INSTALLER AND OWNER GUIDE
Model 850
ELECTRIC HEATER
Fitted with a
(GC No. EF-032-41)
This guide is intended to help you
install and care for your Wonderfire
Premier electric heater. Please read
carefully before installing and using
your heater. However, if further
information is required, our
Wonderfire Premier Technical
Helpline will be pleased to help.
Telephone 0844 8711 554 (National
call rates apply in the United
Kingdom).
In the Republic of Ireland
Telephone 0044 844 8711 554.
Important: Please keep your guide in a safe place for future reference.
©
Baxi Heating U.K. Limited 2010.
Bauhaus
fascia.
5136405/01
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wonderfire 850
Summary of Contents for Wonderfire 850
- Page 1 Bauhaus Fitted with a fascia. (GC No. EF-032-41) This guide is intended to help you install and care for your Wonderfire Premier electric heater. Please read carefully before installing and using your heater. However, if further information is required, our Wonderfire Premier Technical Helpline will be pleased to help.
- Page 2 Warning: Any person who does any unauthorised act in relation to a copyright work may be liable to criminal prosecution and civil claims for damages. Wonderfire Premier, Wood Lane, Erdington, Birmingham B24 9QP www.wonderfire.co.uk Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication ©...
- Page 3 INSTALLER AND OWNER GUIDE Safety First. Wonderfire Premier heaters are CE Approved and designed to meet the appropriate British Standards and Safety Marks. Quality and Excellence. All Wonderfire Premier heaters are manufactured to the highest standards of quality and excellence and are manufactured under a BS EN ISO 9001 quality system accepted by the British Standards Institute.
-
Page 4: Spacer Frame
1.0* An optional spacer frame kit is obtainable either from your heater supplier or direct from Wonderfire Premier Sales. The kit is an 75mm deep spacer kit (Kit number 05801T1). This spacer enables the heater to be flat wall fixed. - Page 5 If the electric cable is damaged, to avoid a hazard it must be replaced by a Wonderfire Premier authorised service agent, or similarly qualified person (See page 20 for contact numbers). All external wiring between the heater and the electrical supply shall comply with current IEE regulations.
- Page 6 INSTALLER AND OWNER GUIDE 3. OPTIONAL SPACER FRAME KIT The following kit is obtainable either from your heater supplier or direct from Wonderfire Premier Sales. Spacer frame kit 05801T1. Contents Quantity (Illustrations are not to scale) 75mm deep Spacer frame...
- Page 7 INSTALLER AND OWNER GUIDE What opening size do you need in the surround or fireplace opening? This heater can be fitted into fireplaces or surrounds where the following dimensions are available. Width 395mm - 450 mm Height 555mm - 590 mm Depth At least 70mm Do you want to fit the heater against a flat wall with the base of the heater...
- Page 8 INSTALLER AND OWNER GUIDE General notes to read before fitting your heater. If fitting the heater onto a reflective or shiny surface such as a hearth we recommend that this surface does not extend further than 300mm from the fixing plane (wall).
- Page 9 INSTALLER AND OWNER GUIDE Fitting the batteries to the Remote Control Handset. The remote control handset uses 2 x 1.5V AAA type batteries. For longer battery life use only alkaline batteries. To install the batteries, slide the cover down on the rear of the handset and remove (See figure 4). The polarity of the batteries is marked on the inside of the battery compartment.
- Page 10 INSTALLER AND OWNER GUIDE The mains cable guides. At the base of the heater you will find two electric cable guides, one each side of the heater. If required, the cable guide on the right hand side (looking from the front of the heater) can be removed and put in the rectangular slot in the centre rear of the heater.
-
Page 11: Wood Screw
INSTALLER AND OWNER GUIDE The heater must be secured into position to prevent it from being tipped over. The following securing options are available: Method A - Securing the heater with Screws. Method B - Securing the heater with Wire. Method C - Securing the heater using the Optional Spacer Frame (kit number 05801T1). -
Page 12: Wall Plug
INSTALLER AND OWNER GUIDE Method B - Securing with wire. This method of securing is recommended where the wall / brickwork is in poor condition or where marble back panels / surrounds are used. Although this section deals with fireplace openings without a spacer, this method of securing the heater it can also be used with the optional spacer frame (See method 1. -
Page 13: Baxi Heating U.k. Limited 2010
INSTALLER AND OWNER GUIDE pull the wire on the right hand side to gather up the excess until the heater is secure. Thread the wire through the remaining small hole to lock the wire and heater in place (See point 4 - figure 9). Method C - Securing with the Optional Spacer Frame. - Page 14 INSTALLER AND OWNER GUIDE Method D - Securing with the clamp. This method of securing cannot be used in conjunction with the optional spacer frame. This is an alternative securing method where fixing to a surround or rear wall proves impractical. 1.
-
Page 15: Baxi Heating U.k. Limited 2010
INSTALLER AND OWNER GUIDE 5. LIGHT SHUTTER ADJUSTMENT The light shutter is an adjustable plate that increases and decreases the appearance of the flames in the flame effect. 1. Switch on the fuel effect. If you are satisfied with the appearance of the flame effect there is no need to adjust the light shutter. - Page 16 INSTALLER AND OWNER GUIDE Fitting the fascia securing magnets. 1. Supplied in the fascia packaging are four magnets. Place the magnets as in figure Fitting the fascia. 1. Remove the fascia from its packaging. 2. Hold the fascia firmly and locate onto the magnets.
- Page 17 INSTALLER AND OWNER GUIDE Figure 17. lamp locations Pressing the ‘Heat 1’ button. This turns the Visualise effect and 675 watt heater on. The indicator lamp will flash amber for approximately five seconds, after this time the lamp will no longer be visible.
- Page 18 INSTALLER AND OWNER GUIDE Press the button a second time. This will turn the 675 watt heater on. The Visualise effect will already be on. The indicator lamp will flash amber for approximately five seconds, after this time the lamp will no longer be visible.
- Page 19 INSTALLER AND OWNER GUIDE 4. I have dark areas in the fuel effect of my heater or the fuel effect is not as bright as it was when new. There is a mirror fitted to the rear of the hood / canopy at the front of the heater and this may need cleaning.
- Page 20 INSTALLER AND OWNER GUIDE 10. WARRANTY AND SERVICE Information for the customer Standard Warranty Terms & Conditions The warranty is for 12 months subject to contract. In the United Kingdom servicing can be carried out either by a heateam service engineer or a suitably qualified person.
- Page 21 INSTALLER AND OWNER GUIDE What this warranty does not cover Repairs to heaters which haven’t been installed properly and as set out in this guide. Faults caused by inadequate supply of electricity. Reimbursement of any third party repair or replacement costs that we haven’t been told about or agreed with you in advance.
- Page 22 INSTALLER AND OWNER GUIDE © Page 22 Baxi Heating U.K. Limited 2010.
- Page 23 Fascia code - Can be found close to the information label (Block Capitals) A LABEL CONTAINING THE FASCIA CODE MAY HAVE BEEN PLACED INSIDE THIS BOX. Brand - Wonderfire Premier Date of Installation Figure 20. © Page 23 Baxi Heating U.K. Limited 2010.
- Page 24 © Baxi Heating U.K. Limited 2010.
