TACTICALELECTRONICS.COM
PRODUCTS / EOD TRAINING / R & D / AVIATION
DESIGN / ENGINEERING / MANUFACTURING
UDC 360
UNDER DOOR 4-CAMERA SYSTEM
HEMLOCK
FACILITY
2200 NORTH HEMLOCK AVE / BROKEN ARROW, OK / 74012
V: 866.541.7996 / V: 918.249.8326 / F: 918.249.8328
TACTICAL ELECTRONICS
SUPPORT PUBLICATION
CRUSADER
FACILITY
2844 CRUSADER CIRCLE / #100 / VIRGINIA BEACH, VA / 23453
V: 757.689.0476 / F: 757.689.3769
Products
OPERATION AND
PROPRIETARY

Advertisement

loading
Need help?

Need help?

Do you have a question about the UDC 360 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tactical Electronics UDC 360

  • Page 1 UDC 360 UNDER DOOR 4-CAMERA SYSTEM TACTICAL ELECTRONICS Products OPERATION AND SUPPORT PUBLICATION PROPRIETARY TACTICALELECTRONICS.COM HEMLOCK FACILITY CRUSADER FACILITY PRODUCTS / EOD TRAINING / R & D / AVIATION 2200 NORTH HEMLOCK AVE / BROKEN ARROW, OK / 74012 2844 CRUSADER CIRCLE / #100 / VIRGINIA BEACH, VA / 23453 DESIGN / ENGINEERING / MANUFACTURING V: 866.541.7996 / V: 918.249.8326 / F: 918.249.8328...
  • Page 2 PROPRIETARY...

  • Page 3: Table Of Contents

    UDC 360 UNDER DOOR 4-CAMERA SYSTEM Manual Contents Kit Identification Power-up Operation Monitoring Options 10-15 Specifications...

  • Page 4: Kit Identification

    UDC 360 KIT IDENTIFICATION OPERATION AND SUPPORT PUBLICATION One) Under Door Camera 360 (4-camera system) » Four cameras: forward, upward, left, and right facing cameras » Internal mini DVR with SD card recording capabilities » 16GB SD card » Four 0.005 lux black & white CCD chip at the distal end of insertion panel »...

  • Page 5: Power-Up

    OPERATION AND SUPPORT PUBLICATION • The UDC 360 Under Door Camera is powered by four 3Volt Photo Lithium batteries. Most manufacturers of these cells designate them as size 123 or CR123A. Tactical Electronics systems draw high current; use only GE SANYO, ENERGIZER, or DURACELL batteries.

  • Page 6: Operation

    » Insertion Panel: The distal tip of the UDC 360 houses both the forward and upward camera lenses, the IR flood illuminator, and the microphone. The 0.005 lux camera chip is located in the tip of the insertion panel and slides into the room when the panel is placed underneath a door.
  • Page 7 • Shown left is the UDC 360 Outgoing Channel selector. The UDC 360 will only transmit on channels 1-4. If a channel outside this range is selected the UDC 360 will not transmit.
  • Page 8 To attach the Push Pole to the UDC 360 simply place the magnetic ball onto the mount located on top of the UDC 360. Once the Push Pole is attached the user is capable of placing the UDC 360 on target and maneuver via the Push Pole.
  • Page 9 UDC 360 OPERATION OPERATION AND SUPPORT PUBLICATION » SD Card Recording: Insert the SD card into the SD card slot with the UDC 360 powered OFF. DO NOT insert or eject the SD card with the UDC 360 powered ON; otherwise, recorded video files will not finalize and will become corrupted.

  • Page 10: Monitoring Options

    MONITOR OPTIONS OPERATION AND SUPPORT PUBLICATION • Tactical Electronics video systems are designed to operate interchangeably with each wireless monitor: Wrist Mounted Monitor (WMM), Handheld Monitor (HHM), Monocular Micro Viewer (MMV), Heads-Up Display (HUD), Wrist Mounted Monitor Pro (WMM Pro), or Handheld Monitor Pro (HHM Pro).
  • Page 11 Handheld Monitor to the camera system (if hard- wire option is available with the camera system). A hard-wire connection provides a slightly brighter picture on the Handheld Monitor that will be beneficial for low light situations. Tactical Electronics & Military Supply...
  • Page 12 Since the initial press of the channel button resets the shutdown timer and displays the current channel, it is necessary to press the channel button more than once to change channels. Tactical Electronics & Military Supply...
  • Page 13 Note: The first press of the channel selector button will display channel selector which channel the HUD is receiving as well as current battery power. To change the channel press the channel selector button Tactical Electronics & Military Supply again within three seconds.
  • Page 14 To determine a camera’s channel frequency, simply cycle through each of the four channels until a picture is displayed on screen. NOTE: Slight adjustments in your viewing angle can greatly affect the quality of the picture. Tactical Electronics & Military Supply...
  • Page 15 HHM Pro to the camera system (if hard-wire option is available with the camera system). A hard-wire connection provides a slightly brighter picture on the monitor that will be beneficial for low light situations. Tactical Electronics & Military Supply...

  • Page 16: Specifications

    RECORDING CAPACITY: 16 hours on 16GB SD card (1GB/hour) ©2013 Tactical Electronics and Military Supply, L.L.C. All Rights Reserved. Product specifications and information are subject to change without notice. If you encounter any problems with your system, please contact us immediately: Tactical Electronics P.O.
