- Page 1 ARTROMOT ® Service Manual (New Generation) Starting from Serial number 3000...
-
Page 2: Table Of Contents
2. Purpose 1. History This service manual is to perform some repairs on ARTROMOT®-K3 products. Repair and maintenance work 2. Purpose may only be carried out by authorised persons, as other- wise all warranty services and liabilities shall be void. - Page 3 The Threaded spindle is not interchangeable with STOP RELEASE ERR: Stop line can not be released ARTROMOT®-K3 serial number < 3000. -> Remove hand-held programming unit or spiral cable (see chapter 7.2) if persistent Do not loosen the knurled handles completely for any adjustment.
-
Page 4: Packing And Unpacking
Put separate pads around the foot plate and frame to protect the device against vibration and damage. 5. Block diagram of electronic parts Controller for Display Hand-held programming unit Knee K3 motor control adjustment Power adapter... -
Page 5: Bill Of Material For Service Parts
6. Bill of material for service parts Position Description Order-Number Electronics Power adapter 115V / 230V 0.0031.107W Power cord USA - version to 0.0031.107W 0.0032.011 Power cord EU - version to 0.0031.107W 0.0032.012 Hand-held programming unit 0.0032.113 Rubber mat 2.0031.195 Sheet metal cover 2.0032.136 Motor electronics... - Page 6 2.12 Interior slit 2.0031.197 2.14 Exterior slit 2.0032.114 2.15 Exterior slit 2.0032.114 2.16 Bottom plate 2.0032.108 2.17 Attachment plate femur bow 2.0032.101 2.18 Attachment plate femur bow 2.0032.100 2.19 Thread plate M6 962.901 2.20 Pan head screw DIN912M6x8A2 2.21 Pan head screw DIN7984M5x25A2 2.22 Countersunk screw...
- Page 7 3.28 Spacer sleeve 0.0031.104 3.29 2.0031.188 3.30 Countersunk screw DIN7991M5x20vz 3.31 Screw thread pin DIN916M4x4sw 3.32 Screw thread pin DIN914M4x4sw 3.33 Countersunk screw DIN7991M4x10vz 3.34 Hexagonal nut DIN934M5vz 3.35 Pan head crew DIN912M5x6vz 3.36 Countersunk screw DIN7991M5x25A2 3.37 Countersunk screw DIN7991M5x55vz 3.38 Countersunk screw...
- Page 8 0.0031.147 Patient kits No illustration Patient kit fleece 2.0032.155 No illustration Patient kit cool-quilt 2.0032.155B No illustration Foot rest reconstruction K3 + K4 2.0032.012 No illustration Leg supports reconstruction kit K3 + K4 2.0032.013 No illustration Stereo jack connector 0.0032.200...
-
Page 9: How To Perform The Repair
If the reference run was interrupted the display shows: equipment. REFERENCE RUN INTERRUPTED (The ARTROMOT®-K3 stops) If you try to start the ARTROMOT®-K3 the display will show: DEVICE NEEDS REFERENCE RUN(The ARTROMOT®-K3 is inoperable) Performe a reference run. Exchange the defect printed circuit board. -
Page 10: Explosion Drawing Part
8. Explosion drawing part 1... -
Page 11: Explosion Drawing
9. Explosion drawing part 2... -
Page 12: Functiontest
100% Adjust a maximum femur length. 5. First press "STOP" and afterwards press "START". The ARTROMOT®-K3 should then reach both points of changing direction within 60 to 75 seconds. 6. Change the speed to 50% and afterwards press "START". The ARTROMOT®-K3 should then reach both points of changing direction within 105 to 120 seconds. - Page 13 ORMED GmbH & Co. KG • Merzhauser Straße 112 • D -79100 Freiburg Tel +49 761 4566-01 • Fax +49 0761 4566-5501 • www.ormed.de • E-Mail: info@ormed.de St. Paul/USA,Tel +1 800 4402784, Fax +1 651 4157405 • Wien/A, Tel +43 1 53 20 83 40, Fax +43 1 53 20 83 431 DIN EN 13485 ORMED Nr.
