- Page 1 INSTRUCTION MANUAL Stallion 300 Clipper PLEASE REFER TO THIS INSTRUCTION MANUAL BEFORE USE PO Box 260 Botany NSW 1455 Ph: (02) 9700 0800 Email: info@shearmagic.net.au Fax: (02) 9700 1171 Website: www.shearmagic.net.au ABN 31 128 341 980...
- Page 2 COMPONENT NAMES...
- Page 3 Do not operate the clipper with a damaged cord or after the appliance has been dropped or damaged in any manner. If damage is suspected, return the appliance to a Shear Magic Service Agent (See below). Do not use the clipper with an extension cord unless the cord has been checked and tested by a qualified electrician.
- Page 4 STALLION 300 CLIPPER SETTING THE BLADES: Check the setting of the blades to be sure they are in the correct position. When correctly set, the top blade should be set back 1.5mm to 2.0mm from the ridge on the bottom blade (Fig 1).
- Page 5 BEFORE BEGINNING TO CLIP Make sure the switch on the side of the clipper is in the "OFF" position. Then insert the plug into an electrical outlet. Slide the switch to the "ON" position and begin clipping. MAINTENANCE OILING AND CLEANING THE BLADES: Keep the clipper blades oiled and clean well while clipping.
- Page 6 MAINTENANCE Keep the motor drive and clipping heads clean. It is recommended that you remove the blades after use and clean them thoroughly. Lubricate the heads and blade cutting surfaces while in use and after use. Keep the air filter free of hair and dirt. Keep blades, comb and cutter sharp for maximum efficiency and long life.
- Page 7 upper blade by sliding it out from under the tension spring (do not loosen tension spring screws) and wiping the mating surfaces of the blades clean. Slide the upper blade back into position, re-assemble back on the clipper and apply a light film of oil to the blades (preferably with the clipper running).
- Page 8 THE SHEAR MAGIC ONE YEAR WARRANTY All Shear Magic clippers come with a full one year warranty from date of purchase against any manufacturing fault. As you would expect, the warranty does not cover the following: ■ Normal wearing parts (lever, latch, hinge, nameplate, bearings, blade etc) ■...
