Get Ready Parts of the Camera Flash Self-timer lamp/AF-assist illuminator Shutter-release button b (e movie-record) button Speaker Lens Microphone Battery-chamber/memory card slot cover Power switch/power-on lamp Eyelet for camera strap Eyelet for camera strap Charge lamp/ m Flash lamp Flexible buttons Multi selector Monitor (Screen) c (shooting/playback mode) button...
Get Ready Using the Monitor Battery level • F: The battery has enough power remaining. • G: The battery level is low. Number of 9 9 9 2 9 m 0 s images that can be taken Maximum movie recording time Flexible buttons Press to select an item shown on the monitor.
Get Ready Attaching the Camera Strap • Guide one hand through the camera strap and hold the camera steady with both hands. • When taking images, be careful not to cover the flash or lens with your fingers. After Attaching the Strap Do not swing the camera by the strap.
Get Ready Inserting the Battery and Memory Card Open the cover, and insert the battery and memory card. • Look at the stickers and insert the battery and memory card the right way. Charging the Battery Connect the camera to the Charging AC Adapter and to the electrical outlet.
Page 7
Get Ready • The battery starts charging, and the charge lamp flashes. • When the battery is fully charged, the charge lamp turns off. • Disconnect the Charging AC Adapter from the electrical outlet and then disconnect the cable. Close the cover. •...
A Shoot Taking Images Press the power switch to turn on the camera. 1 1 0 0 2 0 m 0 s Hold the camera steady and aim the camera so that you can see your subject in the monitor. Press the shutter-release button slightly (halfway).
Page 9
A Shoot Press the shutter-release button the 1 / 2 5 0 F 3.3 rest of the way down. • The camera takes an image. • Record movies → page 13 • Take images underwater → page 14 Using the Zoom H: Makes your subject bigger.
B View Viewing Your Images Press the c (shooting/playback mode) button. • B is displayed in the lower-right of the monitor. • The last image you took is displayed. 1 1 0 0 2 0 m 0 s Use the multi selector to look through your images. Current image Previous image Next image...
B View Deleting Images When B is displayed in the lower- right of the monitor, look through 1 5 / 0 5 / 2 0 1 4 1 5 : 3 0 your images and find an image you want to delete. •...
Page 12
B View Press R Yes. • If you delete an image, you cannot recover it. Erase 1 picture ? • Press S No if you want to stop with deleting the image. Deleting Several Images at Once 1 Select o Erase selected pictures in step 3. 2 Press the multi selector J or K to select the image to be deleted and press S.
Have More Fun Recording Movies While A is displayed in the lower- right of the monitor, aim the camera so that you can see your subject in the monitor. • Make sure you do not cover the microphone. Press the b (e movie-record) button.
Page 14
Have More Fun Taking Images Underwater Before Using the Camera Underwater 1 Make sure there is no debris caught in the battery-chamber/memory card slot cover. If there is debris, blow it off with a blower*. 2 Make sure that the battery-chamber/memory card slot cover is firmly closed. 3 Do not open the battery-chamber/memory card slot cover underwater.
Page 15
Have More Fun Press J or K, select J and press Shoot under water • The waterproofing-related message is displayed. Confirm the message and press K to display the next message. Press O to start shooting. Press the shutter-release button. Cleaning the Camera After Using It Underwater 1 Keep the battery-chamber/memory card slot cover closed and wash off the camera with fresh water.
Have More Fun Making Photo Albums When B is displayed in the lower- right of the monitor, press V. 1 5 / 0 5 / 2 0 1 4 1 5 : 3 0 Press V Picture play. Have fun with pic tures Exchange messages Pic ture play Grading...
Page 17
Have More Fun Select images for a photo album. • Press the multi selector J or K to select Make photo albums the images you want to add to a photo album and press S. Press O when you are finished choosing your images. •...
Page 18
Have More Fun Adding Voice Messages to Your Images When B is displayed in the lower- right of the monitor, find the image 1 5 / 0 5 / 2 0 1 4 1 5 : 3 0 you want to add a message to and press V.
Page 19
Have More Fun Press I Leave a message. • After you record a message, you can Record select Leave a reply. Leave a message Leave a reply Record a message. q: Press to start recording, and press again to stop recording. You can record for up to about 20 seconds.
Page 20
Other Things You Can Do With Your Camera Shoot at intervals Decorate Change sounds Use when shooting Use after shooting Shoot close-ups f Add starbursts X Photograph food A Grade images Y Use the smile timer m Watch slide shows Printed in China CT3L01(11) 6MN42911-01...
