Fast Infrared (Fir

    Windows XP Information Enabling Fast Infrared (FIR) If you wish to enable and use the fast infrared transceiver then follow the procedure outlined below. Enable the FIR Device in the BIOS Restart the computer. Enter the PhoenixBIOS Setup Utility by pressing F2 during the POST. Use the arrow keys to select the Advanced menu.
  • Page 212 Windows XP Information D - 46...

Table of Contents
