Digicam Premium DPA-0440L User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DPA-xxxx series

Digital Video Recorder

User Manual

U D . 7 L 0 2 0 2 D 1 6 0 1 B 0 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DPA-0440L and is the answer not in the manual?

Questions and answers

Summary of Contents for Digicam Premium DPA-0440L

  • Page 1: Digital Video Recorder

    DPA-xxxx series Digital Video Recorder User Manual U D . 7 L 0 2 0 2 D 1 6 0 1 B 0 1...
  • Page 2 Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer. This manual is applicable to: DPA-0440L, DPA-0848L DPA-0448M, DPA-16128M DPA-08200M, DPA-16400L This manual may contain several technically incorrect places or printing errors, and the content is subject to change without notice.
  • Page 3 User Manual of DPA-xxxx Series DVR R e g u l a t o r y i n f o r m a t i o n R e g u l a t o r y i n f o r m a t i o n R e g u l a t o r y i n f o r m a t i o n R e g u l a t o r y i n f o r m a t i o n F C C i n f o r m a t i o n...
  • Page 4 User Manual of DPA-xxxx Series DVR t o y o u r s u p p l i e r o r t o a d e s i g n a t e d c o l l e c t i o n p o i n t . F o r m o r e i n f o r m a t i o n s e e : w w w .

  • Page 5: Preventive And Cautionary Tips

    User Manual of DPA-xxxx Series DVR Preventive and Cautionary Tips Before connecting and operating your device, please be advised of the following tips: • Ensure unit is installed in a well-ventilated, dust-free environment. • Unit is designed for indoor use only. •...

  • Page 6: Product Key Features

    User Manual of DPA-xxxx Series DVR Product Key Features General PAL/NTSC adaptive video inputs. H.264 video compression with high reliability and superior definition. Each channel supports dual-stream. Main stream supports encoding at up to WD1 resolution; and sub-stream encoding at CIF/QCIF resolution.
  • Page 7 User Manual of DPA-xxxx Series DVR Smart search for the selected area in the video. Zooming in when playback. Playing reversely. Supports pause, slow forward, fast forward, skip forward, and skip backward when playback, locating by dragging the mouse. Up to 4/8/16-ch synchronous playback. Backup Export video data by USB storage device.

  • Page 8: Table Of Contents

    User Manual of DPA-xxxx Series DVR TABLE OF CONTENTS Product Key Features ......................5 C H A P T E R 1 ........................11 Introduction ..........................11 1.1 Front Panel ......................... 12 1.2 USB Mouse Operation ....................12 1.3 Input Method Description ..................13 1.4 Rear Panel ........................
  • Page 9 User Manual of DPA-xxxx Series DVR 5.6 Configuring Holiday Record ..................56 5.7 Files Protection ......................59 C H A P T E R 6 ........................61 Playback ..........................61 6.1 Playing Back Record Files ..................62 6.1.1 Playing Back by Channel ................62 6.1.2 Playing Back by Time ..................
  • Page 10 User Manual of DPA-xxxx Series DVR 9.3 Checking Network Traffic ..................123 9.4 Network Detection ....................124 9.4.1 Testing Network Delay and Packet Loss ............124 9.4.2 Exporting Network Packet ................124 9.4.3 Checking Network Status ................126 9.4.4 Checking Network Statistics ................. 127 C H A P T E R 10 ........................
  • Page 11 User Manual of DPA-xxxx Series DVR 13.5 Logging out/Shutting down/Rebooting Device ............. 159 C H A P T E R 1 4 ......................... 160 Appendix ..........................160 Glossary ......................... 161 FAQ ..........................162...

  • Page 12: Chapter 1

    User Manual of DPA-xxxx Series DVR C H A P T E R 1 Introduction...

  • Page 13: Front Panel

    T h e f r o n t p a n e l o f D S - 7 1 0 0 H W I / H V I - S L a n d D S - 7 1 0 0 H W I / H V I - S H s e r i e s D V R i s s h o w n i n F i g u r e 1 . 1 : Figure 1.1 Front Panel of DPA-0440L/0848L/08200M/16400L Table 1.1 Description of Indicators...

  • Page 14: Input Method Description

    Table 1.3 Description of the Soft Keyboard Icons Icon Description Icon Description Number English letter … … Lowercase/Uppercase Symbols Backspace Space Enter Exit English input method 1.4 Rear Panel DPA-0440L/0848L/08200M/16400L The rear panel of DPA-0848L is shown below: Figure 1.3 Rear Panel of DPA-0848L/08200M...
  • Page 15 The DPA-0440L p r o v i d e s 4 v i d e o i n p u t i n t e r f a c e s a n d t h e D P A...
  • Page 16 User Manual of DPA-xxxx Series DVR D P A D P A - - - - 1 6 1 2 8 M 1 6 1 2 8 M D P A D P A 1 6 1 2 8 M 1 6 1 2 8 M The rear panel of DPA-16128M is shown below: Figure 1.4 Rear Panel of DPA-16128M...

  • Page 17: Starting Up And Shutting Down The Device

    Uninterruptible Power Supply (UPS) be used in conjunction with the device. For DPA-0440L/0848L/08200M/16400L series DVR, insert the power supply plug into the power connector on the rear panel and the device will start up; and for the DPA-0448M/16128M series DVR, turn on the power switch button on the rear panel after the power supply is connected.
  • Page 18 User Manual of DPA-xxxx Series DVR Figure 1.7 Message Box for Power Off 4. Disconnect the power supply of the device. Rebooting the device In the Shutdown menu (Figure 1.7), you can also click Reboot to reboot the device.

  • Page 19: Chapter 2

    User Manual of DPA-xxxx Series DVR C H A P T E R 2 Getting Started...

  • Page 20: Using The Wizard For Basic Configuration

    User Manual of DPA-xxxx Series DVR 2.1 Using the Wizard for Basic Configuration The Setup Wizard can walk you through some important settings of the device. By default, the Setup Wizard starts once the device has loaded. Operating the Setup Wizard: Steps: You can set the system language after the device is started.
  • Page 21 User Manual of DPA-xxxx Series DVR Figure 2.3 Login Window Click the Next button to enter the Date and Time settings window, as shown in Figure 2.4. Set the time zone, date format, system date and system time. Figure 2.4 Date and Time Settings Click Next button which takes you back to the Network Setup Wizard window, as shown in Figure 2.5.
  • Page 22 User Manual of DPA-xxxx Series DVR Figure 2.5 Network Configuration Click Next button to enter the HDD Management window, shown in Figure 2.6. To initialize the HDD, click the Init button. Initialization removes all the data saved in the HDD. Figure 2.6 HDD Management Click Next button to enter the Record Settings window, as shown in Figure 2.7.

  • Page 23: Menu Operation

    User Manual of DPA-xxxx Series DVR shown in Figure 2.8. Figure 2.8 Copy Record Settings Click OK to return to the Record Settings window. Click OK to complete the startup Setup Wizard. 2.2 Menu Operation After entering the local operation interface of the device, the main menu bar will be displayed on the top of the screen.

  • Page 24: Chapter 3

    User Manual of DPA-xxxx Series DVR C H A P T E R 3 Live View...

  • Page 25: Introduction Of Live View

    User Manual of DPA-xxxx Series DVR 3.1 Introduction of Live View Live view shows you the video image getting from each camera in real time. The device automatically enters Live View mode when powered on. It is also at the very top of the menu hierarchy, thus pressing the ESC many times (depending on which menu you’re on) brings you to the Live View mode.

  • Page 26: Operations In Live View Mode

    User Manual of DPA-xxxx Series DVR 3.2 Operations in Live View Mode In live view mode, the following functions can be realized: • Single Screen: showing only one screen on the monitor. • Multi-screen: showing multiple screens on the monitor simultaneously. •...

  • Page 27: Using An Auxiliary Monitor

    User Manual of DPA-xxxx Series DVR A l l - d a y P l a y b a c k t h e r e c o r d v i d e o . P l a y b a c k S w i t c h t o t h e a u x i l i a r y o u t p u t m o d e a n d t h e o p e r a t i o n f o r t h e m a i n o u t p u t i s d i s a b l e d .

  • Page 28: Quick Setting Toolbar In Live View Mode

    User Manual of DPA-xxxx Series DVR Steps: Use the mouse wheel to double-click on the HDMI/VGA output screen, and the following message box pops up: Figure 3.2 Switch Main and Aux Output Use the mouse wheel to double-click on the screen again to switch to the Aux output, or click Cancel to cancel the operation.

  • Page 29: Instant Playback

    User Manual of DPA-xxxx Series DVR Instant Playback Instant Playback only shows the record in last five minutes. If no record is found, it means there is no record during the last five minutes. Digital Zoom Digital Zoom can zoom in the selected area to the full screen. You can left-click and draw to select the area for zooming in, as shown in Figure 3.4.
  • Page 30 User Manual of DPA-xxxx Series DVR Figure 3.5 Image Settings Adjust the image parameters including the brightness, contrast, saturation, hue, sharpness level and denoising level by moving the sliding bar or increasing/decreasing the value. The adjustable value range is 0~255 for the brightness, contrast, saturation and hue, 0~15 for the sharpness level and 0~5 for the denoising level.

  • Page 31: Adjusting Live View Settings

    User Manual of DPA-xxxx Series DVR 3.3 Adjusting Live View Settings Purpose: Live View settings can be customized according to different needs. You can configure the output interface, dwell time for screen to be shown, mute or turning on the audio, the screen number for each channel, etc. Steps: 1 .
  • Page 32 User Manual of DPA-xxxx Series DVR Figure 3.8 Live View- Camera Order To set the camera order: Click the View tab to enter the camera order settings interface. Select an output interface and select a screen layout. Click to select a screen in the right region and double-click to select a channel in the left region. Thus the selected channel will be displayed in the corresponding screen.

  • Page 33: Channel-Zero Encoding

    User Manual of DPA-xxxx Series DVR 3.4 Channel-zero Encoding Purpose: S o m e t i m e s y o u n e e d t o g e t a r e m o t e v i e w o f m a n y c h a n n e l s i n r e a l t i m e f r o m w e b b r o w s e r o r C M S ( C l i e n t M a n a g e m e n t S y s t e m ) s o f t w a r e , i n o r d e r t o d e c r e a s e t h e b a n d w i d t h r e q u i r e m e n t w i t h o u t a f f e c t i n g t h e i m a g e q u a l i t y , c h a n n e l - z e r o e n c o d i n g i s s u p p o r t e d a s a n o p t i o n f o r y o u .

  • Page 34: User Logout

    User Manual of DPA-xxxx Series DVR 3.5 User Logout P u r p o s e : P u r p o s e : P u r p o s e : P u r p o s e : A f t e r l o g g i n g o u t , t h e m o n i t o r t u r n s t o t h e l i v e v i e w m o d e a n d i f y o u w a n t t o d o s o m e o p e r a t i o n , y o u n e e d t o e n t e r u s e r n a m e a n d p a s s w o r d t o l o g i n a g a i n .

  • Page 35: Chapter 4

    User Manual of DPA-xxxx Series DVR C H A P T E R 4 PTZ Controls...

  • Page 36: Configuring Ptz Settings

    User Manual of DPA-xxxx Series DVR 4.1 Configuring PTZ Settings The PTZ function is provided by the DPA-0448M/16128M model only. Purpose: Follow the procedure to set the parameters for PTZ. The configuring of the PTZ parameters should be done before you control the PTZ camera. Before you start: Check that the PTZ and the device are connected properly through RS-485 interface.

  • Page 37: Setting Ptz Presets, Patrols & Patterns

    User Manual of DPA-xxxx Series DVR 4.2 Setting PTZ Presets, Patrols & Patterns Before you start: Please make sure that the presets, patrols and patterns should be supported by PTZ protocols. 4.2.1 Customizing Presets Purpose: Follow the steps to set the Preset location which you want the PTZ camera to point to when an event takes place.

  • Page 38: Calling Presets

    User Manual of DPA-xxxx Series DVR 4.2.2 Calling Presets Purpose: The view angle of the PTZ camera will be moved to the predefined position when you call a preset. Call a preset on the PTZ setting interface: Steps: 1. Enter the PTZ Control interface. Menu>...

  • Page 39: Customizing Patrols

    User Manual of DPA-xxxx Series DVR 2. Click the Camera tab on the panel, and select the channel for control on the camera list. 3. Click the Preset tab on the panel, and double-click the preset you want to call on the preset list. 4.2.3 Customizing Patrols Purpose: A patrol is a scanning track specified by a group of user-defined key points, with the scanning speed between...

  • Page 40: Calling Patrols

    User Manual of DPA-xxxx Series DVR R e p e a t t h e a b o v e s t e p s t o a d d m o r e k e y p o i n t s . Y o u c a n a l s o c l i c k t o d e l e t e t h e c o r r e s p o n d i n g k e y p o i n t a n d c l i c k t o d e l e t e a l l t h e...

  • Page 41: Customizing Patterns

    User Manual of DPA-xxxx Series DVR Figure 4.10 PTZ Panel- Patrol 4.2.5 Customizing Patterns Purpose: A pattern is a memorized, repeating series of pan, tilt, zoom, and preset functions. Steps: 1. Enter the PTZ Control interface. Menu>Camera>PTZ>More Settings 2. Choose pattern number in the option box. Figure 4.11 PTZ- Pattern 3.

  • Page 42: Calling Patterns

    User Manual of DPA-xxxx Series DVR Repeat the above steps to save more patterns. 4.2.6 Calling Patterns Purpose: The PTZ camera will move according to the predefined pattern path when you call a pattern. Call a pattern in the PTZ setting interface Steps: 1.
  • Page 43 User Manual of DPA-xxxx Series DVR Control icon to enter the PTZ toolbar. Figure 4.14 PTZ Toolbar Table 4.1 Description of the PTZ toolbar icons Icon Description Icon Description Icon Description Direction button Zoom+, Focus+, Zoom-, Focus-, and auto-cycle Iris+ Iris- button Speed bar of...

  • Page 44: Chapter 5

    User Manual of DPA-xxxx Series DVR C H A P T E R 5 Record Settings...

  • Page 45: Configuring Encoding Parameters

    User Manual of DPA-xxxx Series DVR 5.1 Configuring Encoding Parameters Purpose: By configuring the encoding parameters you can define the transmission stream type, the resolution and so on. Before you start: 1. Make sure that the HDD has already been installed. If not, please install a HDD and initialize it. (Menu>HDD>General) Figure 5.1 HDD- General 2.
  • Page 46 User Manual of DPA-xxxx Series DVR Select the camera for configuration. Configure the following parameters for the Main Stream (Normal) and the Main Stream (Event): • Stream Type: Set the stream type to be Video or Video & Audio. • Resolution: Set recording at resolution of WD1, 4CIF, 2CIF, CIF or QCIF.

  • Page 47: Configuring Record Schedule

    User Manual of DPA-xxxx Series DVR Figure 5.5 Encoding Parameters-Sub-stream Configure the parameters for the sub-stream. Refer to the steps of main stream settings. Click Apply to save the settings. You can click the Restore button to restore the current sub-stream settings to the default parameters.
  • Page 48 4) Set the Type in the dropdown list. Different recording types are available for different models. DPA-0440L/0848L/08200M/16400L: Normal and Motion. DPA-0448M/16128M: Normal, Motion, Alarm, Motion/Alarm and Motion & Alarm. To enable Motion triggered recording, you must configure the motion detection settings as well. For detailed information, refer to Chapter 8.1 and Chapter 8.2.
  • Page 49 1) Click the icon on the right to select a record type. Set the Type in the dropdown list. Different recording types are available for different models. DPA-0440L/0848L/08200M/16400L: Normal and Motion. DPA-0448M/16128M: Normal, Motion, Alarm, Motion/Alarm and Motion & Alarm.
  • Page 50 User Manual of DPA-xxxx Series DVR 3) You can repeat the above steps to set schedule for other channels. If the settings can also be used to other channels, click Copy to enter the Copy Camera interface and then choose the channel to which you want to copy.

  • Page 51: Configuring Motion Detection Record

    User Manual of DPA-xxxx Series DVR 5.3 Configuring Motion Detection Record Purpose: Follow the steps to set the motion detection parameters. In the live view mode, once a motion detection event takes place, the device can analyze it and perform some response actions to handle it. Enabling motion detection function can trigger certain channels to start recording, or trigger full screen monitoring, audio warning, notify the surveillance center and so on.
  • Page 52 User Manual of DPA-xxxx Series DVR Figure 5.13 Motion Detection- Area Settings 4) Click Handling, and the message box for channel information will pop up. Figure 5.14 Motion Detection Handling 5) Select the channels which you want the motion detection event to trigger recording. 6) Click Apply to save the settings.
  • Page 53 User Manual of DPA-xxxx Series DVR Figure 5.16 Edit Schedule To arrange other schedule, leave the All Day checkbox blank and set the Start/End time. Up to 8 periods can be configured for each day. And the time periods can’t be overlapped each other.

  • Page 54: Configuring Alarm Triggered Record

    User Manual of DPA-xxxx Series DVR 5.4 Configuring Alarm Triggered Record This section is available for DPA-0448M/16128M model (customizable with alarm interface) only. Purpose: Follow the procedure to configure alarm triggered recording or capture. Steps: Enter the Alarm setting interface. Menu>...
  • Page 55 User Manual of DPA-xxxx Series DVR 4) Click to set the handling method. Figure 5.21 Alarm Handling 5) Choose the alarm triggered recording/capture channel. 6) Check the checkbox to select channel. 7) Click Apply to save settings. 8) Click OK to back to the upper level menu. 9) Click Apply in the Alarm Input interface to save the settings.

  • Page 56: Configuring Manual Record

    User Manual of DPA-xxxx Series DVR Figure 5.23 Record Schedule 5.5 Configuring Manual Record Purpose: Follow the steps to set parameters for the manual record. When using manual record, you need to manually cancel the record. The manual recording is prior to the scheduled recording. Steps: Enter the Manual settings interface.

  • Page 57: Configuring Holiday Record

    User Manual of DPA-xxxx Series DVR Figure 5.25 Start Normal or Motion Detection Recording 2) Click to enable all-day normal recording or all-day motion detection recording of all channels. 5.6 Configuring Holiday Record Purpose: You may want to have different plan for recording on holiday. Follow the steps to configure the record schedule on holiday.
  • Page 58 User Manual of DPA-xxxx Series DVR Figure 5.27 Edit Holiday Settings 2) Check the checkbox after Enable. 3) Select Mode from the dropdown list. There are three different modes for the date format to configure holiday schedule. 4) Set the start and end date. 5) Click Apply to save settings.
  • Page 59 User Manual of DPA-xxxx Series DVR 7) Set start/end time for holiday schedule. Up to 8 periods can be configured for each day. And the time periods can’t be overlapped each other. In the time table of the channel, both holiday schedule and normal day schedule are displayed. Repeat the above steps4)-7) to set Holiday schedule for other channel.

  • Page 60: Files Protection

    User Manual of DPA-xxxx Series DVR 5.7 Files Protection Purpose: You can lock the recorded files or set the HDD property to Read-only to protect the record files from being overwritten. Protect file by locking the record files: Steps: Enter Playback setting interface. Menu>...
  • Page 61 User Manual of DPA-xxxx Series DVR The record files of which the recording is still not completed can’t be locked. Click to change it to to unlock the file and the file is not protected. Figure 5.31 Unlocking Attention...

  • Page 62: Playback

    User Manual of DPA-xxxx Series DVR C H A P T E R 6 Playback...

  • Page 63: Playing Back Record Files

    User Manual of DPA-xxxx Series DVR 6.1 Playing Back Record Files 6.1.1 Playing Back by Channel Purpose: Play back the recorded video files of a specific channel in the live view mode. Channel switch is supported. Instant playback by channel: Steps: Choose a channel in live view mode using the mouse and click the button in the quick setting toolbar.
  • Page 64 User Manual of DPA-xxxx Series DVR Figure 6.2 All-day Playback Interface 2. Playback management. The toolbar in the bottom part of Playback interface can be used to control playing progress, as shown in Figure 6.4. The channel and time selection menu displays by moving the mouse to the right of the playback interface.
  • Page 65 User Manual of DPA-xxxx Series DVR Figure 6.3 All-day Playback Interface with Channel List Dates marked in different colors: Figure 6.4 Toolbar of All-day Playback Table 6.1 Detailed Explanation of All-day-playback Toolbar Button Operation Button Operation Button Operation Button Operation Audio on Start/Stop 30s reverse...

  • Page 66: Playing Back By Time

    User Manual of DPA-xxxx Series DVR Playback progress bar: use the mouse to click any point of the progress bar or drag the progress bar to locate special frames. About video type bar: represents normal recording (manual or schedule); represents event recording (motion);...
  • Page 67 User Manual of DPA-xxxx Series DVR In the Playback interface: The toolbar in the bottom part of Playback interface can be used to control playing process, as shown in Figure 6.8. Figure 6.7 Interface of Playback by Time Figure 6.8 Toolbar of Playback by Time Table 6.2 Detailed Explanation of Playback-by-time Toolbar Butto Button...

  • Page 68: Playing Back By Normal Video Search

    User Manual of DPA-xxxx Series DVR Playback progress bar: use the mouse to click any point of the progress bar or drag the progress bar to locate special frames. About video type bar: represents normal recording (manual or schedule); represents event recording (motion);...
  • Page 69 User Manual of DPA-xxxx Series DVR 3. Choose channels for simultaneous playback. Optional channels for simultaneous playback are the same as the channels chosen to search record files in step 1. And the channel with the recorded file selected in step 2 is the main channel during multi-channel playback and it is displayed at the upper left corner.

  • Page 70: Playing Back By Event Search

    User Manual of DPA-xxxx Series DVR Pause reverse play/Reverse Pause Fast play/ play/Play/Singl Stop forward Single-frame e-frame play reverse play Progress Video search Exit Hide Video type Playback progress bar: use the mouse to click any point of the progress bar or drag the progress bar to locate special frames.
  • Page 71 User Manual of DPA-xxxx Series DVR 13:00:00, and the pre-play and post-play time is set to 30s and 20s respectively, then the actual playback of event video file is 11:59:30 ~ 13:00:20. Figure 6.15 Video Search Result by Motion 7. You can select an item from the list and click Details to view detailed information of the record file, e.g., start time, end time, file size, etc.
  • Page 72 User Manual of DPA-xxxx Series DVR Figure 6.17 Interface of Playback by Event (1) The hidden list of events will be displayed by moving the mouse to the right of the playback interface. Figure 6.18 Interface of Playback by Event (2) Figure 6.19 Toolbar of Playback by Event...

  • Page 73: Playing Back By Tag

    User Manual of DPA-xxxx Series DVR Table 6.4 Detailed Explanation of Playback-by-event Toolbar Button Operation Button Operation Button Operation Button Operation Start/Stop Audio on/Mute 30s forward 30s reverse clipping Slow Add default tag customized management forward Pause reverse play/Reverse Pause Fast play/ play/Play/Sing...
  • Page 74 User Manual of DPA-xxxx Series DVR Figure 6.20 Interface of Playback by Event Click button to add default tag. Click button to add customized tag and input tag name. Max. 64 tags can be added to a single video file. 2.
  • Page 75 User Manual of DPA-xxxx Series DVR 1. Enter Playback interface. Menu>Playback Click Tag tab to enter Playback by Tag interface. Choose channels, tag type and time, and click Search to enter Search Result interface. Two tag types are selectable: All and Tag Keyword. Input keyword if you choose Tag Keyword. Figure 6.22 Video Search by Tag 2.
  • Page 76 User Manual of DPA-xxxx Series DVR Figure 6.24 Interface of Playback by Tag The hidden list of tags will be displayed by moving the mouse to the right of the playback interface. Figure 6.25 Interface of Playback by Tag with Video List Figure 6.26 Toolbar of Playback by Tag...

  • Page 77: Playing Back By System Log

    User Manual of DPA-xxxx Series DVR Table 6.5 Detailed Explanation of Playback-by-tag Toolbar Button Operation Button Operation Button Operation Button Operation Audio Start/Stop 30s forward 30s reverse on/Mute clipping Add default Slow customized management forward Pause reverse Pause play/Reverse play/Play/Sin Fast play/ Stop...
  • Page 78 User Manual of DPA-xxxx Series DVR Figure 6.27 System Log Search Interface 2. Set search time and type and click Search button. Figure 6.28 Result of System Log Search 3. Choose a log with record file and click button to enter Playback interface. If there is no record file at the time point of the log, the message box “No result found”...
  • Page 79 User Manual of DPA-xxxx Series DVR Figure 6.29 Interface of Playback by Log...

  • Page 80: Auxiliary Functions Of Playback

    User Manual of DPA-xxxx Series DVR 6.2 Auxiliary Functions of Playback 6.2.1 Playing Back Frame by Frame Purpose: Play video files frame by frame, in order to check image details of the video when abnormal events happen. Steps: Go to Playback interface. If you choose playback of the record file: click button until the speed changes to Single frame and one click on the playback screen represents playback of one frame.
  • Page 81 User Manual of DPA-xxxx Series DVR 2. Right-click mouse and select Smart Search to go to analysis area selection interface. Figure 6.31 Right-click Menu in All-day Playback and Normal Playback Interface 3. You can click button to set the full screen as target searching area. After drawing area(s), click button to execute smart search in this area.
  • Page 82 User Manual of DPA-xxxx Series DVR Figure 6.33 Smart Search Result with Video List Figure 6.34 Toolbar of Smart Search Playback Table 6.6 Detailed Explanation of Smart-search-playback Toolbar Butto Button Operation Button Operation Button Operation Operation Audio Start/Stop 30s forward 30s reverse on/Mute clipping...

  • Page 83: Digital Zoom

    User Manual of DPA-xxxx Series DVR Playback progress bar: use the mouse to click any point of the progress bar or drag the progress bar to locate special frames. About video type bar: represents normal recording (manual or schedule); represents event recording (motion);...
  • Page 84 User Manual of DPA-xxxx Series DVR Table 6.7 Detailed Explanation of Right-click Menu under Playback Button Function Return to Playback interface Enter Digital Zoom interface Smart Search against a specified area Show & hide control interface Exit the video playback interface...

  • Page 85: Chapter 7

    C H A P T E R 7 Backup...

  • Page 86: Backing Up Record Files

    User Manual of DPA-xxxx Series DVR 7.1 Backing up Record Files Before you start: Please insert the backup device(s) into the device. 7.1.1 Backing up by Normal Video Search Purpose: The record files can be backed up to USB devices (USB flash drives, USB HDDs, USB writer). Backup using USB flash drives, USB HDDs and USB writer.
  • Page 87 User Manual of DPA-xxxx Series DVR 4. Export the record files. Click Export button and start backup. If the inserted device is not recognized: • Click the Refresh button. • Reconnect device. • Check for compatibility from vendor. You can also format USB flash drives or USB HDDs via the device. USB writer and SATA writer cannot be formatted.
  • Page 88 User Manual of DPA-xxxx Series DVR Stay in the Exporting interface until all record files are exported with pop-up message box “Export finished”. Figure 7.5 Export Finished 5. Check backup result. Choose the record file in Export interface and click button to check it.

  • Page 89: Backing Up By Event Search

    User Manual of DPA-xxxx Series DVR 7.1.2 Backing up by Event Search Purpose: Back up event-related record files using USB devices (USB flash drives, USB HDDs, USB writer), or SATA writer. Backup by alarm input search is supported by DS-7200HI-SL model (customizable with alarm interface) only. Steps: 1.
  • Page 90 User Manual of DPA-xxxx Series DVR start time, end time, file size, etc. The size of the currently selected files is displayed in the lower-left corner of the window. (2) Select record file (s) from the list and click Export button to enter the Export interface, as shown in Figure 7.10.
  • Page 91 User Manual of DPA-xxxx Series DVR Figure 7.11 Export by Event Using USB Flash Drive Stay in the Exporting interface until all record files are exported with pop-up message “Export finished”. Figure 7.12 Export Finished 8. Check backup result. Choose the record file in Export interface and click button to check it.

  • Page 92: Backing Up Video Clips

    User Manual of DPA-xxxx Series DVR 7.1.3 Backing up Video Clips Purpose: You may also select video clips to export directly during Playback, using USB devices (USB flash drives, USB HDDs, USB writer). Steps: 1. Enter Playback interface. Please refer to Chapter 6. 2.
  • Page 93 User Manual of DPA-xxxx Series DVR If the inserted USB device is not recognized: • Click the Refresh button. • Reconnect device. • Check for compatibility from vendor. You can also format USB flash drive or USB HDDs via the device. Figure 7.16 Export Video Clips Using USB Flash Drive Stay in the Exporting interface until all record files are exported with pop-up message “Export finished”.

  • Page 94: Managing Backup Devices

    User Manual of DPA-xxxx Series DVR Figure 7.18 Checkup of Video Clips Export Result Using USB Flash Drive 7.2 Managing Backup Devices Management of USB flash drives, and USB HDDs. Enter Search Result interface of record files. Menu>Export>Normal Set search condition and click Search button to enter Search Result interface. At least one channel shall be selected.
  • Page 95 User Manual of DPA-xxxx Series DVR Figure 7.20 Result of Normal Video Search for Backup Backup device management. Click New Folder button if you want to create a new folder in the backup device. Select a record file or folder in the backup device and click button if you want to delete it.
  • Page 96 User Manual of DPA-xxxx Series DVR Management of USB writers Enter Search Result interface of record files. Menu>Export>Normal Set search condition and click Search button to enter Search Result interface. At least one channel shall be selected. Figure 7.22 Normal Video Search for Backup Select record files you want to back up.
  • Page 97 User Manual of DPA-xxxx Series DVR • Click the Refresh button. • Reconnect device. • Check for compatibility from vendor. Figure 7.24 U S B W r i t e r M a n a g e m e n t...

  • Page 98: Chapter 8

    User Manual of DPA-xxxx Series DVR C H A P T E R 8 Alarm Settings...

  • Page 99: Setting Motion Detection

    User Manual of DPA-xxxx Series DVR 8.1 Setting Motion Detection Steps: 1. Enter Motion Detection interface and choose a camera you want to set motion detection. Menu> Camera> Motion Figure 8.1 Motion Detection Setup Interface 2. Set motion detection area and sensitivity. Check the checkbox of Enable Motion Detection to enable motion detection, use the mouse to draw detection area(s) and drag the sensitivity bar to set sensitivity.
  • Page 100 User Manual of DPA-xxxx Series DVR Select Arming Schedule tab to set the channel’s arming schedule. Choose one day of a week and up to eight time periods can be set within each day. Time periods shall not be repeated or overlapped. Figure 8.4 Set Arming Schedule of Motion Detection 5.

  • Page 101: Setting Sensor Alarms

    User Manual of DPA-xxxx Series DVR You are not allowed to copy the Trigger Channel action. Figure 8.6 Copy Settings of Motion Detection 8.2 Setting Sensor Alarms This section is available for DS-7200HI-SL model (customizable with alarm interface) only. Purpose: You can set handling method of an external sensor alarm.
  • Page 102 User Manual of DPA-xxxx Series DVR 2. Select Alarm Input tab to enter Alarm Input Settings interface and set the handling method of the selected alarm input. Check checkbox to enable the alarm input and click to set up its alarm response actions. Figure 8.8 Alarm Input Settings Interface 3.

  • Page 103: Detecting Video Loss

    User Manual of DPA-xxxx Series DVR Figure 8.10 Set PTZ Linking of Alarm Input 7. If you want to set handling method of another alarm input, repeat the above steps or just copy the above settings to it by clicking Copy in Alarm Input Settings interface. Figure 8.11 Copy Settings of Alarm Input 8.3 Detecting Video Loss Purpose:...

  • Page 104: Detecting Video Tampering

    User Manual of DPA-xxxx Series DVR Figure 8.12 Video Loss Setup Interface 2. Select a channel you want to detect. 3. Check the checkbox of Enable Video Loss Alarm. 4. Click the icon of Handling to enter the Handling interface. 5.

  • Page 105: Handling Exceptions

    User Manual of DPA-xxxx Series DVR Figure 8.14 Video Tampering Detection Setup Interface 2. Select a channel you want to detect video tampering. 3. Check the checkbox of Enable Video Tampering Detection. By default, the video tampering detection is configured in full screen. 4.
  • Page 106 User Manual of DPA-xxxx Series DVR • HDD Full: The HDD is full. • HDD Error: Writing HDD error, unformatted HDD, etc. • Network Disconnected: Disconnected network cable. • IP Conflicted: Duplicated IP address. • Illegal Login: Incorrect user ID or password. •...

  • Page 107: Setting Alarm Response Actions

    User Manual of DPA-xxxx Series DVR 8.6 Setting Alarm Response Actions Purpose: The alarm response actions will be activated when an exception occurs, including Full Screen Monitoring, Audible Warning, Notify Surveillance Center, and Send Email. Full Screen Monitoring When an alarm event (motion detection/video tampering detection/video loss detection) is triggered, the local monitor (VGA or BNC monitor) display in full screen the video image from the alarming channel configured for full screen monitoring.
  • Page 108 User Manual of DPA-xxxx Series DVR If “Manually Clear” is selected in the dropdown list of Dwell Time, you can clear it only by going to Menu> Manual> Alarm and clicking Clear All. Figure 8.17 Alarm Output Settings Interface 2. Set arming schedule of the alarm output. Click to set the arming schedule of alarm output.

  • Page 109: Triggering Or Clearing Alarm Output Manually

    User Manual of DPA-xxxx Series DVR 8.7 Triggering or Clearing Alarm Output Manually This section is available for DPA-0448M/16128M model (customizable with alarm interface) only. Purpose: Sensor alarm can be triggered or cleared manually. If Manually Clear is selected in the dropdown list of dwell time of an alarm output, the alarm can be cleared only by clicking Clear button in the following interface.

  • Page 110: Chapter 9

    User Manual of DPA-xxxx Series DVR C H A P T E R 9 Network Settings...

  • Page 111: Configuring General Settings

    User Manual of DPA-xxxx Series DVR 9.1 Configuring General Settings Purpose: Network settings must be properly configured before you operate device over network. Steps: 1. Enter the Network Settings interface. Menu > Configuration > Network Figure 9.1 General Network Settings Interface 2.

  • Page 112: Configuring Advanced Settings

    User Manual of DPA-xxxx Series DVR 9.2 Configuring Advanced Settings 9.2.1 Configuring PPPoE Settings Purpose: Your device also allows access by Point-to-Point Protocol over Ethernet (PPPoE). Steps: Enter the Network Settings interface. Menu > Configuration > Network Select the PPPoE tab to enter the PPPoE Settings interface. Figure 9.2 PPPoE Settings Interface Check the PPPoE checkbox to enable this feature.

  • Page 113: Configuring Ddns

    User Manual of DPA-xxxx Series DVR By default, the Cloud P2P is enabled. Configuring Cloud P2P Purpose: Cloud P2P provides the mobile phone application and as well the service platform page to access and manage your connected DVR, which enables you to get a convenient remotely access to the surveillance system. Steps: Enter the Network Settings interface.
  • Page 114 User Manual of DPA-xxxx Series DVR If your device is set to use PPPoE as its default network connection, you may set Dynamic DNS (DDNS) to be used for network access. Prior registration with your ISP is required before configuring the system to use DDNS. Steps: Enter the Network Settings interface.
  • Page 115 User Manual of DPA-xxxx Series DVR • PeanutHull: Enter User Name and Password obtained from the PeanutHull website. Figure 9.8 Peanut Hull Settings Interface • NO-IP: Enter the account information in the corresponding fields. Refer to the DynDNS settings. 1) Enter Server Address for NO-IP. 2) In the Device Domain Name text field, enter the domain obtained from the NO-IP website (www.no-ip.com).

  • Page 116: Configuring Ntp Server

    User Manual of DPA-xxxx Series DVR Go to the HiDDNS website: www.hiddns.com. Click to register a user account if you do not have one. After registration is successful, use the account and password to log in. Figure 9.11 Register an Account In the DDNS Management System interface, click the Device Management tab on the left menu bar and then click to register the device.

  • Page 117: Configuring Upnp

    User Manual of DPA-xxxx Series DVR Figure 9.13 NTP Settings Interface Check the Enable NTP checkbox to enable this feature. Configure the following NTP settings: • Interval: Time interval between the two synchronizing actions with NTP server. The unit is minute. •...
  • Page 118 User Manual of DPA-xxxx Series DVR Figure 9.14 UPnP™ Settings Interface 3. Check checkbox to enable UPnP™. 4. Select the mapped type to Auto or Manual. When you select Auto, the mapping ports can be automatically assigned by the router. When you select Manual, you should continue Step5 to edit the mapping ports.

  • Page 119: Configuring Remote Alarm Host

    User Manual of DPA-xxxx Series DVR 9.2.5 Configuring Remote Alarm Host Purpose: With a remote alarm host configured, the device will send the alarm event or exception message to the host when an alarm is triggered. The remote alarm host must have the C M S ( C l i e n t M a n a g e m e n t S y s t e m ) s o f t w a r e installed.

  • Page 120: Configuring Rtsp

    User Manual of DPA-xxxx Series DVR Menu > Configuration > Network Select the More Settings tab to enter the More Settings interface. Set Multicast IP. When adding a device to the C M S ( C l i e n t M a n a g e m e n t S y s t e m ) s o f t w a r e , the multicast address must be the same as the device’s multicast IP.

  • Page 121: Configuring Email

    User Manual of DPA-xxxx Series DVR Menu > Configuration > Network Select the More Settings tab to enter the More Settings interface. Enter new Server Port and HTTP Port. Figure 9.21 Host/Others Settings Menu Enter the Server Port and HTTP Port in the text fields. The default Server Port is 8000 and the HTTP Port is 80, and you can change them according to different requirements.
  • Page 122 User Manual of DPA-xxxx Series DVR Click the Apply button to save the settings. Select the Email tab to enter the Email Settings interface. Figure 9.23 Email Settings Interface Configure the following Email settings: Enable Server Authentication (optional): Check the checkbox to enable the server authentication feature.
  • Page 123 User Manual of DPA-xxxx Series DVR Click the Apply button to save the Email settings. You can click the Test button to test whether your Email settings work. The corresponding Attention message box will pop up. Figure 9.25 Email Testing Attention...

  • Page 124: Checking Network Traffic

    User Manual of DPA-xxxx Series DVR 9.3 Checking Network Traffic Purpose: You can check the network traffic to obtain real-time information of device such as linking status, MTU, sending/receiving rate, etc. Steps: Enter the Network Traffic interface. Menu > Maintenance > Net Detect Figure 9.26 Network Traffic Interface You can view the sending rate and receiving rate information on the interface.

  • Page 125: Network Detection

    User Manual of DPA-xxxx Series DVR 9.4 Network Detection Purpose: You can obtain network connecting status of device through the network detection function, including network delay, packet loss, etc. 9.4.1 Testing Network Delay and Packet Loss Steps: Enter the Network Traffic interface. Menu >...
  • Page 126 User Manual of DPA-xxxx Series DVR 2. Click the Network Detection tab to enter the Network Detection interface. 3. Select the backup device from the dropdown list of Device Name, as shown in Figure 9.28. Click the Refresh button if the connected local backup device cannot be displayed. When it fails to detect the backup device, please check whether it is compatible with the device.

  • Page 127: Checking Network Status

    User Manual of DPA-xxxx Series DVR 9.4.3 Checking Network Status Purpose: You can also check the network status and quick set the network parameters in this interface. Steps: Click Status on the right bottom of the page. Figure 9.31 Checking Network Status If the network is normal, the following message box pops out.

  • Page 128: Checking Network Statistics

    User Manual of DPA-xxxx Series DVR 9.4.4 Checking Network Statistics Purpose: You can check the network statistics to obtain the real-time information of the device. Steps: 1. Enter the Network Statistics interface. Menu > Maintenance> Net Detect 2. Click the Network Stat. tab to enter the Network Statistics menu. Figure 9.34 Network Stat.

  • Page 129: Chapter 10

    User Manual of DPA-xxxx Series DVR C H A P T E R 10 HDD Management...

  • Page 130: Initializing Hdds

    User Manual of DPA-xxxx Series DVR 10.1 Initializing HDDs Purpose: A newly installed hard disk drive (HDD) must be initialized before it can be used with your device. Steps: Enter the HDD Information interface. Menu > HDD>General Figure 10.1 HDD Information Interface Select the HDD to be initialized.

  • Page 131: Configuring Quota Mode

    User Manual of DPA-xxxx Series DVR 10.2 Configuring Quota Mode Purpose Each camera can be configured with allocated quota for the storage of recorded files. Steps Enter the Storage Mode interface. Menu > HDD > Advanced Set the Mode to Quota. The device must be rebooted to activate the settings.

  • Page 132: Checking Hdd Status

    User Manual of DPA-xxxx Series DVR 10.3 Checking HDD Status Purpose: You may check the status of the installed HDD on device so as to take immediate check and maintenance in case of HDD failure. Checking HDD Status in HDD Information Interface Steps: Enter the HDD Information interface.

  • Page 133: Checking S.m.a.r.t. Information

    User Manual of DPA-xxxx Series DVR 10.4 Checking S.M.A.R.T. Information Purpose: The S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitoring system for HDD to detect and report on various indicators of reliability in the hopes of anticipating failures. Steps: Enter the S.M.A.R.T.

  • Page 134: Detecting Bad Sector

    User Manual of DPA-xxxx Series DVR 10.5 Detecting Bad Sector Purpose: The bad sectors of a HDD may cause the system to slow down when reading or writing data. You can detect the bad sectors of the HDD and thus to take immediate measures to repair it. Steps: 1.

  • Page 135: Configuring Hdd Error Alarms

    User Manual of DPA-xxxx Series DVR 10.6 Configuring HDD Error Alarms Purpose: You can configure the HDD error alarms when the HDD status is Uninitialized or Abnormal. Steps: Enter the Exception interface. Menu > Configuration > Exceptions Select the Exception Type to HDD Error from the dropdown list. Click the checkbox(s) below to select the HDD error alarm type (s).

  • Page 136: Chapter 11

    User Manual of DPA-xxxx Series DVR C H A P T E R 11 Camera Settings...

  • Page 137: Configuring Osd Settings

    User Manual of DPA-xxxx Series DVR 11.1 Configuring OSD Settings Purpose: You can configure the OSD (On-screen Display) settings for the camera, including date /time, camera name, etc. Steps: Enter the OSD Configuration interface. 1 . 1 . 1 . 1 . Menu >...

  • Page 138: Configuring Privacy Mask

    User Manual of DPA-xxxx Series DVR 11.2 Configuring Privacy Mask Purpose: You are allowed to configure the four-sided privacy mask zones that cannot be viewed by the operator. Steps: 1. Enter the Privacy Mask Settings interface. Menu > Camera > Privacy Mask 2.

  • Page 139: Configuring Video Parameters

    User Manual of DPA-xxxx Series DVR 11.3 Configuring Video Parameters Steps: Enter the Image Settings interface. 1 . 1 . 1 . 1 . Menu > Camera > Image Select the camera to set image parameters. 2 . 2 . 2 . 2 . Set the period of a day for configuring independent image parameters so as to satisfy different light 3 .

  • Page 140: Device Management And Maintenance

    User Manual of DPA-xxxx Series DVR C H A P T E R 1 2 Device Management and Maintenance...

  • Page 141: Viewing System Information

    User Manual of DPA-xxxx Series DVR 12.1 Viewing System Information 12.1.1 Viewing Device Information Steps: 1. Enter the System Information interface. Menu > Maintenance > System Info 2. Click the Device Info tab to enter the Device Information menu to view the device name, model, serial No. , firmware version and encoding version.

  • Page 142: Viewing Alarm Information

    User Manual of DPA-xxxx Series DVR Figure 12.3 Record Information Interface 12.1.4 Viewing Alarm Information This function is not available for DPA-0448M/16128M model (customizable with alarm interface) only. Steps: 1. Enter the System Information interface. Menu > Maintenance > System Info 2.

  • Page 143: Viewing Hdd Information

    User Manual of DPA-xxxx Series DVR Figure 12.5 Network Information Interface 12.1.6 Viewing HDD Information Steps: 1. Enter the System Information interface. Menu > Maintenance > System Info 2. Click the HDD tab to enter the HDD Information menu to view the HDD status, free space, property, etc. Figure 12.6 HDD Information Interface...

  • Page 144: Searching & Exporting Log Files

    User Manual of DPA-xxxx Series DVR 12.2 Searching & Exporting Log Files Purpose: The operation, alarm, exception and information of the device can be stored in log files, which can be viewed and exported at any time. Steps: 1. Enter the Log Search interface. Menu >...
  • Page 145 User Manual of DPA-xxxx Series DVR Figure 12.8 Log Search Results 5. You can click the button of each log or double click it to view its detailed information. And you can also click the button to view the related video files if available. Figure 12.9 Log Details 6.

  • Page 146: Importing/Exporting Configuration Files

    User Manual of DPA-xxxx Series DVR Check checkbox to select the HDD and click Export to enter the export interface. Figure 12.11 Export Log Files 7. Select the backup device from the dropdown list of Device Name. 8. Click the Export to export the log files to the selected backup device. You can click the New Folder button to create new folder in the backup device, or click the Format button to format the backup device before log export.
  • Page 147 User Manual of DPA-xxxx Series DVR Figure 12.12 Import/Export Config File 2. Click the Export button to export configuration files to the selected local backup device. 3. To import a configuration file, select the file from the selected backup device and click the Import button. After the import process is completed, you must reboot the device.

  • Page 148: Upgrading System

    User Manual of DPA-xxxx Series DVR 12.4 Upgrading System Purpose: The firmware on your device can be upgraded by local backup device or remote FTP server. 12.4.1 Upgrading by Local Backup Device Steps: 1. Connect your device with a local backup device where the update firmware file is located. 2.
  • Page 149 User Manual of DPA-xxxx Series DVR 3. Enter the FTP Server Address in the text field. 4. Click the Upgrade button to start upgrading. 5. After the upgrading is complete, reboot the device to activate the new firmware.

  • Page 150: Restoring Default Settings

    User Manual of DPA-xxxx Series DVR 12.5 Restoring Default Settings Steps: Enter the Default interface. Menu > Maintenance > Default Figure 12.15 Restore Factory Default Click the OK button to restore the default settings. Except the network parameters (including IP address, subnet mask, gateway, MTU and server port), all other parameters of the device will be restored to factory default settings.

  • Page 151: Others

    User Manual of DPA-xxxx Series DVR C H A P T E R 1 3 Others...

  • Page 152: Configuring General Settings

    User Manual of DPA-xxxx Series DVR 13.1 Configuring General Settings Purpose: You can configure the BNC output standard, VGA output resolution, mouse pointer speed, etc. Steps: Enter the General Settings interface. Menu > Configuration > General Select the General tab. Figure 13.1 General Settings Interface Configure the following settings: •...

  • Page 153: Configuring Dst Settings

    User Manual of DPA-xxxx Series DVR 13.2 Configuring DST Settings Steps: Enter the General Settings interface. Menu >Configuration>General Choose DST Settings tab. Figure 13.2 DST Settings Interface You can check the checkbox before the Auto DST Adjustment item. Or you can manually check the Enable DST checkbox, and then set the date of the DST period.

  • Page 154: Configuring More Settings

    User Manual of DPA-xxxx Series DVR 13.3 Configuring More Settings Steps: Enter the General Settings interface. Menu > Configuration > General Click the More Settings tab to enter the More Settings interface. Figure 13.3 More Settings Interface Configure the following settings: •...

  • Page 155: Managing User Accounts

    User Manual of DPA-xxxx Series DVR 13.4 Managing User Accounts Purpose: There is a default account in the device: A d m i n i s t r a t o r . The A d m i n i s t r a t o r user name is a d m i n and the password is 1 2 3 4 5 .
  • Page 156 User Manual of DPA-xxxx Series DVR User’s MAC Address: The MAC address of the remote PC which logs onto the device. If it is configured and enabled, it only allows the remote user with this MAC address to access the device. Click the OK button to save the settings and go back to the User Management interface.

  • Page 157: Deleting A User

    User Manual of DPA-xxxx Series DVR • Remote Advanced Operation: Remotely operating HDD management (initializing HDD), upgrading system firmware. • Remote Shutdown/Reboot: Remotely shutting down or rebooting the device. Camera Configuration • Remote Live View: Remotely viewing live video of the selected camera (s). •...

  • Page 158: Changing Password Of Admin

    User Manual of DPA-xxxx Series DVR Figure 13.9 Edit a User Click the icon to enter the Edit User interface. Figure 13.10 Edit User Interface Edit the user information, including user name, password, level and MAC address. Click the OK button to save the settings and exit the menu. 13.4.4 Changing Password of Admin Purpose: The password of the admin user account can be changed in the User Management menu.
  • Page 159 User Manual of DPA-xxxx Series DVR Select the admin user and click to change the password. Figure 13.12 Change Password Enter the old password, check checkbox, enter new password and confirm password on the menu. Click to save the settings and exit the menu.
  • Page 160 User Manual of DPA-xxxx Series DVR 13.5 Logging out/Shutting down/Rebooting Device Steps: 1. Enter the Shutdown interface. Menu > Shutdown Figure 13.13 Shutdown Menu 2. Click the Logout button to log out, or Click the Shutdown button to shut down the device, or Click the Reboot button to reboot the device.

  • Page 161: Appendix

    User Manual of DPA-xxxx Series DVR C H A P T E R 1 4 Appendix...

  • Page 162: Glossary

    User Manual of DPA-xxxx Series DVR Glossary • Dual Stream: Dual stream is a technology used to record high resolution video locally while transmitting a lower resolution stream over the network. The two streams are generated by the device, with the main stream having a maximum resolution of 4CIF and the sub-stream having a maximum resolution of CIF.
  • Page 163 User Manual of DPA-xxxx Series DVR • Why does my device make a beeping sound after booting? The possible reasons for the warning beep on the device are as follows: There is no HDD installed in the device. The HDD is not initialized. HDD error To cancel the beeping sound and use the device without HDD, enter the Exception Settings interface.

This manual is also suitable for:

Dpa-0448mDpa-16128mDpa-08200mDpa-16400lDpa-0848l

Table of Contents
