  • Page 1 Biopel Pellet Boiler Installation manual...
  • Page 2 Dear Customer.   Thank you for choosing Robus Biopel pellet boiler system. This product is designed and manufactured to the highest standards in the EU. In order for you to get the most out of your product, we strongly recommend that you carefully read this manual prior to installation and operation.
  • Page 5: The Clean Air Act 1993 And Smoke Control Areas

    Fuel and warranty The Robus Biopel pellet boilers are designed for use with EN-plus A grade wood pellets only. The use of substandard fuels will compromise the efficiency, reduce the life span and invalidate the warranty of the appliance.
  • Page 6: General Installation Guidelines

    The boiler must only be installed by qualified engineers. Installer product training is available at Robus Energy Ltd. All local building regulations must be observed (downloads available from the Robus Energy website). The boiler must not be installed on combustible surfaces.
  • Page 7 Biopel burner First check proper position of the grate (see picture) and then place burner into the boiler flange. On all Biopel boilers you can choose left or right side of the boiler for burner installation. However the opposite flange on the boiler bust be always sealed. For example if you choose left flange for burner connection make sure that right flange is properly sealed.
  • Page 8 Insert burner into the burner flange and secure with wing nuts. Connect burner pipe into the hole located on the top of the burner and secure with 2 x burner pipe screws. Attach PVC tube on the burner pipe and from the other side on the external auger outlet.
  • Page 9: Plumbing Schematics

    Plumbing schematics The load valve, supplied with the boiler, must be installed in the boiler return pipe work as shown in the diagram above The use of a buffer tank or thermal store will prevent frequent ignition of the boiler and will prolong the life of the igniter. The min buffer/thermal store capacity should be;...
  • Page 10 Biopel V8 controller The V8 controller comprises of two main components: 1. Controller screen 2. Connection board All interconnecting cables between the screen and connection board are pre- wired with simple plugs to allow for quick installation. The V8 controller has two different mounting options depending on the type of pellet hopper chosen With Compact hopper With external/bulk silo...
  • Page 11 Control board wiring connections Most of the electrical connections on the board are factory wired to allow for a simple and quick installation on “standard” installations. Connections that will need to be made by the installer are: • CH PUMP – This is the boiler pump •...
  • Page 13: Menu Structure

    CONTROL UNIT V8 MENU DESCRIPTION The V8 control unit is designed to offer the home owner and installer a series of simple menus to give full control of all boiler settings and parameters. The controller has 3 levels of PIN protection in order to prevent the home owner unintentionally altering boiler parameters.
  • Page 14 1.1.1 Basic settings Main screen o Display CH o Display service CH temperature – central heating temperature, which is maximum boiler flow temperature. DHW temperature – domestic hot water temperature, which is maximum temperature inside water tank. DHW sensor must be connected into the Connection board. Room temperature decrease –...
  • Page 15 Max of ignitions – max number of ignitions. Can be reset back to zero. Factory setup – reset to factory setup. Program version – version of uploaded software. 1.1.1 Plumber settings Fan correction – correction of fan speed +- 50% Fan max work correction...
  • Page 16 2.0 FIRST BOILER START UP 1. There is function called First boiler start up which is functuon used for exact setup of main boiler functions. Installer is responsible for this setup. First boiler start up has to be done before turning on the burner for the first time.
  • Page 18 4.0 Fan correction Fan correction is responsible for changing the flame size. You change fan speed only for max burner power, but by changing this you basicly change all modulation range for fan speed. Service settings Plumber settings Fan correction Auger settup, Work, What you change Max fan...
  • Page 22: Warranty

    Robus Energy has no influence. In addition, the warranty is invalid due to misuse of the burner for example using fuel that is not approved by Robus Energy. The warranty does not cover parts such as the electrical igniter.
