08/2012 Original. Trademark Information TE (icon), TE Connectivity (logo), and NG4access are trademarks of Tyco Electronics Corporation. Admonishments Admonishments — in the form of Dangers, Warnings, and Cautions — must be followed at all times. These warnings are flagged by use of the triangular alert icon, shown below.
TECP-90-703 • Issue 1 • 8/2012 • Access trays can also be loaded with cabled modules that snap into position. Each cabled module is pre-terminated with 24 LC or 12 SC adapter/connectors and fibers. Snap-in MPO and VAM modules are also available.
TECP-90-703 • Issue 1 • 8/2012 • Guide Strip—provides cable management for fibers routed into the chassis on the front or rear of the frame. 3 GROUNDING AND BONDING THE CHASSIS The standard chassis uses thread-forming mounting screws to provide an electrical path between the chassis and the metalwork in which it is mounted.
Page 5
TECP-90-703 • Issue 1 • 8/2012 3. Install guide strips (provided) on front and rear of chassis. To install a strip, align the tabs on the strip with the slots on the chassis as shown in rear view in Figure 3, then press the radius limiters into place as shown.
TECP-90-703 • Issue 1 • 8/2012 5 DOOR INSTALLATION AND OPERATION The standard chassis is equipped with a separately packed door that when installed protects the access trays when the chassis is not being accessed. To install the door: 1. Position the door at a 90 degree angle with respect to the chassis to align the tabs with the...
TECP-90-703 Publication Number: Contents herein are current as of the date of publication. TE reserves the right to change the contents without prior notice. In no event shall TE be liable for any damages resulting from loss of data, loss of use, or loss of profits and TE further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
