- Page 1 Instruction Manual G-Series Rear View Replacement Mirror Monitor with Navigation and Bluetooth RVS-718-NAVBT Rear View Safety, Inc. © 2015 Reverse With Confidence ™...
- Page 2 Monitor Specifications......32 Troubleshooting......33 Rear View Safety...
- Page 3 NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle.
- Page 4 Rear View Camera System. If you back up while looking only at the monitor, you may cause Rear View Safety...
-
Page 5: Installation
INSTALLATION: • Electric shock or product or disconnected wire may cause a malfunction may occur if this fire. product is installed incorrectly. • While installing the Rear View System be careful with the wire • Use this product within positioning in order to avoid wire the voltage range specified. - Page 6 If you have questions about this product, contact: Rear View Safety 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
- Page 7 Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly.
- Page 8 Do not run the cable over sharp edges, do not kink the cable and keep away from HOT and rotating parts. Fasten all cables and secure all excess cable. Connect camera to the camera extension cable which runs inside the vehicle. Figure 1.2 Rear View Safety...
- Page 9 Wiring After connecting the camera to the “camera cable” the camera should be plugged into AV2 input. Connect the RED 12V power wire to a an ignition power source and the BLACK 12V ground wire to a chassis ground. The GREEN wire is the REVERSE trigger wire. Connect this wire to the vehicle’s backup light circuit to activate the rear-view image whenever the vehicle shifts into reverse.
- Page 10 0.2M space from the car. Accuracy The accuracy of the grid-lines can vary based on how you angle your cam- era. Therefore to conpensate for inaccurancies, you can adjust the grid-lines to your camera angle. Rear View Safety...
- Page 11 FIGURE 1.1 FIGURE 1.2 Reverse With Confidence ™...
- Page 12 FIGURE 2.1 1. RED- Power (+) 2. YELLOW- Video 3. GREEN- Mirror / Normal Imaging 4. WHITE- Audio 5. BLACK- Ground (-) Rear View Safety...
- Page 13 FIGURE 2.2 Reverse With Confidence ™...
-
Page 14: Navigation Functions And Features
The GPS Navigation system uses a satellite signal to display your position on the naviga- tion map. Set your destination, and the system will program the quickest, safest route. Enjoy your trip with navigation features that include realistic onscreen animations, as well as both voice and text site indication. Rear View Safety... -
Page 15: Volume Adjust
1. Map information: The navigation data may not be completely accurate because of changing real time conditions and construction. Please check road status before your trip and always obey all traffic rules. 2. Navigation: The navigation system should be only used as a reference, as the driver may be more familar with the route than the GPS navigator. -
Page 16: Navigation Path
NAVIGATION PATH In the setting menu, click the icon to enter navigation path menu. Use this menu to set a navigation path, or to change the auto start option on or off. Rear View Safety... -
Page 17: Language Setting
LANGUAGE SETTING In the setting menu, click the icon to enter the language menu. Twelve languages are available. GPS INFORMATION Single click the button to enter GPS menu. In this menu you can reset the GPS, or check GPS information. Reverse With Confidence ™... -
Page 18: System Information
SYSTEM INFORMATION Single click the button to access the system information menu. DEFAULT SET Single click to enter the default settings menu. In this menu you can restore your system to default settings. Rear View Safety... -
Page 19: Screen Calibration
SCREEN CALIBRATION Click the to enter the screen calibration menu. Click “ok” to start the screen calibration. Follow the instructions, pressing the screen until the calibration succeeds. Click anywhere on the screen to save the calibration and exit to the main interface. If you do not want to save the calibration, wait 30 seconds to automat- ically exit to the main interface. - Page 20 Do not force the card in. Inserting the card improperly may damage it. Note: Please do not take out the SD/MMC card while using the navigation system. Keep the card out of reach of small children. When removing the card, let it naturally pop out after gently pressing in. Rear View Safety...
- Page 21 Note: Avoid storing the card high in temperatures, humidities, or in direct sunlight. Keep the card away from all liquid and corrosive material. BLUETOOTH SETTING AND INSTRUCTIONS This chapter will explain how to connect a cell phone to your system with Bluetooth. OPERATION METHOD Single click the button in main menu to open the Bluetooth menu as shown...
- Page 22 Play music with Bluetooth through your radio Single click button to open the pair/connect menu as shown below. Rear View Safety...
- Page 23 Search for Bluetooth devices Reverse With Confidence ™...
- Page 24 Single click the button to modify the name of the device. Single click the button to enter the modify PIN menu. Choose your new Pin and choose when you are finished. Rear View Safety...
- Page 25 Single click the “Pairing history” button to display the connection history. Single click the “Search” button to search for Bluetooth devices. Reverse With Confidence ™...
- Page 26 Select your phone, click “Connect”, and input your PIN to connect Bluetooth. The menu shown below will appear if the connection was successful. Notice that icons are now in color and selectable. Rear View Safety...
- Page 27 Single click the button to open the dial pad. Reverse With Confidence ™...
- Page 28 Single click the button to make a call. Use the numbers to dial. When you receive a call, it will display “Calls” and show the phone number. Rear View Safety...
- Page 29 Single click “HANG UP” to refuse the call or click “ANSWER” to answer. When you answer a call, you will be able to hear the other person through the GPS navi- gator, and talk with them through the GPS navigator microphone. Single click the button to switch between the GPS navigator and your phone.
- Page 30 Single click the button to open the call history. Single click the button to open the A2DP. Use this menu to play music. Rear View Safety...
- Page 31 Reverse With Confidence ™...
-
Page 32: Specifications
Screen Size: 4.3” Display Screen: TFT-LCD Display Resolution: 400(H)x234(V) Aspect Ratio: 16:9 Color Depth: 16.7M dithering Pixel Pitch (mm) 0.219x0.219 Power Consumption: Working Voltage: DC12V VIDEO-IN to GPS/DVD Video Input: (Default) Camera to backup camera Signal System: PAL/Auto/NTSC Rear View Safety... - Page 33 No Image On Screen • Do a hard reset, unplug all cables • Verify camera is on correct camera and power cables, leave out for 1 input minute and then re-connect them • Verify cable is connected to • Check to ensure that the monitor connection to the camera is tight •...
-
Page 34: One Year Warranty
OTHERS OR THE UNAUTHORIZED USE OF NONCONFORMING PARTS; THE DAMAGE IS DUE TO NORMAL WEAR AND TEAR, THIS DAMAGE IS DUE TO ABUSE, IMPROPER MAINTENANCE, NEGLECT OR ACCIDENT; OR THE DAMAGE IS DUE TO USE OF THE REAR VIEW SAFETY, INC. SYSTEM AFTER PARTIAL FAILURE OR USE WITH IMPROPER ACCESSORIES. - Page 35 FOR ANY INJURY, LOSS OR DAMAGE, INCIDENTAL OR CONSEQUENTIAL, ARISING OUT OF THE USE OR INTENDED USE OF THE PRODUCT. IN NO EVENT SHALL REAR VIEW SAFETY AND/OR ITS AFFILIATES HAVE ANY LIABILITY FOR ANY LOSSES (WHETHER DIRECT OR INDIRECT, IN...
- Page 36 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. Rear View Safety...
