Summary of Contents for Highland RIDGE RV

  • Page 1 0276622.2017 PRINTED ON RECYCLED PAPER...

  • Page 3: Table Of Contents

    Change Of Address/Ownership Dealer Responsibility Suggestions For Obtaining Service Customer Relations Highland Ridge RV Travel Club Highland Ridge RV Customer First Emergency Roadside Assistance Obtaining Service For Separately Warranted Items Obtaining Service at Highland Ridge RV Replacement Parts ccupant afety...
  • Page 4 able of onTenTs Rear Vision Camera (If So Equipped) Leveling the RV Lippert Auto Leveling System (If So Equipped) Stabilizer Jacks Emergency Stopping Emergency Towing Wheel Lugs Tires Changing A Tire Travel Trailer Set Up Loading the Cargo Area Loading the Front Cargo Deck (If So Equipped) Fig.
  • Page 5 able of onTenTs Propane Regulator Using The Propane System Calculating Propane Gas Usage Cooking With Propane Gas Traveling with Propane Ensure a supply of fresh air (Canada units only) Cooking / comfort heating label Re-fueling Warning Label lumping yStem Plumbing System Maintenance Monitor panel Command center panel Monitor panel...
  • Page 6 Cleaning Your Refrigerator Washer/Dryer Prep (If So Equipped) lectrOnicS HDTV Antenna (If So Equipped) HDTV antenna Enclosure base & signal meter Power injector Television Power Supply (If So Equipped) TV Power Supply nteriOr Cleaning The Interior Décor Items Sofa Free-Standing Table & Chairs (If So Equipped) Booth Dinette (If So Equipped) Cabinetry &...
  • Page 7 Nothing in this manual creates any warranty, either expressed or implied. The only warranty offered by Highland Ridge RV is as set forth in the limited warranty applicable to this vehicle. The owner’s failure to provide required service and/or maintenance could result in the loss of warranty.

  • Page 9: About This Manual

    & S arranty ervice Congratulations! Thank you for selecting a Highland Ridge RV. We are excited to welcome you to our growing RV family. Enjoy the journey! bout AnuAl This manual is a guide to operation of the features, equipment and controls in your recreation vehicle.

  • Page 10: Reporting Safety Defects

    & S arranty ervice  Indicates a potential situation that,if not avoided, may result in property damage or damage to your motor home.  Indicates a potentially hazardous situation that, if not avoided, may result in minor or moderate injury. It may also be used to alert against unsafe practices. ...

  • Page 11: Manufacturing Process

    Highland Ridge reserves the right to discontinue or change specifications or design at any time without notice and without incurring any obligation whatsoever. Recreation vehicles built for sale in Canada may differ to conform to Canadian Codes.

  • Page 12: Dealer Responsibility

    At the time of sale of the new recreation vehicle, your Highland Ridge dealer is expected to: Deliver your recreation vehicle in the best condition possible. Your recreation vehicle must pass the dealer’s pre-delivery inspection (PDI), including all systems tests.

  • Page 13: Customer Relations

    All owners of Highland Ridge recreation vehicles are eligible to participate in the Highland Ridge RV Owner’s Club. The club promotes family camping and the active use of your RV with others who have similar interests in the RV lifestyle. By belonging to the Highland...

  • Page 14: Highland Ridge Rv Customer First Emergency Roadside Assistance

    & S arranty ervice Ridge RV Travel Club, you will find new ways to enjoy your RV and make friends all across the country. Additional information on the Highland Ridge RV Owner’s Club can be found at www. openrangeowners.com. rv c...

  • Page 15: Obtaining Service For Separately Warranted Items

    Should your RV be in need of service, and your dealer recommend that the repairs be made at the Highland Ridge RV Factory Service Center, your RV may be returned to us with the following guidelines*: You or your dealer must make a confirmed appointment a minimum of 60 days prior to dropping off your RV at the Highland Ridge RV Factory Service Center.

  • Page 16: Towable Transferable Limited Warranty

    RV is delivered to the first retail purchaser by an independent, authorized dealer of Highland, or, if the dealer places the vehicle in service prior to retail sale, on the date the RV is first placed in such service. In the event that a substantial defect in material or workmanship, attributable to Highland, is found to exist during the warranty periods, it will be repaired or replaced, at Highland’s option, without charge to the RV owner, in accordance...
  • Page 17 Highland directly, in writing, at the above address, of the unsuccessful repair(s) of the alleged defect(s) so that Highland can become directly involved in making sure that you are provided service pursuant to the terms of this limited warranty.
  • Page 18 RV purchased through auction or wholesale; any RV purchased from a dealer that is not an authorized dealer of Highland; normal wear, tear or usage, such as tears, punctures, soiling, mildew, fading, or discoloration of exterior plastic or fiberglass, or soft goods, such as upholstery, drapes, carpet, vinyl, screens, cushions, mattresses and fabrics;...
  • Page 19 Highland, or any agent of Highland, shall be interpreted as an extension of the warranty or this limitation period. Some states do not allow a reduction in the statute of limitations, so this reduction may not apply to you.
  • Page 20 & S arranty ervice Notes:...

  • Page 21: S Afety Secondary Means Of Escape (Exit Window)

    ccupant afety econDAry eAns of scApe inDoW Your recreation vehicle has been equipped with a window(s) that serves as a secondary means of escape. The window(s) will allow a quick exit from the vehicle during an emergency if access to the main entrance door is not available. It is easily identified by the red latches and label.

  • Page 22: Fire Safety

    ccupant afety Lever style latch Remove the screen by pulling the red tab (upper right arrow). Pull the lever out from the sash clamps. Swing the lever out so it is positioned straight out from the window. Push the lever (and window) out to open and exit the vehicle.

  • Page 23: Smoke Alarm

    ccupant afety Inspection and maintenance Read and follow all instructions on the label and user’s manual provided by the fire extinguisher manufacturer. Inspect the extinguisher at least once a week (more frequently if it is exposed to weather or possible tampering). This should also be done before beginning a vacation or during an extended trip.

  • Page 24: Smoke Detector Warning Label

    ccupant afety indicate the battery is functioning properly. When the production of combustion is sensed, the smoke detector sounds a loud alarm that continues until the air is cleared. The LED light will also give a visual indication of a sounding alarm. How to test Stand at arm’s length from the smoke alarm when testing as the alarm horn may be harmful to your hearing.

  • Page 25: Combination Carbon Monoxide/ Propane Alarm

    ccupant afety  Only use the replacement battery recommended by the smoke detector manufacturer. The smoke detector alarm may not operate properly with other batteries. Never use a rechargeable battery as it may not provide a constant charge. Never disconnect the battery to silence the alarm. Regardless of the manufacturer’s suggested battery life, you MUST replace the battery once the smoke alarm starts “beeping”...
  • Page 26 ccupant afety Carbon monoxide (CO) is an insidious poison. It is a colorless, odorless and tasteless gas. Many cases of reported carbon monoxide poisoning indicate while victims are aware they are not feeling well, they become so disoriented they are unable to save themselves by either exiting the vehicle or calling for assistance.
  • Page 27 ccupant afety Do not re-enter the premises or move away from the open door or window until the emergency service responders have arrived, the premises have been aired out, and your alarm remains in its normal condition. If your alarm reactivates within a 24-hour period, repeat steps 1-4 and call a qualified appliance technician to investigate for sources of carbon monoxide from fuel burning equipment and appliances, and inspect for proper operation of this equipment.

  • Page 28: Lp/Carbon Monoxide Detector

    ccupant afety  Test the alarm operation after the RV has been in storage, before each trip and at least once per week during use. The TEST/RESET button tests all ELECTRICAL functions of the alarm. The TEST/Mute switch is located on the front of the alarm. Press and hold the test button for 1 second. The alarm is working properly if the GREEN indicator light changes color to RED and the horn beeps 4 times.

  • Page 29: Formaldehyde

    ccupant afety orMAlDehyDe Some components in the recreation vehicle contain formaldehyde-based adhesives that may release formaldehyde fumes into the air for an unknown period of time. Individuals who are allergic to formaldehyde gas fumes may experience irritation to eyes, ears, nose and throat. Indoor air quality may also be affected by leaving your vehicle closed for a period of time.

  • Page 30: Condensation

    ccupant afety onDensAtion  Condensation may cause dampness, mildew, mold, staining and, if allowed to continue, it may result in damage to the recreation vehicle (damage caused by condensation is not warrantable). It can also lead to mold or mildew issues, which could be a health hazard.

  • Page 31: Tow Vehicle

    ravel nfOrmatiOn ehicle If you plan to tow your recreation vehicle with a tow vehicle you already own, contact your automotive dealer to find out your vehicle towing capacity. If you plan to purchase a new tow vehicle, be certain to tell your automotive dealer the GVWR, size and type of recreation vehicle that you will be towing (some tow vehicles can be purchased with an optional tow package).

  • Page 32: Weight And Capacity Labels

    ravel nfOrmatiOn eight AnD ApAcity Abels There are 3 main types of labels that can be found on the exterior of the trailer, usually on the roadside front corner of the trailer. Labels at this location will be a Federal Certification label, an Occupant &...

  • Page 33: Loading Your Recreation Vehicle

    ravel nfOrmatiOn oADing ecreAtion ehicle  Never load the RV in excess of the GAWR for either axle. Overloading your RV may result in adverse handling characteristics and damage to the chassis.  Your recreation vehicle’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available space when loading the vehicle.
  • Page 34 RV combination. Highland Ridge cannot be responsible for the suspension system of any tow vehicle. There are a variety of tow vehicle suspension systems available that will affect the ball height, stability and levelness of a hooked up RV.

  • Page 35: Travel Trailer Weight Distributing System (Customer Supplied)

    ravel nfOrmatiOn rAvel rAiler eight istributing ysteM ustoMer upplieD A weight distributing hitch system provides a more stable tow vehicle/RV combination. This system will spread the weight evenly to distribute it to the tow vehicle front and rear axles and the trailer axle. Consult with your dealer to familiarize yourself with the operation and requirements of the weight distributing hitch system.

  • Page 36: Wire Harness/Connector Plug

    ravel nfOrmatiOn 11. Plug in your wire harness/connector plug from the tow vehicle to the travel trailer. 12. Walk around the RV to verify exterior lights are working correctly. 13. Remove the trailer wheel blocks. NOTE: If an Atwood brake actuator is used with an equalizing hitch, be sure the hanger chains hang between straight down and forward up to 34°.
  • Page 37 ravel nfOrmatiOn  DO NOT EXCEED YOUR GVWR! This means you should weigh your RV as loaded for your normal travel to determine the actual weight.  If you exceed the GVWR, you MUST remove items from the RV, or drain liquids, then re-weigh the vehicle to ensure you have achieved a safe weight.
  • Page 38 ravel nfOrmatiOn manufacturer of your tow vehicle. If this overall weight is greater than the GCWR, some contents must be removed to bring the combination into compliance with the listed ratings. Weigh the RV while attached to but excluding the tow vehicle. This will result in the actual weight that is exerted on all of the RV tires.

  • Page 39: Towing

    ehicle peratiOn oWing  Your RV braking system is rated for operation at GVWR not GCWR.  Whenever possible, do not travel with waste in the holding tanks. Liquid or debris in the holding tank(s) may affect the towing characteristics and may result in property damage or personal injury.

  • Page 40: Towing Behind Your Rv

    ehicle peratiOn have not been affected. Never operate any vehicle if a difference in braking efficiency is noticeable. Vehicle Clearance Remember some bridges, older ones in particular, may not support the weight of your tow vehicle/RV combination. Know the weight and size of your towing combination and observe any posted weight and clearance limits.

  • Page 41: Rv Brake System

    ehicle peratiOn rv b rAke ysteM  Failure to maintain the brakes in proper working condition as specified in the operator’s manual supplied by the axle OEM will cause property damage, personal injury and possibly death. Consult with your dealer for assistance. The electric brakes are designed to work with the tow vehicle brakes.

  • Page 42: Travel Trailer Breakaway Switch

    ehicle peratiOn Brake controller (customer supplied) The brake controller should be installed in the tow vehicle to work in conjunction with the RV electric brakes. Consult with your dealer or the brake controller OEM to decide what is right for your towing combination. rAvel rAiler reAkAWAy...

  • Page 43: Rear Vision Camera (If So Equipped)

    ehicle peratiOn not inside the vehicle before you close and lock the entrance door. NOTE: Locks on entrance and baggage doors need biannual lubri- cation using a light coat of silicone spray. Conditions such as rain, salt, dust and pollution may increase the maintenance needs. ision AMerA quippeD...

  • Page 44: Leveling The Rv

    ehicle peratiOn NOTE: For extended dry camping, management of all your re- sources is essential. Check your battery levels and conserve battery power, use it sparingly. eveling the Now that you have parked your recreation vehicle, you need to ensure it is level. Leveling is very important.
  • Page 45 ehicle peratiOn  FAILURE TO ACT IN ACCORDANCE WITH THE FOLLOWING WARNINGS MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH! NEVER LIFT THE RECREACTION VEHICLE COMPLETELY OFF THE GROUND. LIFTING THE RV SO THE WHEELS ARE NOT TOUCHING THE GROUND WILL CREATE AN UNSTABLE AND UNSAFE CONDITION AND MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH.
  • Page 46 ehicle peratiOn Leveling control panel callouts Up arrow - scrolls up through the menu on LCD Down arrow – scrolls down through the menu on LCD Enter – Activates modes and procedures indicated on LCD Retract – places leveling system into retract mode. Press and hold down for (1) second to initiate auto retract LCD display –...

  • Page 47: Stabilizer Jacks

    ehicle peratiOn The rear jacks con only be extended when the touch pad is in the manual mode. Once system is in manual mode, pressing the “REAR” button will extend both rear jacks at the same time. To extend individual rear jacks, press the “LEFT” or “RIGHT” button while simultaneously pressing the “REAR”...

  • Page 48: Emergency Stopping

    ehicle peratiOn  Objects in the camera view are closer than they appear. When backing up, proceed cautiously and be prepared to stop. Mergency topping Always carry road flares or reflective warning signs to display if necessary. Pull off the roadway as far as possible for emergency stopping or tire changing.
  • Page 49 ehicle peratiOn Tighten the lug nuts equally in stages as indicated for your recreational vehicle wheels (see Wheel Lug Torque Chart). Check and re-torque after the first 10, 25 and 50 miles (16, 40 and 80 kilometers). Thereafter, check and maintain the torque according to the listed torque values (see Wheel Lug Torque Chart.) NOTE: The proper method of tightening wheel lug nuts is with a properly calibrated torque wrench and socket, not with an impact...

  • Page 50: Tires

    ehicle peratiOn  Check and tighten wheel lug nuts regularly to make sure they did not loosen during travel. Wheel lug nuts must be applied and maintained at the proper torque levels to prevent loose wheels, broken studs and possible separation of the wheel(s) from your recreation vehicle.
  • Page 51 ehicle peratiOn  It is recommended that the tire pressure be checked at the beginning of each trip to obtain the maximum life of the tire. Follow the instructions listed on the Federal Certification label, affixed to the roadside front corner of your trailer, to determine the correct tire pressure.

  • Page 52: Changing A Tire

    ehicle peratiOn hAnging  Do not use the stabilizer jacks to support the recreational vehicle while under the vehicle or changing tires. The stabilizer jacks are designed as a stabilizing system only. Do not use the stabilizer jacks as a jack or in conjunction with a jack.

  • Page 53: Travel Trailer Set Up

    Any service or warranty coverage on tires is to be handled by the tire store representing the brand installed on your RV. They are not to be returned to your dealer or Highland Ridge. ...

  • Page 54: Loading The Cargo Area

    ehicle peratiOn Install the dolly wheel or platform. Release the weight distributing bars (customer supplied). Open the tongue jack coupler latch. Turn the tongue jack crank to raise the coupler above the hitch ball. Level the RV (front-to-back) with the tongue jack crank. 10.
  • Page 55 ehicle peratiOn  Failure to comply with weight capacities and distribution could result in an accident or loss of control resulting in death of serious injury. Make sure all vehicles/items in the cargo area have been secured with the proper tie down straps and the cargo door is locked prior to transit.

  • Page 56: Loading The Front Cargo Deck (If So Equipped)

    ehicle peratiOn door. If more clearance is needed, the end sections can be unhooked from the side rails by releasing the velcro tab(s), and extending the end rails straight out along the sides of the ramp door. After loading the vehicle, re-attach the end rails to the side rails with the velcro tab(s) (if they were extended).

  • Page 57: Fig. 1

    ehicle peratiOn Vehicles should only be loaded using the combination rail/ramps supplied with the RV. Ramps should be placed off of one of the angled sides at the front of the deck (Fig. 1). Fig. 1  Exercise extreme caution during loading and unloading of vehicles on the front deck.

  • Page 58: Patio "Party" Deck (If So Equipped)

    ehicle peratiOn “p ” D Atio Arty if so equippeD Your unit may be equipped with a patio (party) deck complete with folding rails. The maximum weight capacity of the patio deck is 1500 pounds. This weight capacity is based on evenly distributed load.
  • Page 59 ehicle peratiOn rubber “pedal” (arrow in Fig. C). Push the “pedal” down with your foot, and slide the round aluminum foot on the railing into the slot. Release the pedal, and the aluminum railing support will securely latch into place in the bracket.

  • Page 60: Patio Awning

    ehicle peratiOn Loading a vehicle in the cargo bay: NOTE: Before loading the cargo area, refer to the Loading the Cargo Area section of this manual for detailed and important loading, weight and weight distribution information.  All vehicles and cargo stowed in the rear cargo area must be secured with tie down straps while in transit.
  • Page 61 ehicle peratiOn  It is recommended that if leaving the recreation vehicle unattended for a length of time, retract the awning to avoid unexpected climate conditions. Refer to the manufacturer’s user guide included in your Warranty Packet for operating and safety information.
  • Page 62 ehicle peratiOn Notes:...

  • Page 63: Electric Slide Room System (If So Equipped)

    lideOut yStem lectric liDe ysteM quippeD  Make sure the interior slideout room path and the slideout room itself is clear of people and objects before operating. Keep away from the slide rails and gear assembly when the room is in motion. They may pinch or catch on loose clothing causing personal injury.

  • Page 64: Slideout Systems

    lideOut yStem overlap the side of the seal to avoid the possibility of water penetration. On the inside seal, the side seal should overlap the top. Retracting slideout room Press the IN section of the slideout control switch and hold it until the motor stops.
  • Page 65 lideOut yStem The auxiliary battery (customer supplied) must be fully charged and connected. If possible, the recreation vehicle should be hooked up to 120-volt AC power so the converter operates. The recreation vehicle must be level and the stabilizer jacks in the extended position. Slideout switches are typically located on the inside of the recreation vehicle, either in the command center panel or on the wall.
  • Page 66 lideOut yStem Remove any obstructions before proceeding. Error Codes: Refer to error codes explained previously along with instructions on how to locate the inwall slide controller. Low Voltage: The inwall slide controller is capable of operating the room with as little as 8 volts. But at these lower voltages the amperage requirement is greater.
  • Page 67 lideOut yStem approximately 5 seconds. The red and green LED’s will begin to flash indicating you are in override mode. Release the mode button. Use either a wall switch, or one of the slide room switches located on the command center panel (depending on the slideout).
  • Page 68 lideOut yStem When the room is completely in, plug both motor connectors back into the control module. This will apply the motor brakes for road travel. Disengage motors, manually retract the room and travel lock Locate and remove the motor retention screw which can be found near the top of each vertical column (Fig.
  • Page 69 lideOut yStem Although the system is designed to be almost maintenance free, actuate the room once or twice a month to keep the seals and internal moving parts lubricated. Check for any visible signs of external damage after and before movement of the travel trailer. NOTE: For long-term storage it is recommend the room be closed (retracted).

  • Page 70: Fig. 3-Hex Head Crank Extension

    lideOut yStem  The gears can be stripped out if the room is manually retracted/extended to its fullest extent and the operator continues to rotate manual override. Any damage due to misuse of the Manual Override feature will disqualify any and all claims to the Limited Warranty.
  • Page 71 lideOut yStem Electric Operation  Always make sure the slideout room path is clear of people and objects before and during operation of the slideout room. Always keep away from the slide rails when the room is being operated. The gear assembly may pinch or catch on loose clothing causing personal injury.
  • Page 72 lideOut yStem  When the motor brake is disengaged the slideout room WILL NOT lock into place; therefore, the room will not be sealed. When the room has been manually retracted, be sure to install the transit bars (if so equipped) and return the motor brake lever to its normal engaged position in order to seal and lock the room into position.
  • Page 73 lideOut yStem the rear of the motor) about 1/8 of a turn to the released position (Fig. 2). This will release the brake that holds the room in place. Locate the manual override for the slideout system (Fig. 1). The room is now free to move. Using either a 5/8” or 3/4” wrench or socket, crank the room either in or out completely.
  • Page 74 lideOut yStem Notes:...

  • Page 75: The Electrical System

    lectrical yStemS lectricAl ysteM The RV electrical system is comprised of two independent electrical systems. One operates off of 12-volt DC power and the other off of 120-volt 60hz AC power. All installations have been made in compliance with industry standards applicable on the date of manufacture. Because the electrical equipment and associated circuitry are engineered into a dedicated system specific to your RV, we recommend you do not make unauthorized changes or add fixed appliances to it.

  • Page 76: Gfci Receptacle

    lectrical yStemS gfci r eceptAcle Grounding is your personal protection from electrical shock. Each recreation vehicle has a ground fault current interrupter (GFCI) engineered into the electrical system. This device has been designed to reduce the possible injury caused by electric shock. The GFCI will not protect against short circuits or circuit overloads.

  • Page 77: 50-Amp Power Cord (If So Equipped)

    lectrical yStemS circuits, or that shows outward signs of heat damage. Injury or damage resulting from connection to malfunctioning or improperly wired power sources is not covered by your recreation vehicle warranty. Campsite 120-volt power receptacles can be tested using a digital multimeter or a dedicated circuit analyzer.

  • Page 78: Connecting The Power Cord

    lectrical yStemS onnecting oWer  Plugging the shoreline power cord into an incorrectly wired power source could damage the recreation vehicle electrical system and result in severe or fatal injury. Always test the external power source (i.e., the campsite power receptacle or electrical box) with a ground monitor before connecting your power cord to it.

  • Page 79: 120-Volt Circuit Breakers

    lectrical yStemS  Do not hook up the power cord to any receptacle until you have verified proper polarity and grounding. Polarity indicators can be purchased in most electrical and hardware stores. Do not use any cheater plug, adapter or extension cord to reconfigure incoming AC power or break the continuity of the circuit connected to the grounding pin.
  • Page 80 lectrical yStemS Replacement Only replace circuit breakers with those of the same specified type, voltage, and current rating. Never replace a circuit breaker with one listed at a higher amperage rating. Please contact your dealer for repair assistance when replacing circuit breakers. ...

  • Page 81: 12-Volt Dc System

    lectrical yStemS the reverse polarity fuse(s) in the Load Center. There are no customer serviceable parts inside the converter case and the manufacturer’s warranty will be void if the case has been removed. If you have further concerns contact your dealer. Dc s volt ysteM...

  • Page 82: Auxiliary Battery (Customer Supplied)

    lectrical yStemS  Keep the protective dust cap on the 12-volt DC outlet when not in use to prevent ingestion of foreign material and potential short circuit conditions. uxiliAry Attery ustoMer upplieD Your recreation vehicle has many 12-volt DC loads. When combined, their total is more than the converter can produce.

  • Page 83: Battery Isolator For Your Tow Vehicle (Customer Supplied)

    lectrical yStemS Attery solAtor ehicle ustoMer upplieD You may want to consider the installation of a battery isolator on your tow vehicle as a convenience feature: It receives current from the tow vehicle alternator and controls distribution of energy to both the RV auxiliary battery and the tow vehicle battery.
  • Page 84 lectrical yStemS 120 Volt System Air Conditioner 18 AMPS Coffee Maker 6-12 AMPS Converter (each) 8 AMPS DVD System 3 AMPS Fireplace 12 AMPS Hair Dryer or Curling Iron 10-14 AMPS Microwave 12 AMPS Refrigerator 6 AMPS Satellite Receiver 2 AMPS 2-4 AMPS Vacuum Cleaner 8 AMPS...
  • Page 85 lectrical yStemS STOP the generator immediately if there is a fuel, exhaust or coolant leak and have it repaired!  CARBON MONOXIDE IS DEADLY! MOVING PARTS AND ELECTRICITY can cause severe personal injury or death. To reduce exposure to these hazards, always disable AGS (if so equipped) before: Sleeping in vehicle, unless vehicle has a working CARBON MONOXIDE detector.

  • Page 86: Replacing Light Bulbs

    lectrical yStemS Exercising Your Generator – it’s also very important to run your generator regularly, to keep everything in good working order and in the case of gasoline sets, to avoid fuel varnishing, which can affect performance, if the generator is stored for an extended time. Lack of exercise can cause moisture build-up and fuel system degradation that make it run poorly.

  • Page 87: Fuel Station (If So Equipped)

    & p rOpane yStem tAtion quippeD Automotive Fuel Safety Your recreation vehicle may be equipped with a single factory-installed fuel tank that supplies fuel to the optional fuel station and/or optional generator. For your protection and others, it is critical to understand the danger associated with fuel. Take time to become educated about the property of fuel and use it safely.

  • Page 88: Fuel Nozzle In Contact With Receiving Tank

    & p rOpane yStem Read, understand and follow all safety information in the fuel station manufacturer’s manual before operating the fuel station. If you need further assistance, consult with your dealer or Customer Service. Fuel filler cap  Do not replace the fuel fill cap with one of a different type. Use of a substitute cap may create excessive fuel system pressure, resulting in fuel station damage and improper operation in a collision.

  • Page 89: Fuel Tank(S) (If So Equipped)

    & p rOpane yStem ) (i quippeD  Before filling the RV fuel tanks(s), be sure the RV is level from side to side and front to back to avoid potential overfilling. DO NOT over fill the factory- installed fuel tank(s). Once the pump has shut off by itself, do not try to put more fuel in the tank.

  • Page 90: Propane Gas System

    & p rOpane yStem Do not run the tow vehicle engine, generator engine (if applicable), etc., in confined areas, such as a closed garage, any longer than needed to move your RV in or out of the area. Windows should be closed while driving or running the generator (if so equipped) to avoid drawing dangerous exhaust gases into the RV.

  • Page 91: Propane Leak Test

    & p rOpane yStem Continued periodic checks of the propane system at 5,000 miles of travel (or at least once a year), by a qualified propane service representative as part of your normal maintenance is recommended. Hand tighten the LP gas system valves only, do not use a wrench or pliers as over tightening may damage the valve seals and cause them to leak.

  • Page 92: Installing Propane Cylinder(S)

    & p rOpane yStem nstAlling ropAne ylinDer  Ensure that all fasteners are secured before traveling. Located in a recessed compartment or housing (if so equipped) Two propane cylinder Connect the 3/8” low-pressure hose to the outlet of the two-stage regulator. Place the cylinder on the bracket in the recess compartment or housing and secure them so the outlets of the cylinder valves are facing the “sidewalls”...
  • Page 93 & p rOpane yStem Maintenance Propane gas is normally non-corrosive - you need not worry about the inside of your container. However, the outside should be kept free from rust by a periodic coat of paint in a light reflective color. Rust, scratches and/or dents can affect the safety of the cylinder. Inspect the cylinder at regular intervals.

  • Page 94: Propane Regulator

    & p rOpane yStem ropAne egulAtor  Propane regulators must always be installed with the regulator vent facing downward. Regulators that are not located in baggage compartments have been equipped with a protective cover. Make sure the regulator vent faces downward and (if applicable) the cover is in place to minimize vent blockage that could result in excessive gas pressure causing fire or explosion.

  • Page 95: Calculating Propane Gas Usage

    & p rOpane yStem Make sure that you read and fully understand ALL safety requirements for handling and operation of the propane system. The Warranty Packet contains manufacturer’s user guides for the various appliances hooked to your propane system. The propane system provides added benefits to your camping enjoyment; however, it must be handled with care.

  • Page 96: Traveling With Propane

    & p rOpane yStem  Do not use portable fuel burning equipment (i.e., wood and charcoal grills or stoves) inside the recreation vehicle. Unlike homes, the amount of oxygen supply is limited due to the size of the recreation vehicle. Proper ventilation when using the cooking appliance(s) will help you avoid the danger of asphyxiation.

  • Page 97: Re-Fueling Warning Label

    & p rOpane yStem The label listed below should be kept permanently affixed to your recreation vehicle: Re-fueling Warning Label...
  • Page 98 & p rOpane yStem Notes:...

  • Page 99: Plumbing System Maintenance

    lumping yStem There are two different water systems in your recreation vehicle: The fresh water system consists of the fresh water holding tank, fresh water connections, water pump, outside shower assembly (if so equipped), water heater, faucets, tub/ shower, and water purification system (if so equipped). The waste water system consists of the waste water holding tank, sewage holding tank, drains and toilet.

  • Page 100: Fresh Water System

    lumping yStem or “GRAY2” switch, one or more LED lights will illuminate (from left to right) indicating the content level for that tank. When pushing the “BATT” switch, the LED lights illuminate from left (lowest) to right (highest) to indicate the estimated auxiliary battery condition. NOTE: When using shore power all 4 LEDs will light.

  • Page 101: Fresh Water Holding Tank

    lumping yStem  Never travel with full fresh, black or grey water holding tanks. resh Ater olDing There may be several ways to fill the fresh water tank depending on the model. For details of each method, refer to the Fresh Water Connections or the Utility Center (if so equipped) sections.

  • Page 102: Water Pressure Regulator (Customer Supplied)

    lumping yStem will stay on. The water pump automatically recycles when pressure drops. Some cycling may occur depending on the volume of water being released. Turn the water pump switch OFF when it is not in use. NOTE: If there are multiple pump switches; the pump must be turned off from the same switch used to turn it on.

  • Page 103: Utility Center

    lumping yStem tility enter Your recreation vehicle is equipped with an exterior utility center that contains the following items: A city water connection inlet A fresh water connection inlet A black tank flush connection inlet An outside shower with detachable hose A 120VAC GFI receptacle A 12V light fixture Hookups for satellite and cable TV...

  • Page 104: Water Heater

    lumping yStem Black Tank Flush Connection The black tank flush inlet is used to aid in cleaning out the black water (sewer) tank. One end of a hose (do not use your fresh water hose) is connected to the inlet, the other end to a pressurized water source.
  • Page 105 lumping yStem  Hydrogen gas may result if you have not used the water heater for two weeks or more. HYDROGEN GAS IS EXTREMELY FLAMMABLE. To reduce the risk of injury under these conditions, open the hot water faucet for several minutes at the kitchen sink before you use any electrical appliance connected to the hot water system.
  • Page 106 lumping yStem High altitude deration Operation of the water heater at high altitudes may require derating. If the water heater is not properly derated, lack of sufficient oxygen for combustion may produce improper burner operation. Pilot outage caused by burner lift-off or sooting from a yellow burner may occur, indicating the possibility of carbon monoxide.

  • Page 107: Water Valve Operation/Water Heater Bypass

    lumping yStem Draining and winterization: If the recreation vehicle is to be stored over the winter months, the water heater must be drained to prevent damage from freezing. Damage to the water heater caused by freezing is not warrantable. It is recommended the water heater be drained and bypassed during the winterization process, particularly if introducing RV antifreeze into the plumbing system.

  • Page 108: Fig. B - Water Heater Bypass (2 Valves)

    lumping yStem Fig. A - Water valves (configured for Normal Fig. B - Water Heater Bypass (2 valves) Operation) Normal Operation For normal operation with the pump ON, water is pulled from the water tank and into the water lines (Fig. A). Valve 1 (siphon valve) should be pointing away from the siphon hose.

  • Page 109: Outside Shower (If So Equipped)

    lumping yStem utsiDe hoWer quippeD A handheld shower assembly with both hot and cold water may be included for use outside of your recreation vehicle. Be sure the water heater is ON and had sufficient time to heat the water. Open the outside shower compartment door.

  • Page 110: Bathroom Tub / Shower

    lumping yStem  Water temperatures over 125°F (49°C) can cause severe burns instantly or death from scalds; therefore, be careful when using hot water. Always test the water temperature before showering or washing. AthrooM hoWer The shower faucet includes a vacuum breaker for the shower. There are two purposes for this breaker: To prevent siphoning water through the hose from another fixture.

  • Page 111: Draining The Fresh Water System

    lumping yStem rAining the resh Ater ysteM Permanent water tanks may be drained through a valve located near the tank. An RV with a demand pressure pump system will have low-point drains attached to the water lines (normally located near the water tank). These low-point drains will release water in the supply lines by opening the valves and all faucets.
  • Page 112 lumping yStem How to sanitize Turn water heater power OFF at the command center (both switches: electric and LP gas). Turn the water heater gas valve OFF (located outside the RV). Bypass the water heater (valve 4 OFF, valve 5 ON). Level the RV and drain the fresh water system (see Draining the Fresh Water System).
  • Page 113 lumping yStem Valve 3 should be turned OFF. 12. Turn the water pump ON. Sanitized water will be drawn out of the fresh water tank into the water lines when a fixture is opened. 13. Open all hot water faucets one by one until water begins to flow continuously and a chlorine smell is noticeable.
  • Page 114 lumping yStem Lingering Chlorine Taste: If a chlorine taste lingers in the water, flush the water system with a solution consisting of one-quart vinegar to five gallons of clean water. Re-flush as necessary. The vinegar solution may damage the water heater so it must be bypassed again before performing this operation.

  • Page 115: Winterizing The Plumbing System

    lumping yStem interizing luMbing ysteM  Automotive antifreeze (ethylene glycol) and windshield washer antifreeze (methanol) are poisonous. Never use these products in your fresh water system. These products are harmful and may be fatal if swallowed. Preparing your RV for colder weather or storage is very important for most states and Canada.

  • Page 116: Water Valves And Pump

    lumping yStem Water Heater valves Water valves and Pump Turn water heater power OFF at the command center (both switches: Electric & LP Gas). Turn water heater gas valve OFF (located outside the RV). Bypass the water heater (Valve 4 OFF, Valve 5 ON). Level the RV and drain the fresh water plumbing system.

  • Page 117: Black/Grey Water System

    lumping yStem NOTE: In the spring when flushing antifreeze out of the water lines make sure to turn valve 2 (the fresh water tank shutoff) back ON. Rotate Valve 2 so it points toward the fresh water tank line. If needed, contact your RV dealer for assistance. lAck Ater ysteM...

  • Page 118: Black/Grey Water Holding Tanks

    lumping yStem the RV. By adding water and using a RV approved deodorizing agent you will dissolve the contents faster and will keep the drain lines and tanks clean and free flowing. These chemicals are available at an RV supply store or your dealer. Drain pipes With Dry Sealing Valve (If So Equipped): Your RV may be equipped with a dry sealing valve that prevents the escape of odors from your waste system and eliminates the need for P-traps.

  • Page 119: Black & Grey Tank Drains

    lumping yStem  Whenever possible, do not travel with waste in the holding tanks. Liquid or debris in the holding tank(s) may affect the towing characteristics and may result in property damage or personal injury. & g lAck rAins There are labels on the exterior of the recreation vehicle indicating the location of the grey tank drain and black tank drain (also called dump valves).

  • Page 120: Black Tank Flush

    lumping yStem tank, such as baking soda or an approved RV chemical, will reduce odors from food particles in the system. Cleaning & Maintenance: The toilet should be cleaned regularly for maximum sanitation and operational efficiency. Use only RV approved chemicals. Do not use chlorine (undiluted) or caustic chemicals, such as laundry bleach or drain opening types, in the toilet system.
  • Page 121 lumping yStem toilet several times to release sufficient water into the holding tank. If there is not a sufficient amount of water used during flushing, the waste materials may not evacuate properly from the drain line to the tank. Clogged tanks and pipes could eventually occur. The toilet system will perform better when water is run for ten to fifteen seconds after flushing to ensure that the waste will proceed to the bottom of the tank.
  • Page 122 lumping yStem Notes:...

  • Page 123: Air Conditioner

    & c eating OOling onDitioner Roof Mount (If So Equipped) The roof mounted air conditioning system is controlled by a thermostat. Cooled air enters the RV through the adjustable “chill grill.” Make sure you have sufficient power available before operating the air conditioner. Do not operate the air conditioner without the return air filter.

  • Page 124: Ceiling Fan (If So Equipped)

    & c eating OOling be raised or lowered with the UP/DOWN buttons, and the speed of the fan is controlled by the ARROW buttons. It is also equipped with a rain sensor that will close the vent automatically when it rains. The rain sensor can be turned on/off by holding the DOWN button for 3 seconds.

  • Page 125: Fireplace (If So Equipped)

    & c eating OOling  The furnace should be inspected periodically (monthly during the heating season) for presence of soot on the vent. Soot is formed whenever combustion is incomplete. This is a visual warning that the furnace is operating in an unsafe manner.
  • Page 126 & c eating OOling Notes:...

  • Page 127: Microwave

    pplianceS icroWAve NOTE: To prevent damage, remove the turntable from the micro- wave when traveling. NOTE: Make sure you are connected to a 120-volt power source.  Never use the microwave cavity for storage. The microwave cavity should always be empty when not in use. Microwave Oven Use For list of preset programs, see the Quick Reference Guide provided with your model.

  • Page 128: Kitchen Range & Oven (If So Equipped)

    pplianceS & o itchen Ange quippeD  During and after use, do not touch or let clothing or other flammable material come in contact with the top burners (or heating elements), burner grates or other areas near the top burners or oven until they have had sufficient time to cool.

  • Page 129: Cooking With Propane

    pplianceS NOTE: To help reduce potential condensation or unwanted cooking odors, turn on the overhead kitchen roof vent or the range hood vent (if so equipped). ooking ropAne See the Propane System Section for important safety instructions. Refer to the manufacturer’s owners manual for detailed operating and safety instructions for all propane appliances.

  • Page 130: Cleaning Your Refrigerator

    pplianceS  The ice maker (if so equipped) should be turned off and the ice tray emptied when power to your recreation vehicle has been shut off. With no power, the ice will melt and water may “pool” in the refrigerator door. When power is restored, the vibration may cause this water to run out of the door and on to the vehicle floor.

  • Page 131: Washer/Dryer Prep (If So Equipped)

    pplianceS Stainless steel exteriors: wash with a clean sponge or soft cloth and a mild detergent in warm water. Do not use appliance wax, polish, bleach, or other products containing chlorine on stainless steel. Stainless steel can be cleaned with a commercially available stainless steel cleaner.
  • Page 132 pplianceS Notes:...

  • Page 133: Hdtv Antenna (If So Equipped)

    lectrOnicS hDtv A ntennA quippeD Enclosure base & signal HDTV antenna Power injector meter Your recreation vehicle may be equipped with an exterior amplified high definition TV antenna. The antenna comes equipped with a signal meter and a power injector to aid in receiving the strongest possible signal when tuning in HDTV stations.

  • Page 134: Television Power Supply (If So Equipped)

    lectrOnicS Refer to the HDTV manufacturer’s manual for detailed operating and safety information. elevision oWer upply quippeD For good station reception, the TV power supply must be turned ON to view local television stations. Turning the TV power supply ON sends 12-volt DC through the cable to the TV roof antenna.

  • Page 135: Cleaning The Interior

    nteriOr leAning nterior To keep the value of your recreation vehicle, perform regular maintenance using the proper materials and procedures. Using the wrong cleaner may result in damage to the surfaces in your vehicle. Check with the manufacturer’s information for the recommended cleaning agent.

  • Page 136: Sofa

    nteriOr To remove stuck on dust or stains refer to the following guide. Solar shields: Use a sponge or soft brush and water to remove stains. A mild cleaning solution can be used to remove tougher stains. Rinse after cleaning by wetting a clean cloth in fresh water, wringing our any excess and wiping the areas where the cleaner was used.

  • Page 137: Free-Standing Table & Chairs (If So Equipped)

    nteriOr 2. Using the strap handle, pull 1. Remove tri-fold sofa pillows and set aside sleeping surface up, then out. 3. While sleeping surface is up, gold out legs. 4. Once sleeping surface is grounded, fold headboard Extend sleeping surface until grounded. down flat.

  • Page 138: Cabinetry & Tables

    nteriOr & t Abinetry Ables To keep hardwood doors, cabinet fronts and hardwood tables looking like new regularly dust with a soft cloth dampened with a cleaning polish or mild detergent solution. Avoid using ammonia based products or silicone oils as they may cause damage if used over a long period of time.

  • Page 139: Interior Wall Panel

    nteriOr removed by squeezing fresh lemon juice over the stain and allowing the juice to soak for approximately forty-five minutes. After 45 minutes, sprinkle baking soda over the lemon juice and rub with a soft cloth. Solid surface countertops (if so equipped) Solid surface materials are easy to care for, and if damaged, easy to repair.

  • Page 140: Abs Plastics

    nteriOr Absorb wet spills as quickly as possible by blotting repeatedly with white paper or cloth towels. Refer to the manufacturer’s guide included in your Warranty Packet for detailed cleaning information, or contact a cleaning professional. Vinyl flooring Periodically vacuum or sweep to remove dirt and gritty particles. Although most common spills will not permanently stain the vinyl floors, they are usually easier to remove if wiped up before they set.

  • Page 141: Cleaning The Exterior

    xteriOr leAning xterior To protect your recreation vehicle’s exterior finish, wash it often and thoroughly. For recreation vehicles with painted exterior graphics: If desired you may wash and wax your vehicle 60 days after purchase. The exterior paint does need time to cure before any wax is applied to the exterior surface.
  • Page 142 xteriOr from the surface. Do not use solvent based cleaners on bird droppings or tree sap as these are water based stains. They can be dissolved using ammonia based glass cleaner, warm soapy water and a little “elbow grease”. Once again, after removing stubborn stains immediately rinse with clean water.

  • Page 143: Frame

    xteriOr Polishing your recreation vehicle If painted surfaces have been severely damaged and have lost their original luster and color tone, polish the surface lightly with a fine polishing compound. Avoid limiting your polishing to the damaged surface only; polish a somewhat wider area, moving the polishing cloth in one direction.

  • Page 144: Exterior Roof & Sidewall Vents

    xteriOr NOTE: The convenient lubrication provisions of the E-Z lube or Super-lube feature must not replace periodic inspection and mainte- nance of the bearings. Use a hand-operated grease gun; improper use of a commercial grease gun may damage the seals. &...

  • Page 145: Toy Hauler - Sealant Diagram

    xteriOr You or your dealer must: Inspect all sealants, a minimum of every six months. Make sure to check the roof and all four sides of the recreation vehicle including al moldings, doors, vents and exterior attachments. A quick walk around the recreation vehicle before leaving may help prevent potential problems during trips and vacations.
  • Page 146 xteriOr Notes:...

  • Page 147: Rv Start-Up

    ravel amping tOrage heckliStS rv s tArt The following checklist will help ensure a trouble-free camping season: Inspect and work all interior and exterior latches and locks (lube if necessary). Make sure the batteries are fully charged and installed correctly. Inspect the power cord and carefully clean the contacts if necessary.
  • Page 148 ravel amping tOrage heckliStS Counter items put away or tied down. Furnace turned off. Latch drawers, cabinets & doors. Turn off interior lights and appliances. Disconnect any cable TV or phone hookup, and lower the TV antenna (if so equipped). Move slideout(s) in and lock it in place (if so equipped).

  • Page 149: Rv Storage

    ravel amping tOrage heckliStS Each Trip Inspect and reseal as needed. Check the auxiliary battery (If so equipped). Have the propane system checked for leaks by your dealer. Check running lights. Check tire pressure and wear, including spare (if so equipped). Make sure the tires are cold when checking the tire pressure.
  • Page 150 ravel amping tOrage heckliStS Thoroughly wash the interior and the exterior of your RV. To prevent weather checking and other UV damage, cover tires that are exposed to sunlight. Turn all cushions on edge to prevent the moisture/mildew buildup during storage. Turn off 12-volt DC/120-volt AC/propane to the refrigerator;...

  • Page 151: Vehicle Maintenance Record

    ravel amping tOrage heckliStS ehicle AintenAnce ecorD Make: Model: Model Year: Vehicle Serial#: Service Performed Mileage Work Performed Notes Date...
  • Page 152 ravel amping tOrage heckliStS Service Performed Mileage Work Performed Notes Date...
  • Page 153 ravel amping tOrage heckliStS Notes:...
  • Page 154 ravel amping tOrage heckliStS Notes:...
  • Page 155 Highland Ridge Ownership Notification Fax Form To: (800) 825-7876 ATTENTION! Federal record keeping laws require that we maintain a file of owners of our product. Your cooperation in filling out this from will be appreciated. □...

Table of Contents

Save PDF
