  • Page 1: User Manual

    HS-66M Cautions: 1. Digital Extender® logo is our own trademark of RTcom USA.,Inc. 2. HDMI is a trademark of hdmi.org 3. Any of the products may be changed without any notice in order to improve the function of the product.

  • Page 2: Table Of Contents

    Table of Contents 1. BASIC UNDERSTANDINGS OF THE PRODUCT ....................3 1-1 C ............................3 AUTIONS FOR SAFETY 1-2 P ..............................4 ACKAGE NCLUDES 1-3 F ............................ 4 EATURES OF THE PRODUCT 1-4 N ........................5 AMES AND FUNCTIONS OF EACH PART 1-5 I ......................

  • Page 3: Basic Understandings Of The Product

    1. Basic understandings of the product 1-1 Cautions for safety • All the safety and user manual should be read before the appliance is operated. • The safety and operating instructions should be retained for future reference. • Unplug this product from the wa ll outlet before cleaning.

  • Page 4: Package Includes

    1-2 Package Includes • Main body: HS-66M • Power adapter: DC12V, 5A 60 • RS232C cable/ LAN cable • Rack Ears • User’s manual • IR Remote Controller 3 Features of the product The HS -66M HDMI Matrix Router supports the highest quality of HDMI version 1.3 and full matrix routing...

  • Page 5: Names And Functions Of Each Part

    1-4 Names and functions of each part < FRONT & BACK PANEL > In tallation environments and methods For installation, we recommend the following environments. • Below 85 F (30°C) of ambient temperature (Best condition) • Install and operate in the envir onment below 60% of ambient humidity (Best condition) •...

  • Page 6: Functions Of The Product

    . unctions of the product 2-1. System operation configuration diagram The configuration diagram of the matrix operation is shown in following picture. Any of the HDMI or DVI input signals can be selected to each output port by external RS-232C, LAN or fro panel button.

  • Page 7: Three Stack Configuration

    2-2 Three Stack Configuration This equipment receives signals (6 input ports) from HDMI output ports or equipments compliant to HDMI specification and sends out to any of output ports. It can receive up to 24 input signals in a 3 stack onfiguration and give out to any of 6 output ports.

  • Page 8: Pecifications Of The Product

    2-3 pe cifications of the product • Type of signals: TMDS signals, digital R.G.B. & Audio • Data transmission band: up to 2.25 GHz. • Resolutions: Up to 1080p@60Hz,1080i/720p@120Hz, 2k, • 12/24/30/36-bit, RGB YC bCr, 4:4:4, 16/20/24/30/36-bit YCbCr, 4:2:2, 8/10/12-bitYCb Cr 4:2:2 •...

  • Page 9: Product Number Setting

    -> Input 1 -> Output 1,2,3,4 -> Enter ve EDID data nect HS-66M matrix with display directly DID (EDI ) button → Select one of output # button(whic h is connected with display) → Input # button to be set(one o r multiple) →...

  • Page 10: Rs-232C(Com Port) Communication Setting

    is not available. **The product ID is set number “1” at the time of its deliver y (Factory Default). 3-3 RS-232C(COM PORT) communication setting After booting the matrix, connect RS-232C cable and then ake communicat ion settings as follows: • Execute M niTerm.exe or hyper terminal.
  • Page 11 From Matrix Code (4Byte) Head (1byte) | Address (1Byte) | PN (1Byte) | Tail (1Byte) Code Name Byte Data Function Head (Start) Reply Frame Start Start Header 30h (0) Request Frame Start Start Header 1h (1) est Frame Star Product ID 30h ~ 39h (DIP Sw itch Set) Product Number...
  • Page 12 DID SW ASSIGN SALVO : change all EDID data Input1 Input2 Input3 Input4 Input5 Byte Header Command Output Output Output Output Output ASCII Input6 Byte Tail Output ASCII ASSIG NMENT TA TU RE UE ST : che the ta s tus of present input/output channels Byte Header Command...

  • Page 13: Lan (Tcp/Ip) Communication Setting

    4-2 LAN (TCP/IP) communication setting In order to control the matrix through LAN, intern et IP address should be set first. Set up as follows: -Execute MultiTerm.exe or hyper terminal program -RS-232 setting for communication with matrix. After setting as above, please connect communication cable via RS232 and then turn on Press ‘C’...
  • Page 14 Set up IP Address D key is displayed existing matrix network address information. G key is input gateway IP address S key is input subnet mask key is input matrix IP address H key is input hardware address all inputs are completed, then exit the configuration by press E key. Connect matrix to your network via LAN 1.
  • Page 15 Copyright 2007 RTcom USA., Inc.

  • Page 16: Connector Pin Assignment

    4-3 Connector Pin Assignment Power Input Part No. Pin No. Description Remarks VCC( DC12V) Power Jack(4P) VCC(DC12V) RS-232C Input Part No. Pin No. Description Remarks Not used Rx D Tx D Not used D-SUB 9 Pin Connector Not used Not used Not used Not used LAN Input...

  • Page 17: Warranty Information

    5 Warranty Information 5-1 One Year Warranty RTcom USA warrants each product to be free from defects in workmanship and materials, under normal use and service for a period of one (1) year from the date of purchase from RTcom USA. If a product does not work as warranted during the applicable warranty period, RTcom USA shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund customer the purchase price paid for the defective product.
  • Page 18 Memo Copyright 2007 RTcom USA., Inc.
  • Page 19 © 2007 RTcom USA, Inc. All Rights Reserved Copyright 2007 RTcom USA., Inc.
  • Page 20 Revision2 RTcomUSA, Inc Locations RTcomUSA. Inc. 286 Houses Corner Road Sparta, NJ 07871 USA Tel: 1-973-383-4878 Fax: 1-973-383-1160 www.digitalextender.com For order support, please contact your Distributor or Reseller. For technical support, check with the Email: rtcomusa@earthlink.net info@digitalextender.com Copyright 2007 RTcom USA., Inc.
