Summary of Contents for ADT Pulse NV412A-ADT
- Page 1 ADT Pulse Interactive Solutions ® NV412A-ADT Video Encoder Installation Guide...
-
Page 2: Table Of Contents
Front Panel ......................2 Rear Panel ......................3 INSTALLATION ......................4 Configuring the NV412A-ADT ................. 4 Adding the NV412A-ADT to your ADT Pulse Wireless Network ...... 4 Wall Mounting (Optional) ..................8 APPENDIX A: SPECIFICATIONS ................9 APPENDIX B: REGULATORY APPROVALS ............10 FCC Statement ...................... -
Page 3: Introduction
NV412A-ADT Video Encoder on your ADT Pulse wireless ® system. Overview The NV412A-ADT (hereafter referred to as the video encoder) digitizes video signals and streams digital images directly to the ADT Pulse wireless system. NV412A-ADT Features • Easily installs to the ADT Pulse wireless system •... -
Page 4: Physical Details - Nv412A-Adt
NV412A-ADT Video Encoder Installation Guide Physical Details – NV412A-ADT Front Panel Figure 1: Front Panel Video Out To ensure the best quality video, attach a coaxial terminator to the Video Out connector. Video In Supports a single composite video source. -
Page 5: Rear Panel
NV412A-ADT Video Encoder Installation Guide Rear Panel Figure 2: Rear Panel Ethernet Port Uses a standard Ethernet cable to connect the video encoder to the ADT Pulse Gateway. Power Port The supplied 12VDC power adapter connects to the video encoder’s power supply. -
Page 6: Installation
NV412A-ADT Video Encoder Installation Guide Installation This section provides details of installing and configuring the NV412A-ADT Video Encoder. Configuring the NV412A-ADT The following instructions provide details of configuring the video encoder. 1. Connect the Video Output of the analog camera to the Video In on the video encoder, using a standard video cable with a BNC connector. - Page 7 NV412A-ADT Video Encoder Installation Guide 3. Click the System tab, and then click the Manage Devices button. 4. In the Manage Devices Assistant, click Cameras. ADT Pulse Interactive Solutions ®...
- Page 8 NV412A-ADT Video Encoder Installation Guide 5. Click the picture of the NV412A or select it from the drop-down list, and then click the Continue button. 6. Assign the video encoder a unique camera name in the space provided, and then type the video encoder’s MAC ID in the space provided.
- Page 9 NV412A-ADT Video Encoder Installation Guide 8. Connect the video encoder to the Device LAN port of the Gateway using the Ethernet cable. 9. Connect the power supplies for both the analog camera and the video encoder. 10. Click the Continue button.
-
Page 10: Wall Mounting (Optional)
12. Click Finish after the installation is complete. Wall Mounting (Optional) If desired, you can mount the NV412A-ADT to a wall or other solid surface using the enclosed mounting brackets. 1. Attach the mounting brackets to either side of the NV412A-ADT. -
Page 11: Appendix A: Specifications
NV412A-ADT Video Encoder Installation Guide Appendix A: Specifications Model NV412A-ADT Dimensions 3.5” x 1.2” x 5.5” H x W x D 90mm x 30mm x 140mm Operating Temperature 32°F to 104°F (0°C to 40°C) Storage Temperature 14°F to 140°F (-10° C to 60° C) Video Compression H.264, MPEG4 and MJPEG... -
Page 12: Appendix B: Regulatory Approvals
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. CE Approvals The NV412A-ADT Video Encoder and the Ethernet Video Encoder meet the guidelines of the European Union and comply with the 99/5/EEC and RTTE 99/5EG directives, including the following standards: •...
