Celluon Epic User Manual

Mobile projection keyboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

Mobile Projection Keyboard
Epic
User Guide
+ Copyright:
All rights reserved by Celluon. All page contents are properties of Celluon.
+ Celluon, evoMouse®,Magic Cube® are trademarks or registered trademark of Celluon.
All other products are trademarks or registered trademarks of the respective companies.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Epic and is the answer not in the manual?

Questions and answers

Related Manuals for Celluon Epic

Summary of Contents for Celluon Epic

  • Page 1 Epic User Guide + Copyright: All rights reserved by Celluon. All page contents are properties of Celluon. + Celluon, evoMouse®,Magic Cube® are trademarks or registered trademark of Celluon. All other products are trademarks or registered trademarks of the respective companies.

  • Page 2: Safety Precautions

    Safety Precautions 1. Avoid exposing this product to direct sunlight for extended periods of time, and keep it away from heat sources. 2. There is a risk of malfunction if product is used in places where sudden or extreme temperature changes occur. 3.
  • Page 3 7. Avoid placing any object within the space between main unit and laser projection keyboard layout. 8. Please do not use this product on uneven or irregular surfaces. Place the product on a at surface. Avoid table or surface that is re ective, such as glass or mirror. FCC Compliance Information This device complies with Part 15 of the FCC Rules.
  • Page 4 FCC Class Notice This equipment has been tested and found to comply within the limits for a Class B digital device, pursuant to Part15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment.
  • Page 5 - Connect the equipment to an outlet on a circuit di erent from which the receiver is connected. - Consult the dealer or an experienced radio/TV technician. FCC Caution Any changes or modi cations in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 6 IEC-60825-1 Caution Use of control or adjustments or performances of procedures other than those speci ed here in may result in hazardous radiation exposure. RF Exposure Information The antenna used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 7 Certi cation KC No : KCC-CRM-CLK-Epic FCC ID : TCLEPIC RoHS compliant TELEC No : 010-100043 CMIIT ID : 2013DJ6550 IC No : 10211A-EPIC Class 1 : IEC-60825-1 Bluetooth ID : B018080 CLASS 1 LASER PRODUCT + 07...
  • Page 8 Environmentally Friendly Disposal and Recycling To protect the environment, dispose this product separately from household waste once it has reached its end of life, or take it to your local electronic waste disposal center. Built-in Battery Rechargeable Lithium-ion Polymer Battery: Battery Operating Time: Approx.
  • Page 9 Note If you charge the battery while using the product, it may take longer to charge. When Epic is extremely low on power, it needs to charge for up to 5 minutes before you can use it. Cautions 1. Battery may explode if replaced with an incompatible battery. Dispose used batteries according to the instructions.

  • Page 10: Table Of Contents

    Contents 1. Product Features 2. Package Contents 3. How Epic Works 4. Identifying Parts 5. Connecting Epic 6. Making Adjustments 7. Speci cation 8. Product Warranty 10 +...

  • Page 11: Product Features

    Windows Phone 7 and 8), iOS 4 and later (most iPhone and iPad), Android 4.0 and later, Mac OS X, Blackberry 10, Game Console 2. Package Contents + Epic + Micro USB Cable + User Manual + Quick Start Guide...

  • Page 12: How Epic Works

    3. How It Works: Technology This product emits infrared light from the lower end of the device to detect objects such as ngers. When an object passes through they are illuminated by the infrared light source, any infrared light re ecting o of an object is detected by the sensor. Information on the position and movement of the object is then analyzed to perform the product's role as a keyboard.
  • Page 13 2. Avoid low color temperature light source, such as tungsten, halogen, or incandescent lamp. 3. Avoid uneven or irregular surfaces. Place the product on at surfaces. ** When using Epic on slanted surfaces such as an airplane tray table, please note that device and/or projected keyboard layout may shift.

  • Page 14: Identifying Parts

    4. Identifying Parts (1) Pattern Projector: laser projects an image of keyboard pattern onto a at surface in front of the typist. (2) Sensor: detects re ection of infrared and triangulates the location to determine a keystroke. (3) IR: emits an invisible plane of light to blanket operational area. LED Indicator Battery Lower LED...

  • Page 15: Front View

    Front View Rear View Pattern Projector Power Switch - Upper position : ON - Lower position : OFF Sensor LED for Bluetooth Status LED for Charging Status Pairing Switch Micro USB connector for charging IR Light + 15...

  • Page 16: Connecting Epic

    5. Connecting Epic Epic pairs via Bluetooth. - Compatible with any Bluetooth HID devices: iOS 4 and later (most iPhone and iPad) Android 4.0 or later Windows XP/Vista/7/8 (Not compatible with Windows Phone 7 and Phone 8) Mac OS X...
  • Page 17 Bluetooth connection instructions for iOS/Android/Windows 1. Power on Epic. 2. On primary device, go to Bluetooth setting; search for Bluetooth devices. 3. When the device discovers "Celluon PK Series", tap to connect. 4. Solid blue LED indicates successful pairing. Enabling Pairing Mode 1.
  • Page 18 Screen shot of successful Android pairing on 18 +...
  • Page 19 Screen shot of successful pairing on + 19...

  • Page 20: Making Adjustments

    6. Making Adjustments > Sound Feedback Adjustment + There are total of 5 levels; + To increase sound level : Tap and hold key and tap ↑ key. + To decrease sound level : Tap and hold key and tap key.
  • Page 21 Note : All adjustments must be repeated for each level. Adjusted setting value remains unchanged when device is turned o and on. > Power Save Mode + Tap and hold " " and tap " " key to disable laser projection. + To turn on laser projection, tap the operational area with 3 ngers ( ngers must be separated).
  • Page 22 2. Tap on cursor key to switch back to keyboard mode. Solid LED indicates keyboard mode. * Epic rmware is subject to change without prior notice. Latest rmware updates are available through our website www.celluon.com. Please visit our support page ( www.celluon.com → support → download ) for instructions.
  • Page 23 1. Control the cursor 2. Right-click Move your nger freely in With one nger on surface, any direction within tap with adjacent operational area. (right) nger. 3. Click and Drag 4. Forward and Back 5. Zoom In/Out With one nger on surface, Swipe left for "back".

  • Page 24: Speci Cation

    7. Speci cation >Pattern Projector Item Speci cation Light Source Red Laser Diode Keyboard Layout Approx. 19mm Pitch, QWERTY Layout Keyboard Size Approx. Width : 240mm, Height : 100mm Keyboard Location Approx. 100mm from the bottom of device Projection Surface Flat, opaque surface Recognition Rate Approx.
  • Page 25 >Electrical Characteristics Item Speci cation External Power Supply USB Power / less than 5V 500mA Battery & Capacity Lithium-ion Polymer Battery, 660 mAH (MAX) @3.7V Battery Operating Time Approx. 120min Battery Charging Time Approx. 180min Bluetooth V3.0(class2), HID Pro le with SSP Frequency Range 2402-2480Mhz + 25...
  • Page 26 >Environmental Conditions Speci cation Item Operating 0~35 ℃ /~90%RH Temperature Storage -5~35 ℃ /~90%RH Temperature >Dimensions and Speci cations Speci cation Item 70mm x 20mm x 35mm Size (mm) Approx. 60g Weight (g) 26 +...

  • Page 27: Product Warranty

    Product Warranty Thank you for purchasing Celluon product. This product has passed strict quality control standards. Celluon will repair or replace any defective unit during the warranty period. Model Name Epic Serial No. Date of Purchase Customer Name Purchasing Place...
  • Page 28 Celluon, Inc. 11F, 5, Digital-ro 26-gil, Guro-gu, Seoul, Korea (152-740) www.celluon.com sales@celluon.com support@celluon.com Version 1.0...
