GLI Internationa D53 Operating Instructions Manual

Dissolved oxygen analyzer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Back to MANUALS Menu
OPERATING INSTRUCTION MANUAL
Worldwide Sales:
GLI International, Inc.
9020 West Dean Road
Milwaukee, Wisconsin 53224, U.S.A.
phone: [414] 355-3601
fax: [414] 355-8346
e-mail: info
gliint.com
@
Rev. 0-599
GLI_DissolvedOxAnalyzer_D53_om_D599
Dissolved Oxygen Analyzer
(Universal-mount 1/2 DIN style;
user-selectable D.O. concentration
displayed in ppm, mg/l, or % saturation)
In the interest of improving and updating its equipment, GLI reserves the right to alter specifications to equipment at any time.
A Viridor Instrumentation company
Model D53
1
European Sales:
GLI International Ltd
Ivel Road, Shefford
Bedfordshire. SG17 5JU England
phone: 01462 817070
fax: 01462 813680
e-mail: gli
gli.co.uk
@
Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D53 and is the answer not in the manual?

Questions and answers

Summary of Contents for GLI Internationa D53

  • Page 1 In the interest of improving and updating its equipment, GLI reserves the right to alter specifications to equipment at any time. A Viridor Instrumentation company Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 2 Back to MANUALS Menu Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 3 FOR PERSONAL INJURY. CAUTION: A CAUTION LOOKS LIKE THIS. IT ALERTS YOU TO POSSIBLE INSTRUMENT MALFUNCTION OR DAMAGE. NOTE: A note looks like this. It alerts you to important, useful operating information. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 4 WARRANTY GLI International, Inc. warrants the Model D53 to be free from defects in material or workmanship for a period of 2 years (24 months) from the date of shipment of this product from our facility. A warranty claim will not be honored if defects are...
  • Page 5 NOTE: When the analyzer is equipped with the optional two sensor input software and only one sensor is being used, the unused sensor input must be set for “MANUAL” compensation to prevent a “WARNING: CHECK STATUS” message from appearing. (continued on next page) Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 6 1. Enter the known atmospheric pressure or altitude in your geographic area. C ON FIG U RE TES T/ MA IN T EX IT A. Press MENU key to display (continued on next page) Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 7 ACTIVE?” screen appears, press ENTER key to return the analog outputs and relays to their active states (MEASURE screen appears). C ON FIG U RE TES T/ MA IN T EX IT 2. Press MENU key to display (continued on next page) Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 8 To further configure the analyzer to your application requirements, use the appropriate CONFIGURE screens to make selections and “key in” values. Refer to Part Three, Section 4 for complete configu- ration details. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 9: Table Of Contents

    2.2 Displaying Top-level Menu Screens ........ 35-36 2.3 Displaying Submenu Screens..........36 2.4 Adjusting Edit/Selection Screen Values........ 36 2.5 Entering (Storing) Edit/Selection Screen Values/Choices ..36 SECTION 3 ADJUSTING DISPLAY CONTRAST ..........37 Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 10 AIR CAL Method (highly recommended) ....62-64 SATURATION CAL Method........64-65 5.3 Temperature Calibration: 1 POINT SAMPLE Method ......... 66-67 2 POINT SAMPLE Method ......... 67-69 5.4 Analog Outputs (1 and 2) Calibration ......70-71 Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 11 Assigning a Message ............. 88 Assigning User-defined Date ........88-89 Viewing Identification (ID) ..........89 Viewing Revisions ............89 “Master Reset” Function ............90 “Refresh” Function............... 90 Protocol Command Set for PC Programming ...... 90 Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 12 P A R T F I V E - S P A R E P A R T S A N D A C C E S S O R I E S ...................... 97 Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 13 Analyzer Configuration Settings (Ranges/Choices and Defaults) ......55-57 Table C Comparison of Calibration Methods ................59 Table D Temperature versus Water-saturated Concentration of Oxygen........62 Table E Relay Overfeed Timer Interactions with Other Analyzer Functions ......80 Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 14 Back to MANUALS Menu Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 15: Part O N E - I N T R O D U C T I O N

    Part Three, Sections 5.1 and 5.2. The analyzer also provides two methods for calibrating temperature (Section 5.3). This feature, however, is typically not needed since the analyzer is factory-calibrated for highly accurate tempera- Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 16 Back to MANUALS Menu PART ONE - INTRODUCTION SECTION 1 - GENERAL INFORMATION ture measurement. The mA Analog Outputs values for each analog output can also be calibrated (Sec- tion 5.4). Relays Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 17 (XFER OUTPUTS) • Remain active to respond to the measured value (ACTIVE OUTPUTS). For analog output transfer setup details, see Part Three, Section 4.5 under the sub- heading “Setting Transfer Value.” Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 18: Modular Construction

    A label with the analyzer model number, serial number, 1.4 Analyzer build date, and other items is affixed to the top of the enclo- Serial Number sure. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 19: Emi/Rfi Immunity

    US standards and meets European IEC 801-series testing for electromagnetic and radio fre- quency emissions and susceptibility. Refer to Figure 1-1 and the specifications in Section 2.1 for more information. FIGURE 1-1 EMI/RFI Immunity Diagram Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 20: Specifications

    AIR CAL ......... For use only when the sensor is calibrated in air. The analyzer computes and displays the ppm value based on the entered atmospheric pressure or altitude, and the temperature of the 100% saturated air. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 21: Section 2 Specifications

    1/2 inch (13 mm) conduit holes; nylon mount- ing bracket, and stainless steel hardware Mounting Configurations .... Panel, surface, and pipe (horizontal and vertical) mounting Net Weight......... 3.5 lbs. (1.6 kg) approximately Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 22: Part T W O - I N S T A L L A T I O N

    Figure 2-1 illustrates the various ways to mount the ana- lyzer using the supplied bracket and hardware. Determine the mounting method and attach the hardware as shown in the respective illustration. Refer to Figure 2-2 for analyzer installation dimension details. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 23: Figure 2-1 Analyzer Mounting Arrangements

    Back to MANUALS Menu PART TWO - INSTALLATION SECTION 2 - MECHANICAL REQUIREMENTS FIGURE 2-1 Analyzer Mounting Arrangements Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 24: Conduit Hole Requirements

    3H1230, for cable entries.) Seal unused cable entry holes with appropriate plugs. NOTE: Use NEMA 4-rated fittings and plugs to maintain the watertight integrity of the NEMA 4X enclosure. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 25: Electrical Connections

    NOTE: Do not route the sensor and interconnect cables in any conduit containing AC power wiring (“electrical noise” may interfere with the sensor signal). Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 26: Figure 2-3 Analyzer Terminal Block Designations

    2. When using GLI mounting hardware, plug the sensor cable into the mating receptacle on the junction box. Route the 6-conductor interconnect cable (GLI part number 1W1100) from the junction box to the analyzer. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 27: Figure 2-4 Connecting Gli Membrane Dissolved Oxygen Sensor(S)

    GLI sensor mounting hardware, and the need for interconnect cable. 12 13 14 15 18 19 SENSOR A SENSOR B FIGURE 2-4 Connecting GLI Membrane Dissolved Oxygen Sensor(s) Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 28: Analog Outputs

    Output #1 remains available for nor- mal use. However, in a HART multi-drop wiring configuration, Output #1 becomes dedicated to that function and cannot be used. See Part Three, Sec- tion 8 for more HART communication information. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 29: Relay Outputs

    WARNING: MAKE SURE THAT LINE POWER IS NOT PRESENT WHILE CONNECTING WIRES RELAY TERMINALS. FIGURE 2-5 Connecting Control/Alarm Device(s) To Electromechanical Relay(s) Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 30: Closed Contact Ttl Input

    NOTE: For 230 volt split phase line power, be sure to con- form to local codes with regard to fusing the 115 volt line connected to the “N” terminal. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 31: Figure 2-6 Connecting 115 Volt Single Phase Line Power (90-130 Vac)

    Single Phase Line Power (90-130 VAC) 230 115 N FIGURE 2-7 Connecting 230 Volt Single Phase Line Power (180-260 VAC) FIGURE 2-8 Connecting 230 Volt Split Phase Line Power (180-260 VAC) Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 32: Part T H R E E - O P E R A T I O N

    When a relay overfeed timer is used and it has “timed out,” the respective relay annunciator con- tinuously blinks until the overfeed condition is resolved. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 33: Keypad

    (Example: With the “MAIN MENU” branch selection screen displayed, pressing the ESC key once takes the display up one level to the MEASURE screen.) FIGURE 3-1 Analyzer Keypad Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 34 • Edit/Selection Screens: “Fine” adjusts numerical value, enclosed by parenthesis, up or down respec- tively or moves up or down respectively between choices enclosed by parenthesis. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 35: Measure Screen (Normal Display Mode)

    “ + ” or “ - ” screen symbols appear, indi- cating that the value is respectively above or below range. This also includes the 0-50°C temperature range of the GLI membrane D.O. sensor. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 36: Menu Structure

    Some menu lists are too long to completely fit on the screen. A â symbol at the bottom right of the list indi- cates that you can display hidden items by pressing the Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 37: Displaying Submenu Screens

    2.5 Entering (Storing) After the desired value/choice is displayed, press the Edit/Selection Screen ENTER key to enter (store) it into the non-volatile analyzer Values/Choices memory. The previous screen will then re-appear. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 38: Adjusting Display Contrast

    MEASURE screen displayed, press and hold the ENTER key and simultaneously press the ñ ñ or ò ò key until attaining the desired contrast. ECTION CONFIGURING THE ANALYZER 4.1 Selecting Language to Operate Analyzer Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 39 3. Press ENTER key to dis- play . Use ò ò and ñ ñ keys to view the language choices. 4. With the desired language displayed, press ENTER key to enter this selection. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 40: Configuring Units For Application Conditions

    3. Use ò ò and ñ ñ keys to view all choices for salinity units (milliSiemens/cm conductivity or milliMols/liter ionic strength). 4. With the desired choice displayed, press ENTER key to enter this selection. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 41: Configuring Sensor (A And B) Characteristics

    ENTER key to display keys to view the three choices: • XX.XX ppm • XX.XX mg/l • XXX.X % 4. With the desired choice displayed, press ENTER key to enter this selection. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 42 “+” value; for below sea level altitude, enter a “-” value. (Use ð ð and ï ï keys for coarse adjust; ñ ñ and ò ò keys for fine adjust.) Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 43: Setting Salinity Value (For Process Or Clean Water)

    2. Press ENTER key to display . Use ò ò and ñ ñ keys to view both choices (OFF or ON). 3. With the desired choice displayed, press ENTER key to enter this selection. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 44: Changing Top Line Notation On Measure Screen

    To configure the analyzer for fixed manual temperature compensation, you must select “MANUAL” and enter a spe- cific temperature value: screen displayed, use ò ò key 1. With the to select the “TEMP ELEMENT” line. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 45: Selecting Temperature Display Format (°C Or °F)

    ò ò key to select the “SET °C OR °F” line. 2. Press ENTER key to display . Use ò ò and ñ ñ keys to view both choices (°C or °F). Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 46: Configuring Outputs (1 And 2)

    Back to MANUALS Menu PART THREE - OPERATION SECTION 4 - CONFIGURING THE ANALYZER 3. With the desired choice 4.5 Configuring Outputs displayed, press ENTER (1 and 2) key to enter this selection. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 47 OUTPUTS” function in the TEST/MAINT menu. • Held indefinitely by lo- cally or remotely connecting both TTL in- put terminals on TB1. • Held by an activated “timer” relay for its en- Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 48 3. Set the displayed value at which 0/4 mA is desired, and press ENTER key to enter the value. (Use ð ð and ï ï keys for coarse adjust; ñ ñ and ò ò keys for fine adjust.) Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 49: Setting Transfer Value (Ma)

    3. Set the displayed value to the desired transfer value, and press ENTER key to enter it. (Use ð ð and ï ï keys for coarse adjust; ñ ñ and ò ò keys for fine adjust.) Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 50: Setting Output Filter Time

    “SCALE 0mA/4mA” line. 2. Press ENTER key to display . Use ò ò and ñ ñ keys to view both choices. 3. With the desired choice displayed, press ENTER key to enter this selection. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 51: Configuring Relays (A, B, C, And D)

    SENSOR B measured dissolved oxygen or temperature. Since timer and status function relays are operated by other criteria, the parameter assigned to these relays is not relevant and, therefore, disregarded. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 52: Selecting Function Mode

    “WARNING CHECK STATUS” message flashes on the MEASURE screen. This occurs when the analyzer detects a sensor or analyzer “fail” diagnostic condition (see Part Three, Section 6.1 for details). Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 53 2. Press ENTER key to display . Use ò ò and ñ ñ keys to view the choices (ALARM, CONTROL, STATUS, or TIMER). 3. With the desired choice displayed, press ENTER key to enter this selection. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 54: Selecting Transfer Mode (Relay On Or Off)

    For Control Relay Phase A “high” phase assigns the relay setpoint to respond to increasing measured value; conversely, a “low” phase assigns the relay setpoint to respond to de- creasing measured value. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 55 S ET FU N C TION S ET TRA N S FER A C TIV A TION EX IT screen displayed, use ò ò key to 1. With the select the “ACTIVATION” line. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 56: Enabling/Disabling Passcode

    “MAIN MENU” branch selection screen. There is no limit on attempts to enter a valid passcode. The factory-set passcode is: 3456 To enable or disable the passcode feature: Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 57 2. Press ENTER key to display . Use ò ò and ñ ñ keys to view both choices (DISABLED or ENABLED). 3. With the desired choice displayed, press ENTER key to enter this selection. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 58: Summary Of Configuration Settings (Ranges/Choices And Defaults)

    0-20 mA or 4-20 mA All Outputs: 20 mA SET FILTER? 0-60 seconds All Outputs: 0 seconds SCALE 0mA/4mA? 0 mA or 4 mA All Outputs: 4 mA (Table B continued on next page.) Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 59 0-999.9 minutes 0 minutes Settings For Timer Relays Only: INTERVAL? 0-999.9 minutes 5 minutes DURATION? 0-999 seconds 5 seconds OFF DELAY? 0-999 seconds 1 second (Table B continued on next page.) Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 60 TEMPERATURE A, or TEMPERATURE B SIM SENSOR? D.O: 0-99.99 ppm, 0-99.99 mg/l or Present measured value of 0-999.9% sensor’s selected parameter (dissolved oxygen or TEMP: 0.0-50.0 ° C or 32.0-122.0 ° F temperature). Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 61: Calibrating The Analyzer

    100% saturated with air. The analyzer computes and displays the ppm value based on the entered atmos- pheric pressure or altitude, entered salinity of the 100% saturated process or clean water, and its temperature. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 62: Table C Comparison Of Calibration Methods

    (MEASURE screen appears). • Press ñ ñ or ò ò key to choose “ABORT: NO?” screen, and press ENTER key to continue calibration. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 63: Sample Cal Method

    C ON FIG U RE TES T/ MA IN T EX IT 1. Press MENU key to display 2. With the “CALIBRATE” line selected (shown in reverse video), press ENTER key to display: Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 64 D.O. value. 10. Press ENTER key to enter the value and complete cali- bration (CONFIRM CAL OK?” screen appears). 11. If using a container of process sample, re-install the sensor into the process. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 65: Air Cal Method (Highly Recommended)

    11.6 32.2 10.0 11.3 33.3 11.1 11.0 34.4 12.2 10.7 35.6 13.3 10.4 36.7 14.2 10.2 37.8 15.6 38.9 16.7 40.0 17.8 41.1 18.9 42.2 20.0 43.3 21.1 44.4 22.2 45.6 Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 66 This may take from a few up to 20 minutes. NOTE: If the D.O. reading is relatively stable, you can manually complete calibration by pressing the ENTER key while the “PLEASE WAIT” screen Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 67: Saturation Cal Method

    2. Press MENU key to display 3. With the “CALIBRATE” line selected, press ENTER key to display: 4. With the “SENSOR” (or “SENSOR A”) line selected, press ENTER key to display: Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 68 ENTER key to return the analog outputs and relays to their active states (MEASURE screen ap- pears). This completes “SATURATION CAL” calibration. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 69 7. With the desired choice displayed, press ENTER key to enter this selection. 8. With the sensor in the water (or process sample) and screen showing the active meas- urement reading, press ENTER key to confirm. After Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 70 C ON FIG U RE TES T/ MA IN T EX IT 2. Press MENU key to display 3. With the “CALIBRATE” line selected, press ENTER key to display: Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 71 “last measured” value. 10. Use ñ ñ and ò ò keys to adjust the displayed value to exactly match the known temperature value. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 72 When the reading corresponds to the actual typical process value, press ENTER key again to return the analog outputs and relays to their active states (MEASURE screen appears). This completes “2 POINT SAMPLE” temperature calibration. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 73: Analog Outputs (1 And 2) Calibration

    6. The displayed value is “counts” -- not mA -- that dynamically change when the output is adjusted. Use a calibrated digital multimeter to measure Output 1’s actual minimum value provided at OUTPUT 1 Terminals 1 and 2 on TB1. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 74 (fine adjust) to adjust Output 1’s maximum value to read exactly “20.00 mA” on the digital multimeter -- not the analyzer display. 12. Press ENTER key to complete calibration of the maximum endpoint value. This completes Output 1 calibration. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 75: Test/Maintenance

    4. With the “STATUS” line selected, press ENTER key to display the “STATUS: ANALYZER OK” screen. This screen confirms that the analyzer is operating properly. If “FAIL” appears, it may mean: Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 76 TIME OFF interval time before turning on. (Relay not energized; annunciator is off.) NOTE: TIME OFF only applies to timer relays. 7. To end relay status checking, press ESC or ENTER key. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 77: Holding Outputs

    3. Press ENTER key again to reset all overfeed timers (“OVERFEED RESET: DONE” screen appears, ac- knowledging reset has occurred). 4. To return to the “TEST/ MAINT” top-level menu screen, press ESC or ENTER key. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 78: Providing Output (1 And 2) Test Signals

    A should be de-energized. Confirm this by checking the NO and NC relay output terminals with a continuity meter. 5. To end this test and return to the “TEST/MAINT” top- level menu screen, press ESC or ENTER key. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 79: Checking Eprom Version

    Sensor B dissolved oxygen value or temperature value. 3. With the desired choice displayed, press ENTER key to enter this selection and return to the “TEST/MAINT” top-level menu screen. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 80: Setting Simulation Value

    2. Press ENTER key to display the “RESET CONFIGURE: ARE YOU SURE?” screen, asking if you really intend to perform this extreme action. (If you want to abort this ac- tion, press ESC key now.) Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 81: Resetting Calibration Values To Factory Defaults

    -- not configuration settings -- to factory defaults (“RESET CALIBRATE: DONE” screen appears, ac- knowledging reset has occurred). 4. To return to the “TEST/MAINT” top-level menu screen, press ESC or ENTER key. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 82: Relay Overfeed Timer Feature

    A relay overfeed timer can, and often will, interact with other analyzer functions while those functions are in use. Table E Analyzer Functions on the next page explains common overfeed timer interac- tions. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
  • Page 83 (or a value you On relay is turned Overfeed timer simulate) causes the relay to turn off. “off” by simulation value was timed out Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 84: Hart Option

    Fax: [512] 794-8893 Website: www.hartcomm.org For information on the HART Communicator Model 275, contact: Fisher-Rosemount Systems 12000 Portland Avenue South Burnsville, Minnesota 55337-1535 USA Headquarters: [612] 895-2000 Service: [800] 654-7768 Fax: [612] 895-2244 Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 85: Analyzer Operating Modes For Hart Network

    HART-capable software (or software including GLI Device Specific Command sets). The GLI analyzer never initiates a command sequence, but always responds to commands from the master. Up to two master devices may be Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 86: Single Mode (Point-To-Point) Wiring Arrangement

    Wiring Arrangement Figure 3-3 and connect all devices, including up to two masters, to the 4-20 mA analog Output #1 signal. FIGURE 3-3 HART SINGLE MODE (Point-to-Point) Wiring Connections (for single analyzer) Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 87: Multi-Drop Wiring Arrangement

    Output #1 signal, matching polarity as shown. 4. Connect up to two masters to the 4-20 mA analog Out- put #1 signal cable. FIGURE 3-4 HART MULTI-DROP Wiring Connections (for multiple analyzers) Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 88: Hart Preferences Setup

    The “Num req preams” information screen shows the num- Required Preambles ber of preambles required by the analyzer from the master. 1. With the “GLI SETUP” top-level menu screen displayed, select the “HART INFO” line and press the key. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 89: Device Preferences Setup

    The “Model” information screen shows the model number of Model Number the analyzer. 1. With the “GLI SETUP” top-level menu screen displayed, select the “DEVICE INFO” line and press the key. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 90: Viewing Manufacturer

    4. Press the F4 key to enter the tag, and the F2 key to send the tag to the analyzer. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 91: Assigning A Descriptor

    “DEVICE INFO” line and press the key. 2. With the “DEVICE INFO” submenu screen displayed, select the “Date” line and press the key to display its related information screen. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 92: Viewing Revisions

    3. With the “DEVICE REVISION” sub-submenu screen dis- played, select the appropriate line and press the to display its related information screen. 4. Press the F4 key to return to the “DEVICE INFO” sub- menu screen. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 93: Master Reset" Function

    PC Programming limited operability. The Device Specific Command set for all existing GLI analyzers is available on request for creating a full-featured HART-capable program to run on an IBM- compatible PC. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 94: General Information

    -- or -- • Replace the complete scaling board assembly contain- ing the relays. Refer to Part Five -- Spare Parts -- for the GLI scaling board assembly part number. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 95: Preserving Measurement Accuracy

    Cut cables to proper length during installation to avoid unnecessary inductive pickup (“electrical noise” may interfere with sensor sig- nal). Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 96: Troubleshooting

    3. Note the analyzer reading now and compare it with the reading taken in step 1. If the reading changed, a ground loop exists. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 97: Isolating Measuring System Problem

    POSSIBILITY OF ELECTRICAL SHOCK. 1. After disconnecting line power and the sensor(s) from the analyzer, connect a 1% tolerance, 30K ohm resistor between SENSOR A Terminals 14 (black) and 15 (yel- low) on TB1. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)

  • Page 98: Verifying Interconnect Cable Integrity

    1. Use a digital multimeter to check the interconnect cable Cable Integrity for shorted or open wires. Replace the interconnect ca- ble if necessary. 2. Check the junction box connections for moisture or cor- rosion. Replace the junction box if necesary. Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...

  • Page 99: Analyzer Repair/Return

    (Recommendation: Use the original GLI shipping carton or an equivalent.) Also, GLI will not accept analyzers returned for re- pair or replacement unless they are thoroughly cleaned and all process material is removed. Rev. 0-599 Model D53 D.O. Analyzer (universal-mount 1/2 DIN)
  • Page 100 With HART option........D53A2010-004 Power Supply/Scaling Board Assembly..D53A2020-001 Ribbon Interconnect Cable......1000A3355-001 Fuse Kit (one 80 mA fuse and one 100 mA fuse per package) ......1000G3315-101 Mounting Hardware Kit........ 1000G3228-101 Model D53 D.O. (universal-mount 1/2 DIN) Rev. 0-599...
