Summary of Contents for Kamasa-TOOLS K 10613
- Page 1 Cordless K 10613 two speed drill/driver...
-
Page 2: Safety And Precaution
SAFETY AND PRECAUTION Consider work area environment. Do not expose tools to rain. Do not use tools in damp or wet locations – Keep work area clean and well lit. Do not use tools in the present of flammable liquids or gases. Guard against electric shock. -
Page 3: Product Safety Instructions
PRODUCT SAFETY INSTRUCTIONS Disconnect battery pack from tool or place the main switch in the locked or off position before making any adjustments, changing accessories, or storing the tool. Such preventa- tive safety measures reduce the risk of starting the tool accidentally. Remove adjusting keys or wrenches before turning the tool on . -
Page 4: Specific Safety Rules And/Or Symbols
ADDITIONAL SAFETY RULES FOR CHARGER & BATTERY PACK Do not charge battery pack when temperature is below 10°C (50°F) or above 40°C (104°F). Do not attempt to use a set-up transformer, an engine generator or DC power receptacle. Do not allow anything to cover or clog the charger vents. Always cover the battery pack terminals with the battery pack cover when the battery pack: is not used. -
Page 5: Product Specifications
PRODUCT SPECIFICATIONS Model No. K 10613 Voltage 18V DC No load speed/min Low: 0–1220 rpm High: 0–340 rpm Max Torque 45 Nm (33 ft-lb) Tool weight (with battery) 2.08 kg Chuck capacity Keyless 1/2” (13 mm) Clutch 17 sections Charging Time... -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS INSTALLING OR REMOVING BATTERY PACK (See Fig.1 Fig.2) Always switch off the machine before insertion or removal of the Fig 1 battery pack. To remove the battery pack, push the button on the battery pack and pull the tool unit from the battery pack in the direction.(See Fig.1.) To insert the battery pack, align the tool unit slides with the battery pack sliding groove and push the tool unit into place. - Page 7 LED INDICATION FUNCTION The Battery Pack has a “SW” button and 4-step green LEDs for indicating remaining capacity status and Over temperature condi- tion. The remaining capacity (RC) and temperature protection status green LED indications (3 seconds) when the “SW” button is POWER INDICATION momentarily pressed.
- Page 8 TOOL OPERATING HOW TO INSERT AND REMOVE BITS To insert a bit, turn the chuck clockwise. To remove a bit, turn the chuck counterclockwise. FORWARD/REVERSE KNOB SELECTION BUTTON Select the forward or reverse direction of the tool by pushing the Forward/Reverse knob. Turn counter clockwise Remove the bit Insert the bit...
- Page 9 HIGH/LOW SPEED SELECTION Use the “High” for drilling application. Use the “Low” form screwdriver application. SELECT THE APPLIED TORQUE Use the 17 sections adjustment ring to select the right torque for your application. DRILL MODE Turn the torque ring to the sign for the maximum torque position if you would like to drill on wood.
- Page 10 PARTS K 10613...
- Page 11 PARTS LIST K 10613 Parts name Qt Spare part No Chuck screw Keyless chuck Gear boc ass’y K 10265 High/low speed knob K 10267 Knob spring Speed change ring Motor connector Screw Motor ass’y K 10266 Forward/reverse knob Main switch...
