Owner' s Manual
with Installation Instructions
1996 & Later Vehicles with OBDII Diagnostics
THIS MANUAL IS FOR USE WITH KITS 61195, 61196, 61201, 61202
Gale Banks Engineering
546 Duggan Avenue • Azusa, CA 91702
(626) 969-9600 • Fax (626) 334-1743
Product Information & Sales: (888) 635-4565
Customer Support: (888) 839-5600
Installation Support: (888) 839-2700
bankspower.com
©2016 Gale Banks Engineering
02/16/16 PN 97273 v.4.0
