Summary of Contents for Hefei Meiling MCBR1010 SERIES
- Page 1 MCBR1010 SERIES SERVICE MANUAL PREPARED BY:280W item group...
- Page 2 Hefei Meiling Company Ltd.Aug,2006 CATALOGUE PRODUCT BRIEF ……………………………………… 3 COOLING SYSTEM ………………………………… 6 CONTROLING SYSTEM ……………………… 8 EXPLODE VIEW ……………………………………… 11...
-
Page 3: Chapter 1 Product Brief
CHAPTER 1 PRODUCT BRIEF This product is a newly developed frost-free refrigerator of our company. The product's external appearance is special and decent sculpting. It is the whole box hull structure, poured foam behind, ensured foamed layer thickness equality. So the heat preservation function is more excellent It is the whole foamed door structure, designed to a thin door gasket structure that can keep cold air effect better and with... -
Page 4: Refrigerator Temperature
can spread hot efficiency increment and make cold effectively. Control the system accords with American UL safe attestation request, you can trust an usage please. Structure sketch plan and main parts name of that product 1.FREEZER BIN 2.REFRIGERATOR BIN 3.CAN DISPENSER 4.FREEZER SHELF 5.FREEZER TEMPERATURE 6.REFRIGERATOR TEMPERATURE... -
Page 5: Leveling Legs
11.LEVELING LEGS The chapter 2 colding system Colding system principle diagram Explain: refrigerant processing Compress left condenser connect pipe Suction pipe right condenser Evaporator connect pipe... - Page 6 Capillary pipe filter anti-coagulate pipe Two, function parameter form Technology parameter BCD-280W Electric shock classification of protection aganist Total capacity(L) Effective cubage refrigorator（L） 72 Freezen （L） Voltage（V） Frequency（Hz） Total input power（W） Defrost power（W） Electricity consumption 1.05 （KW.h/24h） Refrigerant and inject amount R134a /103g weight（Kg）...
- Page 7 Three, break down analysis: 一、refrigerate room isn’t cool or is cool not better Break down analysis: 1)the fan is bad or there is the stopper and its rotate speed is much low(it is much more possibility in after two kind.) 2)Refrigerator air road is not free so that breeze is much little or not.
- Page 8 much low(it is much more possibility in after two kind.) 2) Refrigerant lacks or leaks 3) Frost on the evaporate is thick ,or the ice is much more(see a behind reason analysis)so that refrigerator room is not cold or cold much better. 4) The compressor doesn't operate or is bad(see a behind reason analysis).
- Page 9 Break down analysis: 1) The door is not closed completely or the door gasket does not seal properly. 2) The electrical connection doesn’t operate properly. 3) The temperature fuse doesn’t operate properly. 4) the fan is bad or there is the stopper and its rotate speed is much low The compressor doesn't start Break down analysis:...
- Page 10 三 Control system 1. Electricity principle diagram 2.Defrost work principle It is time to begin from last defrost period,defrost timer port 3 and 4 are connected, the compressor begins to operate, between the compressor is operated ,the same time the motor of the defrost timer is operated,when it 16 hours that is the time of the compressor s operated ,under the drive of defrost timer motor defrost timer port 3 and 2 are connected ,the...
- Page 11 connected and defrost timer is stopped. The defrost timer motor is processed after about 7 minutes under the drive of defrost timer motor defrost timer port 3 and 2 are connected again,and it is time to end of defrost period, and the compressor is operated.Such as goes round and round.
- Page 12 Product Explosive View...
- Page 14 Model: MCBR1010GS/S/W Page 1...
- Page 15 Model: MCBR1010GS/S/W Page 2...
