Summary of Contents for WINYCAM LOG

  • Page 1 WINYCAM Vehicle Drive Recorder User Manual www.winycam-eng.com...

  • Page 2: Table Of Contents

    3-22. REC Time 3-5. LED Operation 3-23. Specification 3-6. Voice Guide 4. FAQ 3-7. PC Original Viewer Program Installation 3-8. PC Original Viewer – Screen Configuration Warranty 3-8. PC Original Viewer – Viewer Configuration 3-10. PC Original Viewer – Configuration WINYCAM LOG...

  • Page 3: Safety Precautions

    Off. applied when product is unused.) Do not use the product in places in high temperature/humidity. Do not exert excessive force to the product (especially to LCD buttons and to bracket) as it may cause breakdown. WINYCAM LOG...
  • Page 4 LED is turned off, the last recording file may not be saved, so please be careful. When turn off the power of the body and remove the SD card before LED is turned off, the last recording file may not be saved, so please be careful. WINYCAM LOG...

  • Page 5: Before Use

    Please read carefully before use. current state of the product, and may contain typographical errors or omissions. LOG is an auxiliary product to alert users for safe driving and prevent accidents, by Contents of this User Manual may be recording video during driving.

  • Page 6: Product Feature

    GPS. (In the function On/Off can be set in PC viewer) general video player (e.g. Windows media player), recorded video can be played) Each capacity of a normal / event/ motion folder can be set in PC Viewer. WINYCAM LOG...

  • Page 7: Package

    2-2. Package Standard Package LOG Body Cigar Lighter Micro SD card SD Card Adaptor WiFi Dongle Rear(D1)Camera Rear Camera Video Cable Bracket 3M tape for bracket USB Card Reader Option Accessories Video Splitter Cable Null Cable External GPS (Y-Type) The viewer program is included in the micro SD card.

  • Page 8: Product Parts

    2-3. Product Parts Wi-Fi USB Jack GPS Jack DC Jack Rear Camera Jack (TV-OUT) Bracket Front Camera Speaker Security LED SD Card Slot Power Power LED REC LED Mute Urgent REC WINYCAM LOG...

  • Page 9: How To Use

    3-1. Front Camera Installation 1. Insert Micro SD card to LOG SD card 2. Remove the protect sticker. 3. Connect Cigar lighter cable to Power slot. (Check the SD card direction) connection of product. 4. Attach the Winner in place on the 6.

  • Page 10: Rear Camera Installation

    4. Connect video cable 5. Check an operation 6. Arrange a front/rear camera cable Power on LOG and check to playback a REC video correctly. (The video splitter cable has to be connected when check it with TV-OUT.) ( ㅡ...
  • Page 11 ACC Line (Yellow) : Connect to Fuse Power Ground Line (Black) : GND 2. How to connect Video Splitter & Rear camera Cable (TV-OUT) Connect TV-Out terminal TV-Out signal line Video Splitter Cable Rear camera connection cable (Y-Type) WINYCAM LOG...

  • Page 12: Gps / Tv-Out Cable Installation

    AV-IN jack your car splitter cable(Y-Type) LOG body. and tidy up a cable. navigation. on a LOG body. (Please refer 10P) Caution on GPS Installation Caution on TV－OUT Connection GPS module may be affected by main body or by When connecting to your vehicle navigation, you need an other electronic devices if it is too close each other.

  • Page 13: How To Record

    30 sec during added during constant added during constant connecting to the fuse cable) motion detect) motion detect) ※ 수동으로 주차모드 전환하여 녹화하다가, 다시 상시 녹화 녹화로 전환 하는 방법은 모션 대기 중에 수동 이벤트 녹화 버튼을길게 3초 누르면 됩니다. WINYCAM LOG...

  • Page 14: Led Operation

    1.5 sec Red flashing interval Red flashing interval No micro SD Card at 0.5 sec at 0.5 sec (including an error) Green flashing Green flashing SD Card Format interval at 0.5 sec interval at 0.5 sec WINYCAM LOG...

  • Page 15: Voice Guide

    “Normal recording will now end.” Alarm tone in a Rear Camera disconnect “Ding-Dong Ding-Dong Ding-Dong” (the error for 2CH REC) ※ Only when event REC mode is set in the configuration, the voice guiding "event recording will start" will announce WINYCAM LOG...

  • Page 16: Pc Original Viewer Program Installation

    DirectX Support (WPF) 2. Install Download the latest Winy BB Viewer from our website (http://www.winycam-eng.com) If you run “setup.exe”, Winy BB Viewer will be installed And then, installation will be continued according to the installation sequence of setup dialog box.
  • Page 17 1. NEXT 2. Select file location and click “Next” 3. NEXT   4. Installing 5. Complete installation ※ Installation may take a long time depending on PC usage environment. WINYCAM LOG...

  • Page 18: Pc Original Viewer - Screen Configuration

    3-8. PC Original Viewer – Screen Configuration 2 3 4 5 6 13 14 15 16 19 20 WINYCAM LOG...
  • Page 19 Playback File Location Brightness / Contrast REC file list / Map Display GPS signal condition Playback Video Image Driving Speed Playback Control Latitude / Longitude Full Screen G-sensor Information Flip Horizontal Split Image Flip Vertical File Skip Back WINYCAM LOG...

  • Page 20: Pc Original Viewer - Viewer Configuration

    3-9. PC Original Viewer – Viewer Configuration WINYCAM LOG...
  • Page 21 App Always Top Select App is always the top of another window. Video Reverse Video can reverse from side to side and up and down Product Model Select the model. Video Adjustment Control playback speed Volume Control recording volume level WINYCAM LOG...

  • Page 22: Pc Original Viewer - Configuration

    3-10. PC Original Viewer – Configuration 1 WINYCAM LOG...
  • Page 23 Select a breaking voltage for a constant power discharge production function Video-Out Format Select TV-Out format Front LED Setting Select front security LED function REC Channel Select a recording channel Time Setting Set the current time. Set Time? The time setting will be applied to LOG. WINYCAM LOG...
  • Page 24 3-10. PC Original Viewer – Configuration 2 WINYCAM LOG...
  • Page 25 Select Brightness, Chroma. Back to default value after click sensor initialization SD Card Folder Select the capacity of each recording mode in SD card Capacity Adjustment LOG synchronizes the time automatically according to the standard time Standard Time setting with GPS Summer Time Apply a summer time.

  • Page 26: Configuration Default Setting

    Motion Adjustment(%) Parking Mode G-sensor 3(Middle) Event Voice Guide Volume Level Standard Time +09:00 REC Volume Level Summer Time Breaking Voltage 12.2(24.3)V Video Out Format NTSC Front LED Setting REC Channel Time Setting PC Setting value Set Time? WINYCAM LOG...

  • Page 27: Playback (Standard Video Player)

    (Parking mode) evtxx : Event record which is detected a shock Note by shock sensor. GPS Information is displayed in the original viewer. You can check only front REC when playing by standard video player. WINYCAM LOG...

  • Page 28: Playback (Pc Original Viewer)

    P : Parking REC file list 3) Original Viewer Program Click icon for the original viewer 4) Find a REC file location Click “FILE LOCATION” in original viewer on upper right. Choose file location, video file list will be shown WINYCAM LOG...

  • Page 29: Playback (Tv/Can Navigation)

    Please check the TV / Vehicle navigation supplier for an external monitor cable. Mode change method is different for each modes, please refer user manual of TV / Vehicle navigation. Note If remove or insert TV Out cable during recording, recording will end and start reboot. WINYCAM LOG...

  • Page 30: Smartphone Wi-Fi -Download

    - Wi-Fi USB Dongle is optional. - Please check Wi-Fi signal or the setting if the application can’t search LOG for the first connection. - When [Internet Service Check] menu is “On” on Wi-Fi setting, try again after changing to “ Off ”...

  • Page 31: Smartphone Wi-Fi - How To Set Ios

    3-16. Smartphone Wi-Fi Setting – iOS 1. Turn on Wi-Fi on the Smartphone configuration menu. WCBB_xxx 2. Select ‘ ’ network on the Wi-Fi list. 00000000 3. Press ‘Connect’ after enter the password [ WINYCAM LOG...

  • Page 32: Smartphone Wi-Fi - How To Use

    Wi-Fi list will be shown when pressing “START” Available Wi-Fi list will be displayed. Press “Firmware Check” and download the latest Press ‘WCBB_xxx’ and “NEXT” firmware. 3. Main 4. Live view Select the command from the menu. Live video shows F/R (Front/Rear video change) WINYCAM LOG...
  • Page 33 Select the files and press ‘Download’ on the top, Downloaded REC file list shows. then REC video can be downloaded to Smartphone. After selecting files, playback and delete REC video Select a number of files, consecutive download is files are available. available. WINYCAM LOG...
  • Page 34 The device firmware version shows. Change or initialize the setting, please press Available to upgrade firmware version if the device ‘ Transmit ’ button. firmware is lower than the latest one. SD Card format is available in real time. WINYCAM LOG...

  • Page 35: Smartphone Wi-Fi - Variable Bitrate

    Reconnect to the parking mode after applying the wifi bitrate, parking REC guidance will Live View Connection announce after “Diriring-” alarm. Parking Reconnect to the parking mode after changing to the normal bitrate after 30 seconds, parking Live View Exit REC guidance will announce after “Diriring-” alarm. WINYCAM LOG...

  • Page 36: To Save Video File On Your Pc

    2) Go to the folder where recorded video files are stored. 3) Create the new folder in same location. 4) Drag the particular file to the new file to copy. (If you drag a folder, the whole folder will be copied.) WINYCAM LOG...

  • Page 37: Firmware Upgrade

    2) Backup all files that are stored in the files to your PC. 3) Download the latest firmware from our website (http://www.winycam-eng.com) and copy to a SD card. 4) Insert the SD card to Winner. After power ON then firmware will be updated automatically.

  • Page 38: Rec Time

    By mode : Total record files are stored by your setting rate on “SD card Folder Capacity Adjustment”. Note When memory is full on a particular recording mode, the oldest file will be automatically deleted on particular recording mode. Stored file may also be deleted. WINYCAM LOG...

  • Page 39: Specification

    High Temperature View angel Cut-off Rear : 89.9(H) x 64.9(V) x 120.3(D) OFF, 11.4V(23.1), 11.6V(23.4) Breaking Voltage External GPS Module (Option) 11.8V(23.7), 12.0V(24.0), 12.2V(24.3) Operating Power Input DC 12V~24V -20℃ ~+70℃ Temperature Storage Battery Super Capacitor -20℃ ~+85℃ Temperature WINYCAM LOG...

  • Page 40: Faq

    3. If the constant power protect function is set ‘OFF’, monitoring during parking will be performed only for a certain period of time. If the vehicle battery voltage is lowered for self-protection, power to the device may be disconnected even in the Parking Mode disabling the recording. WINYCAM LOG...

  • Page 41: Warranty

    Warranty 1. The products are manufactured through the strict quality control and inspection process. 2. The defect occurring in normal use of user within the warranty period will be repaired free of charge. 3. If the warranty period has passed, we will repair by paid charge. 4.
  • Page 42 WinyTechnology Co., Ltd. www.winycam-eng.com...
