IR Bullet Camera User Manual
The product image shown above may differ from the actual product.
Please use this camera with a DVR which supports HD video recording.
FEATURES
1.
1/2.7" CMOS Sensor
2.
1080P video output
3.
Low light sensitivity of 0.1 Lux / F1.8, 0Lux (IR LED ON)
4.
Day and night 24-hour surveillance with IR effective distance up to 15 meters
5.
IP66 for weather-proof application
PACKAGE CONTENT
IR camera
User manual
SPECIFICATIONS*
Pick-up Element
Number of Pixels
Video Frame Rate
Min. Illumination
S/N Ratio
Shutter Speed
Lens
Lens Angle
IR LED
IR Effective Distance
IR Shift
Day & Night Mode
IRIS Mode
White Balance
AGC
Sharpness
Flickerless
BLC
IP Rating
Operating Temperature
Video Output
Power Source (±10%)
Current Consumption (±10%)
* The specifications are subject to change without notice.
Please read the instructions thoroughly before using the product.
Sun shield
AUTO / USER / PUSH / 8000K / 6000K / 4200K / 3200K
Installation Sticker
1/ 2.7" CMOS image sensor
1930(H) x 1088(V)
1080P@30fps / 1080P@25fps
0.1 Lux / F1.8, 0 Lux (IR LED ON)
More than 48dB (AGC OFF)
1/30 (1/25) sec ~ 1/720000 (1/600000) sec
f3.6mm / F1.8
96° (Horizontal) / 50° (Vertical) / 116° (Diagonal)
12 units
Up to 15 meters
YES
YES
AES
Adjustable
Adjustable
50HZ / 60HZ / OFF
Adjustable
IP66
-20℃ ~ 40℃
1.0 Vp-p composite, 75Ω
DC12V / 0.5A
200mA
681z
Accessories
d105a_V1.0
Advertisement
Table of Contents
Summary of Contents for AGI Security VC-CA-HTTR831
- Page 1 681z IR Bullet Camera User Manual The product image shown above may differ from the actual product. Please use this camera with a DVR which supports HD video recording. Please read the instructions thoroughly before using the product. FEATURES 1/2.7” CMOS Sensor 1080P video output Low light sensitivity of 0.1 Lux / F1.8, 0Lux (IR LED ON) Day and night 24-hour surveillance with IR effective distance up to 15 meters...
- Page 2 INSTALLATION Step1: Find the supplied installation sticker, and paste it to where you want to install. Then, screw holes as marked on the sticker for installation later. Step2: Loosen the screw as indicated below to move down the camera lens. Then, fasten the camera to the ceiling or wall.
- Page 3 CAMERA PARAMETERS This camera series has its own configuration menu, and either of the two methods below is available to access the menu based on the camera model you have. NOTE: The methods below are available only when the camera is used with our brand’s HD CCTV DVR.
- Page 4 MENU DESCRIPTION 1 ~ 5 Set the level of Auto Gain Control to automatically adjust the image when the light level changes. ON / OFF Enable or disable Lens Shading Correction to correct the phenomenon of vignetting when the focal length is short. SPECIAL PRIVACY AREA SEL.
