H-100
Instant Hot Water Dispenser
• This product can not be used if the voltage is different from that mentioned in the rating plate.
• For your safety and proper use of the product, please read this User's Manual before use.
• Warranty card is included in this User's Manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Coway H-100

  • Page 1 H-100 Instant Hot Water Dispenser • This product can not be used if the voltage is different from that mentioned in the rating plate. • For your safety and proper use of the product, please read this User’s Manual before use.

  • Page 2: Table Of Contents

    DEAR CUSTOMERS Coway Instant Hot Water Dispenser Thank you for using our Please read this Users’ Manual to use and maintain the product correctly. If you encounter a problem while using the product, you may solve the problem referring to the User’s Manual.

  • Page 3: Safety Information

    SAFETY INFORMATION Be careful to keep this safety information. Please read this information to prevent property loss and ensure your safety. for 220 V - 240 V use only for 120 V use only Danger: If not observed, serious injury or even death may occur as a result.
  • Page 4 SAFETY INFORMATION • Do not place dishes or containers of water, drugs, food, or small metal objects on top of the product. • Immediately unplug and call the customer service center if the unit makes a strange noise or odd smell. •...
  • Page 5 Caution: If not observed, minor physical injury or property damage may occur as a result. • Use or place the unit on a level area and do not apply force to the unit. • Make sure that all electrical wiring and connections conform to local codes.

  • Page 6: Parts Name

    PARTS NAME Front / Rear 1 COVER-FRONT 4 COVER-SIDE LEFT 2 COVER-DIAL 5 POWER-CORD 3 LED(RED) 4 COVER-SIDE RIGHT 1 1/4 White tube to Faucet 2 3/8 Flexible tube to Faucet Check to make sure tubes are connected properly and are pushed down as far as possible. Accessories FAUCET SCREW(2)

  • Page 7: Installation

    INSTALLATION 1. Mounting Tank Position tank vertically beneath faucet so the flexible tube from the faucet reaches the center faucet supply tube on the tank and tank touches the wall. While holding sheet of screw point in place on the spot selected for installation, use a pencil to mark locations for 2 hanging screw.
  • Page 8 4. Connect Cold Water Supply Make sure the cold water connecting to the faucet is filtered. Use an Coway Commercial Grade filter System to provide filtered Water. Refer to the Coway Filter System Install and Operation Manual for installation procedures.
  • Page 9 6. Prepare for Power Double check temperature control dial is in the OFF position. Temperature dial controls the water temperature, not the water flow or delivery. 7. Test Installation Plug electrical cord into a grounded 3-prong outlet. Do not use outlet controlled by an off/on wall switch. Turn temperature control dial clockwise to the highest position.

  • Page 10: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Seasonal Shutdown To prevent damage when dispenser is exposed to freezing temperatures, water must be drained. 1. Unplug dispenser tank to power supply. 2. Turn control dial to OFF position (fully counterclockwise). 3. Turn faucet on and run water until water is cold. 4.

  • Page 11: Specifications

    SPECIFICATIONS Instant Hot Water Dispenser Product Name Model H-100 Power Supply 120 V~, 60 Hz, 750 W, 6.26 A 180 mm (W) x 195 mm (D) x 293 mm (H) Dimension 7 inch (W) x 7.6 inch (D) x 11.5 inch (H) Working Temperature 41 °F ~ 95 °F (5 °C ~ 35 °C)
  • Page 12 MEMO...
  • Page 13 MEMO...

  • Page 14: Warranty Card

    INCLUDING ITS REPRESENTATIVES, TO MAKE ANY only to Product used for an application specified REPRESENTATION OR TO OFFER ANY WARRANTY, by COWAY for the Product and applied in strict CONDITION OR GUARANTY IN RESPECT OF THE accordance with COWAY published specifications PRODUCT OTHER THAN THIS WARRANTY.
  • Page 15 If the Product fails to operate for its accident, alteration, improper installation or intended purpose, then notify Coway or its other acts that are not the fault of Coway or Representative Agency within 48 hours or the manufacturer of the product or that are within the next business day after discovery not covered by the manufacturer’s warranty;...
  • Page 16 MADE IN KOREA 1214458 www.coway.com...
