- Page 1 User manual EVBIKE - LCD display C961...
-
Page 2: Base Settings
Carefully read the enti re manual prior to installati on and fi rst use! If you fi nd any fact in the manual that would prevent you from using our product, please contact your reseller for further discussion and keep the original packaging. The reseller will advise you how to proceed properly. www.ev-power.eu... - Page 3 The C961 display is made of ABS and is designed to perform well under -20º to 60º C. Available colors: Black. DIMENSION OF DISPLAY Size (Unit: mm). Pictures - LCD display, holder for LCD display. During instalation, is possible to use spacers to fill the gap between the handlebar and holder of the display.
- Page 4 • Remaining Battery Capacity • Speed (Speed/MAX/AVG) • Distance and Odometer (TRIP/TOTAL) • Time • Assist walking (slow speed motor assist) • Backlight • Error codes INTERFACE: Power Speed Mode Level Unit Walking Distance Time Unit TRIP BUTTON: Power on/off www.ev-power.eu...
-
Page 5: Walking Assist
Do not attempt to reset parameters if the display is not working. Call for service if the C961 display is not working. INSTALATION Install the display and button control on the handlebar and adjust its location. Plug it into the controller with power off. -
Page 6: Power Level
BACKLIGHT Press and hold to turn on the C961’s backlight screen. If a front light is configured as well, this will switch it on as well if front light available. Press and hold again to switch it off. Note: The automatic backlight is available only if the controller (or built-in controller) offers this function. -
Page 7: Trip Reset
When something goes wrong with system, an error code will flash on the display. Check details on attached list. The motor will stop working in the event of an error. Only when the error is gone, will the motor work again. EVBIKE - LCD display C961... - Page 8 Makes sure the connections are good, then power on. SETTING Press and hold to turn on the display. Press and hold the to set the mode UNIT Press to change unit Km or Mile. Press to save and go to set speed. www.ev-power.eu...
-
Page 9: Setting The Speed Limit
To limit the speed range (from 15Km/h to 40Km/h), press to change the limit up or down. Press to save & go to set backlight. BACKLIGHT Press to change the brightness (range is 1 to 8). Press to save & go to time setting. EVBIKE - LCD display C961... -
Page 10: Advance Setting
The settings go into effect after restart. ADVANCE SETTING Press and hold to start the display. Press and hold both to enter setting mode. Press and do not release, meanwhile press eight times to go to the advanced setting menu. www.ev-power.eu... -
Page 11: Wheel Size Setting
0 to 60 minutes. Display will sleep and cut off power after no operation on system for the selected time. Press to save and skip to level amount setting. EVBIKE - LCD display C961... - Page 12 Power level amount setting Press to change the amount. The range from 0 – 3 to 0 – 9 levels. Press to save and exit. The settings go into effect after restart. www.ev-power.eu...
-
Page 13: Error Codes
Chybová hlášení Vysvětlení Throttle not returning to zero state Throttle abnormality Low voltage protection Over voltage protection Hall sensor abnormality Phase line abnormality Controller overheat Temperature sensor in controller abnormality Current sensor abnormality Speed sensor abnormality EVBIKE - LCD display C961... - Page 14 EVBIKE - LCD display C961 Importer do EU: GWL Power Ltd. 3rd fl oor, 207 Regent street, London, W1B 3HH United Kingdom...
