Summary of Contents for pleomax MF210
- Page 1 User Manual WIRELESS HEADSET MF210...
-
Page 2: Headset Overview
ENCLOSURES MF210 Headset Ear hook USB Cable 3 different size ear bud User manual (Small, Medium, Large) HEADSET OVERVIEW Charging Port Speaker Multifunction Button Ear Bud Volume Button Microphone English... -
Page 3: Power On/Off
2. Press and hold Multi-function button for 5 seconds until blue LED turns on. 3. Search the headset via your phone and please follow the instruction of your mobile phone. 4. When you find your headset MF210, Active Dev List Input PIN Code Model Name please select it and confirm by “Yes”... -
Page 4: Making A Call
EASY PAIRING: If you use headset for the first time, headset will go pairing mode directly. Low Battery Warning : When Headset needs to charge, you can hear the warning beep every 30 seconds, unless you don’t charge within 30 minutes and headset will be power-off. MAKING A CALL Make a call from your mobile phone as usual;... -
Page 5: Ending A Call
ENDING A CALL Press the MFB during the call or just the ending button on the phone to end a call. LAST NUMBER REDIAL With the phone in standby, press MFB; the headset automatically dials the last number dialed from the phone. VOICE DIAL Press MFB for about 2 seconds until you hear a beep. - Page 6 MULTIPOINT : Using the Headset with two phones [NOTE] Some mobile phones are not available for Multipoint. 1. Multi-point Connect Set the headset into pairing mode first. After then search headset from each mobile phones at the same time. Please connect first mobile phone. Once the connection is completed, please connect the second mobile phones.
-
Page 7: Volume Control & Mute Function
VOLUME CONTROL & MUTE FUNCTION Press the VOL button. There are 6 volume levels that cycle as you press the VOL button. When the highest level is reached, the volume level cycles back down to the lowest. Press and hold volume down button for 2 seconds, then the MIC will be muted with the melody every 5 seconds. - Page 8 2. Making a phone call [To use the 2nd mobile phone] Press the Volume button for twice until a beep sound is heard to make an last number redial from the second mobile phone. [NOTE] Making a phone call [To use the 1st mobile phone] Follow the same instruction in the section of ‘Making a call’...
-
Page 9: Status Indication
STATUS INDICATION 1. LED Indication Speaker Status LED Indication Power On Blue LED blinks 3 times Power Off Blue LED blinks 4 times Pairing Mode Blue LED turns On Connectable Mode Blue LED blinks 1 time every 5 seconds Connected Mode Blue LED blinks 2 times every 5 seconds Active Call Mode Blue LED blinks 3 times every 5 seconds... -
Page 10: Specifications
SPECIFICATIONS Model Name MF210 Bluetooth Core Spec Bluetooth Specification 2.0 Profile HFP, HSP Carrier Frequency 2400 MHz to 2483.5 MHz Modulation Method GFSK, 1Mbps, 0.5BT Gaussian Maximum Data Rate Asynchronous : 723.2 kbps / 57.6 kbps Synchronous : 433.9kbps / 433.9 kbps... -
Page 11: Safety And General Information
SAFETY AND GENERAL INFORMATION 1. Please read this guidebook carefully and follow the instruction. 2. To avoid any damage or malfunction of the unit, do not drop it from high place. 3. Keep away unit from humidity, water and any other liquid. And if the unit is exposed by water, moisture and other liquid directly, then do not operate it normally to avoid any electrical shock, explosion and damage of the unit. - Page 12 instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver.
-
Page 13: Warranty
Austria, Belgium, Denmark, Finland, France,Germany, Greece, Ireland, Italy, Luxembourg, The Netherlands, Portugal, Spain, Sweden, United Kingdom and within EFTA in Iceland, Norway and Switzerland. Bluetooth is a trademark owned by the Bluetooth SIG, Inc. WARRANTY The condition of this warranty and our responsibilities under this warranty are as follows: Supplier’s warranty is non-transferable. -
Page 14: Weee Symbol Information
WEEE SYMBOL INFORMATION Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
