FROM HUAYUAN TO YOU
Thank you for choosing products of Huayuan.
●
This instruction manual is designed to help you install, debug, operate
●
and maintain. So when using the equipment, thoroughly read it and
associated manuals introduced in it. Also pay careful attention to safety
and handle the equipment properly. We've made installation and
operation quick and easy. With Huayuan you can count on years of
reliable service with proper maintenance.
Please check the machine carefully when it arrives, if you find that the
●
machine is damaged in transportation or discordant with the packing
list, please call us as the following numbers ： +86-28-85011951
(85012443, 85013964).
The machine should be operated and maintained by the man who has
●
specialized training. If you have any technical problem, please contact
us.
●
The right of technology of the welding positioner belongs to
Co., Ltd specializes in manufacturing welding machines and auxiliary
equipment. For information on our other products, please call us by
86-28-8501195(85012443, 85013964), or visit our website at
http://www.hwayuan.com.
Chengdu Huayuan Electric Equipment Co., Ltd
www.w estweld .com
Huayuan Electric Equipment Co., Ltd. It is
forbidden to copy
third party. Otherwise it will be regarded as a
tort. Chengdu Huayuan Electric Equipment
the instruction manual to any
Chengdu
Advertisement
Table of Contents
Summary of Contents for Huayuan Electric HB-30
- Page 1 If you have any technical problem, please contact ● The right of technology of the welding positioner belongs to Chengdu Huayuan Electric Equipment Co., Ltd. It is the instruction manual to any forbidden to copy third party. Otherwise it will be regarded as a tort.
-
Page 2: Table Of Contents
www.w estweld .com TABLE OF CONTENTS Security Notes…………..……..…………………………….………….P.4-5 Summary …………………….………………….…….………………..P.6-7 Working Conditions ……………………………….……………………P.6-7 Technical Parameters ………….…………………….………………….P.8-9 Machine’s Structure………….…...……………….….……………..P.10-11 Operation Process …..………………………………………………. …P.12-13 Control System……..…..….……………………….……………………P.12-13 Installation & Debugging…….……………………….…………………P.12-15 Machine Maintenance…………………………………….……………..P.14-15 Packing List…………………………………..………..………………...P.16... -
Page 3: Security Notes
www.w estweld .com Security Notes The welding positioner must ground, and each electric connector must be firmly connected to keep good insulation. ……………………………………………………………………………... Welding arc is harmful to your body. Please wear necessary guard, such as veil, glove, work cap etc. ……………………………………………………………………………... -
Page 4: Summary
www.w estweld .com Summary HB series welding positioner is a electric-mechanical efficient equipment for automatic welding. It is always used in automatic welding of revolving work-pieces such as axes, disks, cylinders etc. It is especially fit for circle automatic welding, and it is used in other occasions where the work-piece position needs to be changed. -
Page 5: Technical Parameters
.com Technical Parameters Type definition HB-[]-[] “0”- normal type， “1”- special type Load, number×0.1=T Welding positioner Technical Parameters Type(型号) HB-30 Load(承重) 3000kg Gravity center(重心高) 300mm Eccentricity (偏心高) 300mm Revolving speed(旋转速度) 0.045-0.65rpm Reversal speed(翻转速度) 0.37rpm Gradient angle(倾斜角度) 120° Diameter of work table(工作台直径) 1400mm Power voltage(电源电压) -
Page 6: Machine's Structure
www.w estweld .com Machine’s Structure The product is made up of work table, machine body, rotation drive part, reversal drive part, electric system etc. machine body: The body is made of steel board by welding. There are two hooks for lifting itself up on the flank of the body. -
Page 7: Operation Process
www.w estweld .com Operation Process Firstly，drive the work table to horizontal position，and take the work pieces on the work table，fix and clamp it firmly. Reverse the work table to a suitable angle. Calculate the power frequency according to the required line-speed. -
Page 8: Machine Maintenance
www.w estweld .com Connecting the Power Cable (see figure below) Please connect the yellow/green cable to the ground. Chart 2 Debugging Connect the electric connector firmly, turn on the power, and then depress or stir the switch on the remote control box. Check all the actions of start, stop, left rotation, right rotation, forward reversal, backward reversal, so that you can check and ascertain whether the electric connector is right connected, and whether the limited switching is effective in the proper position. -
Page 9: Packing List
.com Packing List HB-30 Welding Positioner 1 set Input Power Cable 10 meters Electric Box 1 unit Remote Control Box 1 unit Control Cable 5 meters...
