Summary of Contents for MK 05733s S4
- Page 1 Sentry Digital Timers 05733s S4 Contents Safety precautions General Information DIN rail Installation Display Layout Programming Technical Data Guarantee...
- Page 2 Safety precautions · The connection and installation of electrical devices may only be carried out by a qualified electrician. · Interventions in and changes to the device result in the voiding of the warranty claim. · Observe your national regulations and the respective safety provisions. ·...
- Page 3 Installation on DIN rail Terminal diagram Battery change Attention! · The battery change may only be carried out by a qualified electrician! – – Type: CR 2032 · Isolate the device before replacing the battery! · Check battery polarity when replacing. SUPPLY (LOAD) Load...
- Page 4 reset General information · The middle communication line shows the 1 2 3 4 5 6 7 selectable menu item. If confirmed with OK, this item is activated. · Flashing texts or symbols require an entry. · If no entries are made within the next 2 minutes, the clock reverts to Auto mode.
- Page 5 Initial start-up - selection of menu language English Deutsch Francais Español Italiano – Nederland Portugues Menu Czech Info In the delivered state the time switch is in the Auto mode with a preset time, date and the menu language English. After selecting language, the time switch jumps automatically to Program mode after 4 seconds.
- Page 6 Prog. New weekly program Info The time switch has 50 memory spaces. Example ON command at 3 pm. OFF command at 6 pm. · Select NEW program and confirm with OK. · Select WEEKLY program and confirm with OK. · The free memory spaces 1 2 3 4 5 6 7 are briefly displayed.
- Page 7 Prog. New holidays program Info The holiday program is run every year unless changes are program- med in. 1 2 3 4 5 6 7...
- Page 8 Prog. View, edit program Info · The program steps can be scrolled through with "+/-". · The respective program can be edited by pressing OK. The procedure is the same as when creating a new program.
- Page 9 Prog. Delete individual programs Info When deleting individual programs, the corres- ponding program steps are deleted (e.g. P01 ON and P02 OFF). Delete all programs...
- Page 10 Set date and time Info The date and time are preset at the factory. Set AM/PM (12-hour-) or 24-hour display...
- Page 11 Switchover for summer/winter time Info The following settings are possible: AUTO Factory presetting of the published calendar dates. This is automatically recalculated for each year. No switchover...
- Page 12 CALIBRAT Programming. The start date of the summer time and winter time must be entered for this purpose. The factory presetting is overwritten. The programmed summer / winter time is automatically recalculated for each year. The changeover takes place on the same specified day of the week in the same week of each month.
- Page 13 Operating mode Info Press 1 x = FIX ON = continuous ON Press 2 x = FIX OFF = continuous OFF Press 3 x = return to Auto mode FIX ON: FIX OFF: AUTO: (no display) programmed switching times – Menu Technical data Protection class...
- Page 14 GUARANTEE MK Electric undertakes to replace or repair at its discretion goods should they become defective within 10 years solely as a result of faulty materials and workmanship. Understandably, if the product has not been installed, operated or maintained in...
