Summary of Contents for Trasam DAC2
- Page 1 DAC2 HiFi Asynchronous Digital-to-Analog Converter Owner’s Manual...
-
Page 2: Table Of Contents
Contents Controls………………………………………………………...3 Operation……………………………………………………..4 Input mode Volume Pair/Mute Button Indicator Connections…………………………………………………..5 Connecting main power Connecting earphone Connecting amplifier Connecting PC…………………………………………………5 Connecting PC via USB Connecting PC via Optical or Coaxial Connecting PC via Bluetooth Connecting a CD player……………………………………….6 Connecting a mobile phone…………………………………..7 Bluetooth operation…………………………………………..7 Features………………………………………………………..7 Specifications………………………………………………….8... -
Page 3: Controls
Controls 【Front Panel】 【Rear Panel】... -
Page 4: Operation
Flashing Bluetooth pairing Slow flashing Bluetooth reconnecting Fast flashing Connections Connecting main power 1. Be sure that the DAC2 power switch is in the OFF position. 2. Connect the power cord to the DAC2 and plug it into the 220/110V... -
Page 5: Connections
4. Turn the volume at the lowest level before turning on the power. Connecting amplifier 1. Be sure that the power switches of both DAC2 and amplifier are in the OFF position. 2. Turn the volume at the lowest level for both devices. -
Page 6: Connecting A Cd Player
4. Be sure the player’s digital output is enabled, and select “ Stereo” sound channel. 5. The blue indicator light of DAC2 will be on when playing a disc. Connecting a mobile phone 1. Select the DAC2 input mode “ WIRELESS”. -
Page 7: Bluetooth Operation
1. NO pairing required for second use. 2. Turn on the Bluetooth of your device, select input mode “WIRELESS” of DAC2. Power on the DAC2, it will search and make the same previous connection automatically in 10 seconds. Switch to another new Bluetooth device 1. -
Page 8: Specifications
9. Equipped with CSR BC5 Bluetooth chip, support A2DP protocolV2.1 Specifications Supply Voltage……………………………………220V/110V 50-60Hz Power Consumption……………………………………..13W USB Input………………………………………32K/44.1K/48K/ 16Bit Optical Input…………………………………………..Max 216K/24Bit Coaxial Input…………………………………………..Max 216K/24Bit Load Impedance……………………………………………16-600 Ohm Output Power…………………………………...700mW (32 ohm Load) SNR…………………………………………………...100dB(BW 30K) Max Output Level……………………………………………5.8V RMS Crosstalk………………………………………………100dB(BW 30K) THD+N………………………………………………0.049%(BW 30K) Frequency Response………………………………20HZ-20K +-0.3dB Bluetooth transmission range………………………………………10M...
