11. When well trained in using the gun and rapid shooting is required, simply let the water
valve open and shot when the gun is filled. Use the refilling time to consider where to
place the next shot. For the extinguishing of smaller fires the gun can be filled with
smaller amounts of water simply by opening of the water valve for shorter periods or
through a faster shooting sequence.
12. Regular training and exercise with the IFEX 3000 Impulse fire extinguishing equipment
will result in maximum fire extinguishing efficiency, reducing the time needed to
extinguish fires and the amount of water used.
C. After use of the IFEX Impulse Gun and Trolley
1. Close the water valve, and empty the water chamber.
2. Close the air pressure cylinder valve.
3. Empty the gun by pulling the trigger repeatedly, until the remaining air has left the hoses
and the gun.
4. Open the drain valve at the trolley to reduce the air pressure.
5. Refill the water cylinder with fire extinguishing agent as per Para 7.2 and the air pressure
cylinder as per Para 7.3 of the filling instructions.
6. Put the hoses together, if possible in an 8 form and fold them across the handles of the
trolley.
7. Put the gun into the foot ring of the trolley, and tighten it with the strap.
Place the IFEX 3000 Impulse Fire Extinguishing Equipment at its destined location.
Please note carefully:
These test and filling instructions describe the standard rules for testing by the user and for
maintenance of the mobile IFEX 3000 Impulse Fire Fighting Equipment. Maintenance should
be carried out as per DIN 14406, part 4, latest
Warning:
Before testing of IFEX 3000 Impulse Fire Extinguishing Equipment:
1. Make sure the air pressure valve is closed.
2. Use the drain valve at the water container to release remaining pressure.
3. Make sure there is no remaining pressure in the IFEX- gun or hose. This is
done by triggering the gun repeatedly until the remaining air in the hoses and gun
is evacuated.
Caution:
Put on the gun according to the user manual as there may be a recoil due to the
remaining air in the gun!
IFEX 3000 Impulse Fire Fighting Technology
Instruction Manual
Instructions for Use and Operation
IFEX 3035 and IFEX 3050
Mobile Fire Extinguishing Equipment

Test and filling instructions

edition.
