Solution MVME712M Installation And Use Manual

Transition module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Solution MVME712M Installation And Use Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVME712M and is the answer not in the manual?

Questions and answers

Summary of Contents for Solution MVME712M

  • Page 1 720-565-5995 sales@solusys.com solusys.com  We are a systems integrator and value added reseller of computer hardware System Integration and software primarily focusing on the embedded marketplace. We provide custom turnkey solutions to get your project started quickly. We pride  Consulting ourselves in our agility and ability to engineer complex solutions quickly.

  • Page 2: Installation And Use

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com MVME712M Transition Module Installation and Use VME712MA/IH2 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com...
  • Page 3 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Notice While reasonable efforts have been made to assure the accuracy of this document, Motorola, Inc. assumes no liability resulting from any omissions in this document, or from the use of the information obtained therein. Motorola reserves the right to revise this document and to make changes from time to time in the content hereof without obligation of Motorola to notify any person of such revision or changes.
  • Page 4 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preface This manual, MVME712M Transition Module and P2 Adapter Board Installation and Use, provides general information, hardware preparation, installation instructions, and support information for the MVME712M Transition Module and the P2 Adapter Board.
  • Page 5 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com All Motorola PWBs (printed wiring boards) are manufactured by UL-recognized manufacturers, with a flammability rating of 94V-0. This equipment generates, uses, and can radiate electro- magnetic energy. It may cause or be susceptible to electro-...
  • Page 6 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Safety Summary Safety Depends On You The following general safety precautions must be observed during all phases of operation, service, and repair of this equipment. Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the equipment.

  • Page 7: Table Of Contents

    Serial port 4 clock configuration select header -- J15 .......2-12 SCSI Termination ..................2-13 Preparing the P2 Adapter Board ................2-14 Cables and Connectors.....................2-15 Installing the MVME712M Module and P2 Adapter Board ........2-17 Procedure ......................2-17 Configuration A - Internal SCSI Devices Only ..........2-19 Configuration B - Internal SCSI Devices Only ..........2-21 Configuration B1 - Internal SCSI Devices Only ..........2-23...
  • Page 8 Introduction ....................... 3-1 P2 Adapter Board ...................... 3-2 P2 connector ....................... 3-2 J2 connector ....................... 3-2 J3 connector......................3-7 MVME712M Transition Module ................3-9 J2 connector ....................... 3-9 J3 and J4 connectors..................3-14 SCSI interface connector.................. 3-16 J5 connector...................... 3-18 J6 connector......................
  • Page 9 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com List of Figures Figure 2-1. MVME712M header locations..............2-3 Figure 2-2. Serial port 1 configured as DCE .............2-4 Figure 2-3. Serial port 1 configured as DTE..............2-5 Figure 2-4. Serial port 2 configured as DCE .............2-6 Figure 2-5.
  • Page 10 Table 2-2. VMEmodule headers/switches ...............2-12 Table 2-3. Cables and connectors ................2-15 Table 2-4. Cabling configurations................2-18 Table 3-1. P2 adapter board and MVME712M connectors ........3-1 Table 3-2. Connector J2 interconnect signals ............3-2 Table 3-3. Connector J3 interconnect signals ............3-7 Table 3-4. Connector J2 interconnect signals ............3-9 Table 3-5.

  • Page 11: Introduction

    EIA-232-D DTE or DCE through jumper arrangements on the MVME712M. The MVME712M front panel also has an Ethernet port, a SCSI port, and a printer port. In addition, the MVME712M routes the EIA-232-D port 2 signals to an internal modem.

  • Page 12: Mvme712M Transition Module

    Radio Frequency Interference (RFI) protection on front panel Electrostatic Discharge (ESD) protection on front panel P2 Adapter Board The MVME712M requires the use of the P2 adapter board. The features of the P2 adapter board include: A connector that permits SCSI cable connection to other SCSI...

  • Page 13: Specifications

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Specifications Specifications The following table lists the general specifications for the MVME712M Transition Module. The subsequent sections detail cooling requirements and FCC compliance. A complete functional description of the MVME712M appears in Chapter Table 1-1.

  • Page 14: Cooling Requirements

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com General Information Cooling Requirements Motorola VMEmodules are specified, designed, and tested to operate reliably with an incoming air temperature range from 0 degrees C to 55 degrees C (32 degrees F to 131 degrees F) with forced air cooling.

  • Page 15: Fcc Compliance

    720-565-5995 | info@solusys.com | www.solusys.com FCC Compliance FCC Compliance The MVME712M Transition Module was tested in an FCC-compliant chassis, and meets the requirements for Class A equipment. FCC compliance was achieved under the following conditions: Shielded cables on all external I/O ports...

  • Page 16: Related Documentation

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com General Information Related Documentation The publications listed below are referenced in this document. To purchase manuals you may contact Motorola in these ways: Through your local Motorola sales office By contacting the Literature Center via phone or fax at the numbers listed under Product Literature at MCG’s World Wide Web site,...

  • Page 17: Mcg Customer Services

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com MCG Customer Services MCG Customer Services The Motorola Computer Group Customer Services organization provides numerous services that support the needs of our OEM customers throughout the qualification, development, deployment, and continued service phases of their product life cycles.

  • Page 18: Introduction

    2Preparing and Installing the Hardware Introduction This manual provides hardware preparation and installation instructions for the MVME712M Transition Module and P2 adapter board. Unpacking the Hardware Note If the carton is damaged upon receipt, request that carrier’s agent be present during unpacking and inspection of the equipment.

  • Page 19: Preparing The Mvme712M Module

    Serial ports 1 through 4 can be configured as a modem (DCE) for connection to terminal or configured as a terminal (DTE) for connection to modem. The MVME712M is shipped with the ports configured for DTE operation. The following table lists the serial ports with their corresponding jumper headers.

  • Page 20: Figure 2-1. Mvme712M Header Locations

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing the MVME712M Module MVME 712/M Figure 2-1. MVME712M header locations http://www.mcg.mot.com/literature Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com...

  • Page 21: Serial Port 1 Dce Configuration -- J1 And J11

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing and Installing the Hardware Serial port 1 DCE configuration -- J1 and J11 To configure port 1 for DCE (modem to terminal) operation, install jumpers on headers J1 and remove jumpers on headers J11 as shown below.

  • Page 22: Serial Port 1 Dte Configuration -- J1 And J11

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing the MVME712M Module Serial port 1 DTE configuration -- J1 and J11 To configure port 1 for DTE (terminal to modem) operation, remove jumpers from header J1 and install jumpers on header J11 as shown below.

  • Page 23: Serial Port 2 Dce Configuration -- J16 And J17

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing and Installing the Hardware Serial port 2 DCE configuration -- J16 and J17 To configure port 2 for DCE (modem to terminal) operation, install jumpers on header J16 and remove jumpers from header J17 as shown below.

  • Page 24: Serial Port 2 Dte Configuration -- J16 And J17

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing the MVME712M Module Serial port 2 DTE configuration -- J16 and J17 To configure port 2 for DTE (terminal to modem) operation, remove jumpers from header J16 and install jumpers on header J17 as shown below.

  • Page 25: Serial Port 3 Dce Configuration -- J13 And J14

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing and Installing the Hardware Serial port 3 DCE configuration -- J13 and J14 To configure port 3 for DCE (modem to terminal) operation, install jumpers on header J13 and remove jumpers from header J14 as shown below.

  • Page 26: Serial Port 3 Dte Configuration - J13 And J14

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing the MVME712M Module Serial port 3 DTE configuration - J13 and J14 To configure port 3 for DTE (terminal to modem) operation, remove jumpers from header J13 and install jumpers on header J14 as shown below.

  • Page 27: Serial Port 4 Dce Configuration -- J18 And J19

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing and Installing the Hardware Serial port 4 DCE configuration -- J18 and J19 To configure port 4 for DCE (modem to terminal) operation, install jumpers on header J18 and remove jumpers from header J19 as shown below.

  • Page 28: Serial Port 4 Dte Configuration - J18 And J19

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing the MVME712M Module Serial port 4 DTE configuration - J18 and J19 To configure port 4 for DTE (terminal to modem) operation, remove jumpers from header J18 and install jumpers on header J19 as shown below.

  • Page 29: Figure 2-10. J15 Clock Line Configuration

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing and Installing the Hardware Serial port 4 clock configuration select header -- J15 Serial port 4 can be configured to use clock signals by the TRXC4 and RTXC4 signal lines. Header J15 configurations of the clock lines are...

  • Page 30: Scsi Termination

    You must ensure that the SCSI bus is terminated properly. The P2 adapter and the MVME712M module have sockets for terminating the SCSI lines. Both the P2 adapter and the MVME712M use three 8-pin SIP resistors. Refer to the installation instructions for use of the terminators.

  • Page 31: Preparing The P2 Adapter Board

    SCSI. Figure 2-11 shows the component locations. Refer to the installation instructions in Installing the MVME712M, in this chapter, for use of the terminators. A P2 mounting bracket kit is also furnished for use on some systems.

  • Page 32: Cables And Connectors

    Cables and Connectors Cables and Connectors The MVME712M front panel has four serial ports, one printer port, one SCSI port, and one Ethernet port. The connectors for these ports, the P2 backplane connector, and two modem connectors are described in the following table.
  • Page 33 If you wish to use your own cable for the P2 signals from J2 on the P2 adapter board to J2 on the MVME712M, note that the cable should be kept as short as possible. Any cable over 2.5 to 3 feet is likely to cause signal problems.

  • Page 34: Installing The Mvme712M Module And P2 Adapter Board

    Warning Procedure To begin the installation of the MVME712M in the system, proceed as follows: 1. Turn all equipment power OFF and disconnect the power cable from the AC power source.

  • Page 35: Table 2-4. Cabling Configurations

    (if the chassis has a rear card cage). Other modules in the unit may have to be moved to allow space for the cables connected to the P2 adapter and the MVME712M. 4. Continue the installation procedure by choosing one of the configurations listed in the following table, and described on the following pages.

  • Page 36: Configuration A - Internal Scsi Devices Only

    4. Terminators must be installed on the last SCSI device in the system. 5. Attach the furnished 64-conductor cable from connector J2 on the P2 adapter to connector J2 on the MVME712M. Be sure to orient cable pin 1 with connector pin 1.

  • Page 37: Figure 2-12. Configuration A -- Internal-Only Scsi Connections

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing and Installing the Hardware TERMINATORS SCSI INSTALLED DEVICE SCSI DEVICE MVME712M MVME xxxx 50-CONDUCTOR CABLE 64-CONDUCTOR CABLE P2 ADAPTER TERMINATORS INSTALLED ENCLOSURE BOUNDARY cb2349301A Figure 2-12. Configuration A -- internal-only SCSI connections...

  • Page 38: Configuration B - Internal Scsi Devices Only

    1. The MVMExxxx is at one end of the cable, so terminators must be installed on the P2 adapter module. 2. The MVME712M is at one end of the cable, so terminators must be installed on the MVME712M. 3. Install the P2 adapter module to the backplane directly in line with the P2 connector on the MVMExxxx.

  • Page 39: Figure 2-13. Configuration B -- Internal-Only Scsi Connections

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing and Installing the Hardware SCSI DEVICE SCSI DEVICE MVME712M MVME xxxx P2 ADAPTER 64-CONDUCTOR CABLE TERMINATORS TERMINATORS INSTALLED INSTALLED 50-CONDUCTOR CABLE ENCLOSURE BOUNDARY cb2359301A Figure 2-13. Configuration B -- internal-only SCSI connections...

  • Page 40: Configuration B1 - Internal Scsi Devices Only

    1. The MVMExxxx is not at one end of the cable, so terminators must be removed from the P2 adapter module. 2. The MVME712M is at one end of the cable, so terminators must be installed on the MVME712M. 3. Install the P2 adapter module to the backplane directly in line with the P2 connector on the MVMExxxx.

  • Page 41: Figure 2-14. Configuration B1 -- Internal-Only Scsi Connections

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing and Installing the Hardware TERMINATORS SCSI INSTALLED DEVICE SCSI DEVICE MVME712M MVME xxxx 50-CONDUCTOR CABLE 64-CONDUCTOR CABLE P2 ADAPTER 50-CONDUCTOR CABLE TERMINATORS TERMINATORS INSTALLED REMOVED ENCLOSURE BOUNDARY cb236 9301A Figure 2-14. Configuration B1 -- internal-only SCSI connections...

  • Page 42: Configuration C - Internal And External Scsi Devices

    1. The MVMExxxx is at one end of the cable, so terminators must be installed on the P2 adapter module. 2. The MVME712M is not at one end of the cable, so terminators must be removed from the MVME712M. 3. Install the P2 adapter module to the backplane directly in line with the P2 connector on the MVMExxxx.
  • Page 43 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing and Installing the Hardware power. The fuse on the MVMExxxx is for Ethernet transceiver power. The resistance of each fuse should be less than 1 ohm. 2-26 Computer Group Literature Center Web Site Solution Systems Technologies Inc.

  • Page 44: Figure 2-15. Configuration C -- Internal And External Scsi Connections

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Installing the MVME712M Module and P2 Adapter Board SCSI DEVICE SCSI DEVICE MVME712M MVME xxxx 50-CONDUCTOR P2 ADAPTER CABLE 64-CONDUCTOR CABLE TERMINATORS TERMINATORS REMOVED INSTALLED 50-CONDUCTOR CABLE SCSI DEVICE ENCLOSURE BOUNDARY...

  • Page 45: Configuration C1 - Internal And External Scsi Devices

    1. The MVMExxxx is not at one end of the cable, so terminators must be removed from the P2 adapter module. 2. The MVME712M is not at one end of the cable, so terminators must be removed from the MVME712M.

  • Page 46: Figure 2-16. Configuration C1 -- Internal And External Scsi Connections

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Installing the MVME712M Module and P2 Adapter Board TERMINATORS SCSI INSTALLED DEVICE SCSI DEVICE MVME712M MVME xxxx 50-CONDUCTOR CABLE 64-CONDUCTOR CABLE 50-CONDUCTOR P2 ADAPTER CABLE 50-CONDUCTOR TERMINATORS CABLE TERMINATORS REMOVED REMOVED...

  • Page 47: Configuration D - Internal And External Scsi Devices

    1. The MVMExxxx is not at one end of the cable, so terminators must be removed from the P2 adapter module. 2. The MVME712M is not at one end of the cable, so terminators must be removed from the MVME712M.
  • Page 48 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Installing the MVME712M Module and P2 Adapter Board P2 adapter module is for SCSI terminator power. The fuse on the MVMExxxx is for Ethernet transceiver power. The resistance of each fuse should be less than 1 ohm.

  • Page 49: Figure 2-17. Configuration D -- Internal And External Scsi Connections

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing and Installing the Hardware SCSI DEVICE TERMINATORS INSTALLED SCSI DEVICE SCSI DEVICE MVME712M MVME xxxx USER PROVIDED PANEL 50-CONDUCTOR CABLE 64-CONDUCTOR CABLE 50-CONDUCTOR P2 ADAPTER CABLE 50-CONDUCTOR CABLE TERMINATORS TERMINATORS...

  • Page 50: Configuration E - External Scsi Devices Only

    1. The MVMExxxx is at one end of the cable, so terminators must be installed on the P2 adapter module. 2. The MVME712M is not at one end of the cable, so terminators must be removed from the MVME712M. 3. Install the P2 adapter module to the backplane directly in line with the P2 connector on the MVMExxxx.

  • Page 51: Figure 2-18. Configuration E -- External-Only Scsi Connections

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing and Installing the Hardware MVME712M MVME xxxx 64-CONDUCTOR CABLE 50-CONDUCTOR P2 ADAPTER CABLE 50-CONDUCTOR CABLE TERMINATORS TERMINATORS REMOVED INSTALLED SCSI DEVICE ENCLOSURE BOUNDARY SCSI DEVICE TERMINATORS cb240 9301A INSTALLED Figure 2-18. Configuration E -- external-only SCSI connections...

  • Page 52: Configuration F - External Scsi Devices Only

    1. The MVMExxxx is not at one end of the cable, so terminators must be removed from the P2 adapter module. 2. The MVME712M is not at one end of the cable, so terminators must be removed from the MVME712M.
  • Page 53 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Preparing and Installing the Hardware The fuse on the MVMExxxx is for Ethernet transceiver power. The resistance of each fuse should be less than 1 ohm. 2-36 Computer Group Literature Center Web Site Solution Systems Technologies Inc.

  • Page 54: Figure 2-19. Configuration F -- External-Only Scsi Connections

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Installing the MVME712M Module and P2 Adapter Board SCSI DEVICE TERMINATORS INSTALLED M VM E712M M VM E xxxx USER PROVIDED PANEL 50-CONDUCTOR CABLE 64-CONDUCTOR CABLE 50-CONDUCTOR P2 AD APTER CABLE...

  • Page 55: Introduction

    720-565-5995 | info@solusys.com | www.solusys.com 3Interconnect Signals Introduction This chapter provides the interconnection signals for the MVME712M and P2 adapter board. The connectors described are listed in the following table. All front panel connectors have metal shells and jack posts that are electrically connected to the front panel.

  • Page 56: P2 Adapter Board

    J2 connector Connector J2 on the P2 adapter board and connector J2 on the MVME712M are 64-pin DIN connectors that are the same pin-for-pin. Each pin connection, signal mnemonic, and signal characteristic for these connectors is listed in the following table.
  • Page 57 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com P2 Adapter Board Table 3-2. Connector J2 interconnect signals (Continued) Signal Signal Name and Description Number Mnemonic PRACK* DATA ACKNOWLEDGE (Printer) - a low level input pulse indicating that the next character may be sent.
  • Page 58 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Interconnect Signals Table 3-2. Connector J2 interconnect signals (Continued) Signal Signal Name and Description Number Mnemonic RTS4 REQUEST TO SEND (Serial Port 4) - RTS is supplied by the terminal to the modem when it is required to transmit a message.
  • Page 59 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com P2 Adapter Board Table 3-2. Connector J2 interconnect signals (Continued) Signal Signal Name and Description Number Mnemonic TRANSMIT + (output) (Ethernet) - this line is intended to operate into terminated transmission lines.
  • Page 60 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Interconnect Signals Table 3-2. Connector J2 interconnect signals (Continued) Signal Signal Name and Description Number Mnemonic SIGNAL NUMBER DTR4 DATA TERMINAL READY (Serial Port 4) - a signal from the terminal to the modem indicating that the terminal is ready to send or receive data.

  • Page 61: J3 Connector

    J3 connector Connector J3 on the P2 adapter board and connectors J3 and J4 on the MVME712M module are 50-pin connectors that are the same pin-for-pin. Each pin connection, signal mnemonic, and signal characteristic for these connectors is listed in the following table.
  • Page 62 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Interconnect Signals Table 3-3. Connector J3 interconnect signals (Continued) Signal Signal Name and Description Number Mnemonic 27-31 GROUND ATN* ATTENTION - signal driven by the initiator. Indicates the attention condition. 33-35...

  • Page 63: Mvme712M Transition Module

    MVME712M transition module. J2 connector Connector J2 on the MVME712M and connector J2 on the P2 adapter board are 64-pin DIN connectors that are the same pin-for-pin. Each pin connection, signal mnemonic, and signal characteristic for these connectors is listed in the following table.
  • Page 64 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Interconnect Signals Table 3-4. Connector J2 interconnect signals (Continued) Signal Signal Name and Description Number Mnemonic TXD3 TRANSMIT DATA (Serial Port 3) - data to be transmitted is furnished on this line to the modem from the terminal.
  • Page 65 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com MVME712M Transition Module Table 3-4. Connector J2 interconnect signals (Continued) Signal Signal Name and Description Number Mnemonic CTS4 CLEAR TO SEND (Serial Port 4) - CTS is a function supplied to the terminal by the modem, and indicates that it is permissible to begin transmission of a message.
  • Page 66 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Interconnect Signals Table 3-4. Connector J2 interconnect signals (Continued) Signal Signal Name and Description Number Mnemonic PRD04 DATA (bit 4) (Printer) PRD06 DATA (bit 6) (Printer) C9,C10 GROUND PRPE PAPER EMPTY (Printer) - out of paper.
  • Page 67 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com MVME712M Transition Module Table 3-4. Connector J2 interconnect signals (Continued) Signal Signal Name and Description Number Mnemonic DTR4 DATA TERMINAL READY (Serial Port 4) - a signal from the terminal to the modem indicating that the terminal is ready to send or receive data.

  • Page 68: J3 And J4 Connectors

    Interconnect Signals J3 and J4 connectors Connectors J3 and J4 on the MVME712M module and connector J3 on the P2 adapter board are 50-pin connectors that are the same pin-for-pin. Each pin connection, signal mnemonic, and signal characteristic for these connectors is listed in the following table.
  • Page 69 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com MVME712M Transition Module Table 3-5. Connectors J3 and J4 interconnect signals Signal Signal Name and Description Number Mnemonic 27-31 GROUND ATN* ATTENTION - signal driven by the initiator. Indicates the attention condition.

  • Page 70: Scsi Interface Connector

    SCSI interface connector The SCSI port is the connector labeled SCSI INTERFACE on the front panel of the MVME712M, connected to connector J4 on the top of the board. Each pin connection, signal mnemonic, and signal characteristic for the SCSI port connector is listed in the following table Table 3-6.
  • Page 71 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com MVME712M Transition Module Table 3-6. Connector SCSI interface interconnect signals Signal Signal Name and Description Number Mnemonic MSG* MESSAGE - signal driven by the target during the message phase. SEL* SELECT - signal used by an initiator to select a target or by a target to reselect an initiator.

  • Page 72: J5 Connector

    720-565-5995 | info@solusys.com | www.solusys.com Interconnect Signals J5 connector Connector J5 is the port labeled PRINTER on the MVME712M front panel. This is a Centronics type parallel port. Each pin connection, signal mnemonic, and signal characteristic for the printer port connector is listed in the following table.

  • Page 73: J6 Connector

    720-565-5995 | info@solusys.com | www.solusys.com MVME712M Transition Module J6 connector Connector J6 is the port labeled ETHERNET on the MVME712M front panel. Each pin connection, signal mnemonic, and signal characteristic for the Ethernet port connector is listed in the following table.

  • Page 74: J7 - J10 Connectors

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Interconnect Signals J7 - J10 connectors Connectors J7 through J10 are EIA-232-D 25-pin front panel connectors, labeled SERIAL PORT1/CONSOLE, SERIAL PORT2/TTY01, SERIAL PORT 3, and SERIAL PORT 4. Each pin connection, signal mnemonic, and signal characteristic for the serial port connectors is listed in the following table.

  • Page 75: J20 Connector

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com MVME712M Transition Module Table 3-9. Connectors J7 - J10 interconnect signals Signal Signal Name and Description Number Mnemonic 18-19 Not used. EDTR DATA TERMINAL READY - A signal from the terminal to the modem indicating that the terminal is ready to send or receive data.

  • Page 76: J21 Connector

    Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Interconnect Signals Table 3-10. Connector J20 interconnect signals (Continued) Signal Signal Name and Description Number Mnemonic DTR2 DATA TERMINAL READY - A signal from the terminal to the modem indicating that the terminal is ready to send or receive data.
  • Page 77 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com Index airflow required depth antistatic wrist strap 2-17 description, general documentation, related DTE/DCE configuration select headers bus interface EIA-232-D port cables 2-15 Electrostatic Discharge (ESD) 1-2, 2-17 cautions 2-1, 2-17 EMI and EMC reduction...
  • Page 78 J6 connector signals (MVME712M) 3-19 I/O ports J7-J10 connector signals (MVME712M) installation instructions 2-1, 2-17 3-20 installing the MVME712M and P2 adapter jumper configurations, factory 2-17 interconnect signals 3-1, ETHERNET connector (MVME712M) LEDs, green and yellow 3-19 LEDs, unlit 2-19, 2-21, 2-23, 2-25, 2-28,...
  • Page 79 Solution Systems Technologies Inc. 720-565-5995 | info@solusys.com | www.solusys.com qualification range Radio Frequency Interference (RFI) storage relative humidity terminator power RF emission terminators, SCSI 1-2, 2-13, 2-14, 2-19, 2-21, RFI (see Radio Frequency Interference) 2-23, 2-25, 2-28, 2-30, 2-33, 2-35...
