  • Page 1 core powered by...
  • Page 2 To get started with Ride, install the Core device on your bike using this guide. When installing modules, refer to the respective guides. For more info, logon to ridescorpio.com/help...
  • Page 3 Download the app and signup for an account. Then, scan your ID and activate your subscription account. Ready to ride. Logon with the app and Rider Dash at ridescorpio.com/dash.

  • Page 4: Table Of Contents

    table of contents Components Plan an Install Mounting Switched Power 10–11 Attach GPS Plug in Core Testing the installation Accellerometer Programming 15–17 Troubleshooting...

  • Page 5: Components

    components Core Harness Hook & Loop Cable-ties Antenna Quick Connector...

  • Page 6: Plan An Install

    plan an install Make sure that the motorcycle battery is fully charged. Verify that no moving parts will interfere with the components. Do not route wires near sharp edges which could cut wires and create a short. Do not mount components near high heat sources such as the exhaust pipes.

  • Page 7: Mounting

    Select a suitable location under the seat or side cover that the module can lay as flat as possible. The Ride Core harness has three wires. You’ll need to connect these to your bike. Red: Install the terminal ring of this wire directly to the battery positive post.

  • Page 8: Switched Power

    switched power Common tail light power wires color Honda Brown, White w/stripe Kawasaki Suzuki Brown Yamaha Blue w/Red stripe Harley-Davidson Blue Ducati Yellow Locate the 12 volt switched wire source on your vehicle. The most common applications are the tail light power wire (not the brake light) or the license plate light power wire.
  • Page 9 White: Install this wire to a 12 volt switched source using the provided Quick Connector. For example: the tail light or license plate light power wire. Insert the hot wire in the slit of the smaller cap. Then, tighten onto the body of the connector. Remove the cap on the open end of the Quick Connector attached to the white wire of the installation harness.

  • Page 10: Attach Gps

    tech tip RIDE requires proper installation of the switched power wire to function correctly. Switched power is hot when the ignition is on, cold when off. Common switched power sources are the tail light, (NOT the brake light), the license plate light, and some accessory plugs.

  • Page 11: Plug In Core

    plug in core Plug the installation harness into the Ride module. Secure the module with the included hook & loop/cable ties. tech tip If the Red light and White light do not stay on solid when the ignition is on then there is a problem with the switched power (white wire) installation.

  • Page 12: Testing The Installation

    testing the installation Once the harness is plugged in confirm that there are lights illuminated on the Ride module to confirm you have good power and ground. Turn the ignition switch of the motorcycle to the “on” position. Confirm that a red light is now illuminated solid on the Ride module.
  • Page 13 accelerometer programing After the installation is complete and tested, unplug the Ride harness from the Ride module. Plug back in the Ride harness to the Ride module with the IGNITION ON to access Accelerometer Programming mode. During first 10 seconds the white LED will blink slowly to indicate countdown.
  • Page 14 Prog. Mode Accel. Mode White light flashes every 3 seconds to indicate programming mode. Red light flashes to indicate accelerometer sensitivity setting. Turn Ignition on/off to toggle through sensitivity levels. (1-5). Test shock with ignition off. Red LED will light for 1.5 seconds to indicate successful shock.
  • Page 15 tech tip RIDE includes a back-up battery to protect your motorcycle in case of theft. The back-up battery will power the device when disconnected from power. To disconnect the device without triggering the back-up battery, unplug the main harness within 5 seconds of turning on the motorcycle’s ignition.

  • Page 16: Troubleshooting

    troubleshooting Lights not appearing when Ride is plugged in? Check that the power and ground wires have a firm connection to the appropriate battery posts (see Mounting Components steps 3). Also verify that your battery is fully charged. Red light not appearing when the key is on? Check that the white wire is firmly connected to a 12v switch source.
