- Page 1 StovAmore ® MONZA INSTALLATION MANUAL www.docherty.co.uk SINCE 1960...
-
Page 2: Table Of Contents
General installation and operation manual for Docherty Monza stoves The fireplace stoves may only be operated in accordance with this manual! No unauthorized changes may be performed on the fireplace stoves! 1. Introduction............................3 2. Technical description........................3 3. Safety regulations.........................4 4. 3.1. Safe distances........................5 3.1.1 Safe distance of fireplace stoves from flammable materials........5... -
Page 3: Introduction
2. Technical description Fireplace stoves are intended for installation into various interiors (apartments, recreation buildings, restaurants). Docherty stoves are manufactured from quality construction materials – cast metal, CORTEN steel and quality construction and steel fittings, with stressed parts made of HARDOX steel. The surface of steel constructions is protected by a refractory opaque paint. -
Page 4: Safety Regulations
After the chimney heats up, you can partially or even completely close the primary air intake, based on the target output of the fireplace stove. It is also possible to reduce the fuelling or limit the chimney draught by attaching a draught stabiliser. This is recommended especially for a chimney draft around and above 20Pa. -
Page 5: Safe Distances
Please pay special attention when handling the ashpan and when removing hot ash due to danger of burns! The hot ash must not get in contact with flammable objects -e.g. when throwing in communal waste containers. When the fireplace stove is used only seasonally and with unfavourable draught or weather conditions, special attention must be paid when putting the stove into operation. -
Page 6: Chimney Fire Prevention Measures
3.3 Chimney fire prevention measures: Ordinary operation, especially with humid fuel, leads to the settling of ash and tar in the chimney. Neglecting regular checking and cleaning of the chimney in accordance with Building Regulations increases the danger of fire. We recommend that the chimney should be swept twice a year. -
Page 7: Operation Manual
PLEASE NOTE: SOME APPLIANCES ARE FITTED WITH A SMOKE SHUTTER/DAMPER FITTED WITHIN THE NECK OF THE APPLIANCE, IF USED TO CONTROL EXCESSIVE FLUE DRAUGHT THE POSITION TO ACHIEVE THE CORRECT FLUE DRAUGHT SHOULD BE NOTED AND NOT EXCEEDED WHEN IN NORMAL OPERATION AS THIS WILL RESULT IN PERMANENT DAMAGE TO THE APPLIANCE. -
Page 8: Kindling And Firing
5.3 Kindling and firing Fireplace stoves with grate - first put crumpled paper into the chamber and then lay chopped wood in it. You can also use an appropriate suitable fire-lighter to start the fire. After starting fire, let it burn freely with all air regulation elements open. It is forbidden to use flammable liquid (oil, petroleum, etc.) for starting fire! After the fire begins to burn and the draught is strong enough, bigger logs or wood briquettes might be added without the danger of smoke. -
Page 9: Cleaning The Glass
Store the ash in closed non-flammable containers. Warning: Make sure that the ash does not contain any glowing remains of wood that could cause fire in the waste container. Be careful when removing hot ash! 5.7 Cleaning the glass The cleanliness of the window is influenced not only by the using of suitable fuel, providing sufficient air intake and chimney draft but also by the method of operating the fireplace stove. -
Page 10: Warranty Information
Any claims during the warranty period should be directed to the dealer who sold the stove. All stoves from Docherty Group come with their own individual serial number this can be found on the data plate affixed to the appliance. This may be located either on the back of the stove or within the storage area beneath the stove. -
Page 11: Technical Information
8. Technical information Nominal output 5.9 kW Regulated output 3 - 8 kW Efficiency 83.6% Weight 152kg Flue outlet 150mm H 1049 x Dimensions (mm) W 628 x D 398 Average wood consumption (kg/h) 1.64 Max. allowed wood batch (kg/h) 1/3 of the The greatest height of the filling firebox... -
Page 12: Transfer Protocol
Simply visit our website at www.docherty.co.uk and complete the warranty registration form www.docherty.co.uk/stove-warranty-registration Alternatively, you can fill out the form below and post it back to Docherty Group Warranty registration form 55 Woodburn Road, Birmingham, B66 2PU Please return to Docherty Group...
