Uponor Smatrix Wave PLUS
U@home R-167
Installation and operation manual
Help and tutorial

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smatrix Wave Plus U@home R-167 and is the answer not in the manual?

Questions and answers

Related Manuals for Uponor Smatrix Wave Plus U@home R-167

Summary of Contents for Uponor Smatrix Wave Plus U@home R-167

  • Page 1 Uponor Smatrix Wave PLUS U@home R-167 Installation and operation manual Help and tutorial...

  • Page 2: Table Of Contents

    Cisco in the U.S. and other countries and is used under license. App Store is a service mark of Apple Inc. Google, Android and other marks are trademarks of Google Inc. 2 l Uponor Smatrix Wave PLUS U@home R-167...

  • Page 3: Installation And Configuration

    O P E R AT I O N M A N U A L Please see further instructions in the Uponor Smatrix Wave PLUS manual. 03 | 2015 Uponor Smatrix Wave PLUS U@home R-167 – Installation and confi guration l 3...
  • Page 4 Go to the main menu in the interface I-167 and then to “Preferences”, “RF Link” and “Link U@home module”. You will receive a visual confirmation when the linking procedure is complete. 4 l Uponor Smatrix Wave PLUS U@home R-167 – Installation and confi guration...

  • Page 5: Create A User Account

    • We recommend that you subscribe to the mailing list if you wish to be informed about updates, the service status or any scheduled maintenance tasks. You will not receive any commercial or non-U@home related emails. Uponor Smatrix Wave PLUS U@home R-167 – Installation and confi guration l 5...
  • Page 6 Once you click on this link, your U@home user account will be activated. • Now you can login by using your email and the chosen password. 6 l Uponor Smatrix Wave PLUS U@home R-167 – Installation and confi guration...

  • Page 7: User Interfaces Of U@Home; Local And Remote

    U@home module installed in your home. If, after logging in to your account, your installation appears as “Remote control disabled”, just click on “Enable communication” to start the remote access service. Uponor Smatrix Wave PLUS U@home R-167 – User interfaces of U@home l 7...

  • Page 8: U@Home Web Access (Remote)

    Select the installation you would like to control (if you have more than one) and click “Go”. A new window will open showing the U@home web access home page. 8 l Uponor Smatrix Wave PLUS U@home R-167 – U@home web access...

  • Page 9: Basic Use Of The Web Access Function

    Please check with your supplier how best to save energy in “Away” mode. More information about “Home” and “Away” modes can be viewed in the section “Home/Away”. Uponor Smatrix Wave PLUS U@home R-167 – U@home web access l 9...
  • Page 10 For more information, please see the section “Trends and Utilization factor”. Alarm list. Click here to see a list of active alarms in this room. 10 l Uponor Smatrix Wave PLUS U@home R-167 – U@home web access...

  • Page 11: Home/Away" Function

    To set a common “ECO” setback, go to “System Settings” and change the value by clicking on the “plus” and minus buttons. Press “OK” once you have selected the desired value. Uponor Smatrix Wave PLUS U@home R-167 – U@home web access l 11...
  • Page 12 If you plan to be away from home for several days, you can switch your installation to “Away” mode in order to save energy. This is easily done by clicking “Away” on the home page: 12 l Uponor Smatrix Wave PLUS U@home R-167 – U@home web access...
  • Page 13 “Away” mode: While you are in “Away” mode, this is indicated on each room page by the “ECO” sign: Uponor Smatrix Wave PLUS U@home R-167 – U@home web access l 13...

  • Page 14: Use Of The Setpoint

    (upper half of the circle) is shown in grey, the “plus” and “minus” buttons are not shown in the lower half and the “thermostat” icon is active (blue). 14 l Uponor Smatrix Wave PLUS U@home R-167 – U@home web access...
  • Page 15 “Room settings”. To change the setpoint value with digital thermostats and analogue thermostats in “Override thermostat mode”, click on the buttons to set a new value: Uponor Smatrix Wave PLUS U@home R-167 – U@home web access l 15...
  • Page 16 If the colour is light, it means that heating or cooling will stop until room temperature decreases or increases respectively. Heating needed (dark orange) Heating not needed (light orange) 16 l Uponor Smatrix Wave PLUS U@home R-167 – U@home web access...

  • Page 17: Alarms

    • By clicking on the room alarm list option, from the room page. If you are unable to find this shortcut, please see section “Basic use of U@home”. Uponor Smatrix Wave PLUS U@home R-167 – U@home web access l 17...
  • Page 18 The alarm is automatically deactivated if temperatures increase a number of degrees over the limit (hysteresis). An email can optionally be sent if this alarm happens. 18 l Uponor Smatrix Wave PLUS U@home R-167 – U@home web access...
  • Page 19 (ISP) has interrupted the service or an incorrect router setup. In order to activate such alarm notifications you need to tick the following checkbox during registration (see “Create a user account”). Uponor Smatrix Wave PLUS U@home R-167 – U@home web access l 19...
  • Page 20 This timeout can be adjusted by clicking in Actions > Edit. Then select the desired timeout or “off” to disable this alarm. Click on “Save”. 20 l Uponor Smatrix Wave PLUS U@home R-167 – U@home web access...

  • Page 21: Trends And Utilization Factor

    Please contact your installer to check the utilization factor results and improve the energy efficiency of your installation. Uponor Smatrix Wave PLUS U@home R-167 – U@home web access l 21...

  • Page 22: Humidity Control

    • Current Relative Humidity (RH) value measured in the room • Activation/deactivation of humidity control • Humidity setpoint • Humidity deadzone Please check the Uponor Smatrix Wave PLUS manual to learn how these functions work. 22 l Uponor Smatrix Wave PLUS U@home R-167 – U@home web access...

  • Page 23: Eco" Profiles

    (“ECO” off). This option is available from “Room settings”. Please note that the custom profile is not selectable from U@home. It can only be selected from the interface I-167. Uponor Smatrix Wave PLUS U@home R-167 – U@home web access l 23...

  • Page 24: Average Room Temperature

    In order to exclude one room in particular from the average calculation, go to “Room settings”. 24 l Uponor Smatrix Wave PLUS U@home R-167 – U@home web access...

  • Page 25: Apply Modifications To The Installation

    Next, the old device is removed by clicking on “Show extra options” and “Remove installation”. Confirm. Note that the new owner cannot add the device to his/her account until the previous owner has completed this step. Uponor Smatrix Wave PLUS U@home R-167 – U@home web access l 25...

  • Page 26: Change Of Password

    Please check the “Create a user account” section. During registration, no device credentials will be requested in this case. 26 l Uponor Smatrix Wave PLUS U@home R-167 – U@home web access...

  • Page 27: Smartphone/Tablet Apps

    Note: If the GPS location is disabled in Android devices during configuration, the weather information will not be able to be accessed and therefore will not be shown in the app. Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps l 27...
  • Page 28 If more than one device are detected in your local network, the app will show a list with all existing devices in your network and their serial numbers. Please choose the correct one. 28 l Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps...

  • Page 29: Basic Use Of Apps; "Home" And "Away" Modes

    If you rotate the iPad or tablet and place it in vertical position, the view is the same as for smartphones (shown above). Swipe the different screens to reach the room you would like to monitor or control. Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps l 29...
  • Page 30 More information about this can be found in the section “Trends and Utilization factor”. Room temperature. Current measured value. Alarm list. Tap here to see a list of active alarms in this room. 30 l Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps...

  • Page 31: Home/Away" Function

    Just tap on the “Room Settings” icon of the room you would like to change and set a new value by pressing the “plus” and “minus” buttons. Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps l 31...
  • Page 32 “Away” mode. In order to do this, just press and drag the man back into the house. While you are in “Away” mode, this will be indicated on each room page by the “ECO” sign. 32 l Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps...

  • Page 33: Use Of Setpoints

    The “thermostat” icon is greyed out and the knob is shown in orange if the system is in heating mode or blue if the system is in cooling mode. Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps l 33...
  • Page 34 High heating demand Lower heating demand Heating not needed (darker orange) (medium orange) (light orange) 34 l Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps...

  • Page 35: Alarms

    Technical alarm. There are failures in your UFH system. Please call a professional installer to check your installation as soon as possible. RH limit. Condensation protection is active, and cooling has stopped in this room. Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps l 35...
  • Page 36 The room alarm list shows the status of all alarms. Icons No alarm active. New alarm active. Tap here to acknowledge alarm. Then the icon becomes orange. Active alarm which has been acknowledged. 36 l Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps...

  • Page 37: Alarm Settings

    • “Connection to server lost” timeout. This alarm is triggered some time after the server loses the connection with the U@home module. This delay can be configured here. Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps l 37...

  • Page 38: Trends And Utilization Factor

    The current room is highlighted in blue. This indicates the percentage of time that heating or cooling is on (actuator open). High percentages normally indicate lower energy efficiency. 38 l Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps...

  • Page 39: Humidity Control

    • By pressing the “RH options” you can set: – Humidity setpoint. – Humidity deadzone. – Dehumidifier control: Yes/No Please check the “Uponor Smatrix Wave PLUS” manual to learn how these functions work. Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps l 39...

  • Page 40: Eco" Profiles

    U@home. It can only be selected from the interface I-167. Please select an “ECO” profile from the droplist. “No ECO” means that “ECO” profiles will be disabled for this room. 40 l Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps...

  • Page 41: Average Room Temperature

    In order to exclude one room in particular from the average calculation, go to “Room settings”. Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps l 41...

  • Page 42: Apply Modifications To The Installation

    “yes” button, you will be requested to enter a configuration process will start again as described in section descriptive name of your choice. This will help you to identify “Configuration of the apps”. 42 l Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps...

  • Page 43: Remove U@Home Modules From The App

    If you change your device password, you will also need to reset your device configuration by removing the old installation from the app and adding a new one with the correct credentials. Uponor Smatrix Wave PLUS U@home R-167 – Smartphone/tablet apps l 43...

  • Page 44: U@Home Discovery Tool; Local Access

    The U@home module must be powered and connected to Your U@home module will be found and identified. your router. The PC that is running the discovery tool must also be connected to the same router. 44 l Uponor Smatrix Wave PLUS U@home R-167 – U@home Discovery Tool...

  • Page 45: Access From Other Devices

    Several numbers separated by dots will be shown in a pop-up window. Copy these numbers and enter them in the web browser you would like to access from. Uponor Smatrix Wave PLUS U@home R-167 – U@home Discovery Tool l 45...
  • Page 46 Notes 46 l Uponor Smatrix Wave PLUS U@home R-167...
  • Page 47 Notes Uponor Smatrix Wave PLUS U@home R-167 l 47...
