KARVIN 2700 S Service Instructions Manual

KARVIN ELECTRIC OUTBOARD MOTOR
Dear customer,
you just bought a fully integrated outboard motor unit, which will fulfill your requirements fully.
The Karvin electric motor is more than an excellent accessory or auxiliary motor; it is a
"workhorse", which can satisfy demands of both amateurs and professionals on the water.
The Karvin electric motor has many features not available even in gasoline outboard motors.
• silent
• simply to operate
• low maintenance
• very low operating costs
• light
• dependable
• ecologically friendly
Further features and advantages:
• The fastest and the most efficient electric outboard motor in the current world market.
• Two times lower consumption of electricity than comparable DC motors.
• 81% efficiency.
• Suitable for use in conjunction with solar panels.
• High torque.
• Computer controlled motor operation.
• Continuous RPM regulation forward and reverse.
• Electronic key insures safety and security. Karvin motor will shut off if the operator falls
overboard and prevents also its starting by any incompetent person.
• Large illuminated display.
Electronic display shows important information, allowing the economical and efficient
operation of boat and motor:
• RPM (Rotations Per Minute)
• Actual current consumption
• Battery voltage
• Accumulated hours of operation (total number of hours the motor has been used)
• Audible and visual low voltage warning system. This system also shifts automatically the
motor into power conservation mode, preventing total discharge of batteries and insuring
a safe return to the shore.
Important warning for the operating person
• Never put the engine into operation when not being in the water.
• Don't connect the battery to the terminal connectors, before the engine is hanged up in its
working position and fixed to the boat.
• Pay your attention to the correct incoming cable connecting polarity to the battery! If
it's not the case, the motor electronical control will be destroyed.
• Control also if the incoming cables isolation is faultless, before you put the engine in
operation.
SERVICE INSTRUCTIONS
