ADC WFX-3100-M-1 Quick Installation Manual page 2

Install the Power Module
Step Action
2 If necessary, remove the front bezel from the
WFX-3100.
3
Insert the power module into a vacant slot in the
WFX-3100, and secure with a 3/16 inch allen key.
Figure 2. Install the Power Module
Mount the WFX-3100
Step Action
1
If necessary, reattach the front bezel.
2
Mount the WFX-3100 in a 1U rack.
Page 2 of 4
